Quick Start Guide
AgaMatrix Agile™
Blood Glucose Monitoring System
Customer Care:
0800 093 1812 (UK) | 1800 817 315 (ROI)
About the System
The AgaMatrix Agile Blood
Glucose Monitoring System
allows you to check your glucose
levels with capillary whole blood.
For complete instructions, see
your AgaMatrix Agile Owner's
Guide.
WARNING: The AgaMatrix Lancing
Device MUST be used ONLY to
obtain a blood sample by a single
person for self-testing. Do not use
any lancet or lancing device that
has been used by another person.
Note: You should pair your meter to the AgaMatrix Diabetes Manager App (the App) to set the meter's time and date before testing. This will ensure that
results from meter are sent wirelessly to the App. Please see the reverse side of this Quick Start Guide or see your Owner's Guide for further details.
Blood Glucose Testing Steps
(For complete instructions, see your AgaMatrix Agile Owner's Guide)
1
Insert the test strip
into the meter:
Insert the test strip, with the
contact bars facing up, into the
test strip port. The meter will
automatically be activated.
CAUTION: To ensure accurate
results, wash your hands with
warm, soapy water, rinse and
thoroughly dry before every test.
3
Obtain a drop
of blood:
Squeeze from the base of
your finger up towards
the tip, milking your
finger, until a small blood
drop forms.
Do not squeeze directly
around the lanced area.
5
Remove test strip from
the blood sample when
the visual fill window
completely turns red
and the meter beeps:
The entire visual fill
window will turn red.
The calculation animation
1-2-3 indicates that the meter
is calculating your result.
©2022 AgaMatrix, Inc. All rights reserved. All trademarks and/or copyrights are properties of their respective owners. For patent information, see www.agamatrix.com/patents
Blood Glucose Meter
1) Display Area
2) Test Strip Port
3) Meter Button: Press to
turn on meter, select the
fasting tag and view past
glucose test results.
2
Please see the instructions
for how to prepare the
lancing device, on the right.
Press the lancing device
against the site to be
lanced and press the
release button.
4
The meter displays the apply sample
to test strip animation, indicating it is
now ready for you to apply blood.
The test strip draws
the blood into the
test strip.
6
Following the calculation animation,
the test result will appear on the
meter display. The test result is
stored in the meter's memory.
BEEP
Adding Fasting Tag (Optional):
Press the Meter Button once to tag the
glucose reading with the Fasting Tag.
Remove the used test strip from the
meter. The meter will automatically
turn off.
Snap off the lancing device cap and
cover the lancet point with the flat of
the cover. Remove the used lancet.
Discard the used test strip and lancet properly. Follow
your healthcare professional's instructions for disposal.
Test Strip
1) Contact Bars:
insert this end into
the test strip port
2) Visual Fill Window:
completely fills when
enough sample is
applied
3) Sample Area: blood
or control solution
applied here
Lance the test site:
Bring the test strip
to the blood sample:
View test result
and final steps:
automatically SYNCs To App Via
Bluetooth
wireless technology
®
Reference steps on the reverse side to pair and
In case of emergency, contact your healthcare
professional or emergency medical response.
Lancing System
1) Cocking Handle
2) Depth Selector Dial
3) Depth Indicator Window
4) Release Button
5) Lancet Holder Cup
6) Lancing Device Cap
7) Lancet
8) Lancet Cover
Prepare the Lancing
System
Snap off the cap from
the lancing device.
Release
Button
Insert a new lancet
firmly into the lancet
holder cup.
Twist and gently pull
the lancet cover off.
Replace lancing
device cap.
Set the skin
penetration depth.
1
Pull the cocking handle
out until it clicks.
2
3
4
5
Depth Level
