ADI PRO 0E-FOBRMT345 User Manual

FOUR-BUTTON KEYFOB
USER MANUAL
Specifications
Frequency: 345MHz
Battery: CR2032 (225 mAh) 3VDC
Battery Life: 5 years
Enrolling
Each product has a unique serial number printed on the back and each button has a unique loop number
assigned to it as indicated below. You must assign each button to an individual zone and configure it
as a BR (button type) input. Once prompted for the serial number, press and release the desired button
twice to assign that button to the zone. Refer to your specific alarm control panel or receiver instructions for details.
Operation
Away Arming (Loop 3)
Press this button to arm your system when no
one will be home. All the sensors in the systems
will be in the armed mode.
Stay Arming (Loop 4)
Press this button to arm your system while
you are still at home. All the doors and
windows will be armed, but the motion detectors
will remain in standby mode.
Note: For 2GIG panels, pressing both the Away Arming and Disarm key will activate the panic function, if enabled in the control panel.
Assigning Users to Remotes (VISTA Panels)
When a zone is configured to arm or disarm the system with a wireless remote, that zone must be assigned to a user code in the control panel for
it to operate. Refer to the User Code programming section of your specific control panel for details on assigning users to buttons.
Programmable Options (not evaluated by ETL)
There are several programmable options available with this remote. To enter program mode, press and hold the Away Arming and Aux buttons
until the LED turns on. While in programming mode the LED will flash.
• Press the Away key to toggle between no delay or a 1-second delay on all buttons.
• Press the Disarm key to toggle between a normal delay set by the option above, or a 3-second delay only on the AUX button.
• Press the AUX button to toggle between a regular transmission for the Aux button (loop 1), or the Aux button will simulate the
double button press (Away Arming and Disarming button) panic function for 2GIG panels, effectively creating a one button panic
feature for 2GIG panels.
Note: Do not program this feature if using with a Honeywell control panel.
ADI PRO TECHNICAL SUPPORT: 1.833.574.9124 | WEBSITE: adiglobal.com/adiexclusivebrands
Operating Temperature: 32° to 120°F (0° to 49°C)
Operating Humidity: 5-95% RH non-condensing
Compatible with 2GIG receivers and Honeywell
receivers (standar mode) d
Disarm (Loop 2)
Press this button to disarm your system. You do
not have to enter your access code when you use
this key to disarm the system.
Aux (Loop 1)
Press this button to activate the auxiliary function
assigned to this button. Refer to your specific panel
instructions for the available options.
0E-FOBRMT345
© 2024 ADI Global
