Amber Grandview GRFF H Series User Manual

Step 6

There is a locking latch on the bottom wall mount only.
Up Bracket
Bottom Bracket
Secure Button
Locking Latch
Fig 16

Step 7

Fix the mounts onto the wall separately. (Fig 17-18)
H = Viewing height + 110mm
Up Bracket
Bottom Bracket
Fig 17

Step 8

Hook screen onto the top mount and bottom mount. (Fig 19-20)
Fig 19

Step 9

To uninstall the screen, please press the latch towards the wall to
release bottom frame from bottom mount, then lift the screen a
little to release it totally from top and bottom groove of the
mounts. (Fig 21-22)
Fig 21 Fig 22
Happy Viewing!

Protecting Your Screen:

• Keep away from direct sunlight or high temperatures.
• Use a soft brush or cloth to lightly remove any
foreign particles.
• Keep the fabric from scratches.

Cleaning Your Screen:

• Do not use any solvents, chemicals or abrasive cleaners
h
on the screen surface.
• Use a mild detergent with warm water to remove any
marks on the surface or screen case.
Fig 18
• Always immediately dab the screen with a lint free
soft cloth to avoid soap marks.
• Do not scrub the surface.

Warranty: 12 Months

Fig 20
FLOCKED FRAME SCREEN
USER MANUAL
Product Code:
GRFFxxxH &GRFFxxxAT
