Using close contact WIRING MAP
1 2 3 4
Line
RS485-B RS485-A
Function
STOP UP DOWN
RS232-GND RS232-TXD
S1 SW-PB
STOP
S2 SW-PB
UP
COMMON
S3 SW-PB
LINE
DOWN
8
7
8 7 6 5 4 3 2 1
6
5
4
3
2
1
R 45 J
8P8C
RS-232 Control Protocol
General Port
Baud Rate: 2400
Data Bits: 8
Stop Bits: 1
Parity: None
Hex command:
Screen UP: ff ee ee ee dd
Stop: ff ee ee ee cc
Down: ff ee ee ee ee
In some cases you may need to
enable the RS-232 control by
sending hex command:
ff ee ee ee aa
Note:
When setting RS232 or RS485, if the screen is not able to
operate as it is, please switch position of No. 1 and No. 2.
The electric resistance of return circuit is less than 20
Do not do wiring nearby interference sources.
Setting for Up and Down Limited Positioning for Motor:
The limited positioning of motor has been defaulted when
EX-factory, it is not allowed to reset.
Screen: Voltage AC220-230V/50/60HZ, 0.27Amp, power 60watts.
RF remote(F): Voltage 3V, use CR2450*1 battery.
Radio Frequency: 433Hz. maximum control distance 15m.
Protecting your Screen:
To ensure long lasting viewing enjoyment keep the screen rolled
up when not in use. Check both the front and back surfaces before
5 6 7 8
retracting into the case to make sure it is free of dust, dirt, insects
or other foreign matter. Use a soft brush or cloth to lightly remove
COMMON
any foreign particles.
LINE
Cleaning your Screen:
Use warm water with a mild detergent to remove any marks on the
P1
1 surface or screen casing (only dab, do not rub). Immediately dry the
6
2
screen with a soft cloth or towel. Do not leave it to air dry.
7
3
8
4
9
5
-
RS 232
Never use any solvents, chemicals or abrasive
cleaners on the screen surface as they can
permanently damage the screen surface.
USB Serial Port (COM3) Property
Drive Program
Detail Event
Baud Rate: 2400
Data Bits: 8
Parity: None
Stop Bits: 1
Flow Control: None
Advanced Restore
Confirm Cancel
.
SKYSHOW SCREEN
USER MANUAL
Product code:
GRSKXXXX
