Q-Audio QMEDIAMIX52 Instruction Manual

5-channel mic/line audio mixer with bluetooth, mp3, fm radio
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
QMEDIAMIX52
Instruction Manual
QMEDIAMIX52 Instruction Manual
Version 1.0
CAUTION - ATTENTION - VORSICHT
RISK OF ELECTRIC SHOCK- DO NOT OPEN
RISQUE D'ELECTROCUTION- NE PAS OUVRIR
STROMSCHLAGGEFAHR- NICHT OFFNEN
In Compliance with the following directives: RoHS Directive
(2002/95/EU) and WEEE Directive (2002/96/EU)
If this product is no longer functional or reaches the end of its
usable life, please take it to an approved recycling plant.
www.q-audio.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QMEDIAMIX52 and is the answer not in the manual?

Questions and answers

Related Manuals for Q-Audio QMEDIAMIX52

Summary of Contents for Q-Audio QMEDIAMIX52

  • Page 1 QMEDIAMIX52 Instruction Manual QMEDIAMIX52 Instruction Manual Version 1.0 CAUTION - ATTENTION - VORSICHT RISK OF ELECTRIC SHOCK- DO NOT OPEN RISQUE D’ELECTROCUTION- NE PAS OUVRIR STROMSCHLAGGEFAHR- NICHT OFFNEN In Compliance with the following directives: RoHS Directive (2002/95/EU) and WEEE Directive (2002/96/EU) If this product is no longer functional or reaches the end of its usable life, please take it to an approved recycling plant.

  • Page 2: Safety Advice

    Introduction: Dear Customer, Thank you for purchasing the QMEDIAMIX52 5 Channel Audio Mixer. For your safety and to ensure you make full use of the product’s features, please make sure you read this manual in full. Safety Advice: • Read this manual in full before operating this product.
  • Page 3 1 piece Bluetooth Aerial 1 piece The Q Audio QMEDIAMIX52 media installation mixer is a versatile audio solution featuring three stereo inputs, two microphone inputs, and a multimedia player with Bluetooth, FM tuner, and USB connectivity. The mixer includes two stereo inputs with pre-set signal LEDs, rear-panel gain controls, and front-panel level adjustments.
  • Page 4 Technical Specifications: Product QMEDIAMIX52 Signal/ Noise > 82dB (Line) Crosstalk Damping > 65dB (Line) <0.05% (Line) Frequency Response 20Hz - 20kHz AC IN (230V Setting) AC220-250V ~ 50Hz AC IN (115V Setting) AC110-120V ~ 60Hz Power Consumption max. 18W Dimensions...

  • Page 5: Internal Settings

    Internal Settings: Emergency Mic Settings Emergency Mic Settings IMPORTANT NOTICE: THE FOLLOWING CHAPTER CONTAINS WORK ON AN OPEN UNIT- WITH CONTACTS, WIRES AND PARTS CARRYING LIVE VOLTAGE EXPOSED. ALL WORK BELOW SHOULD BE CARRIED OUT BY A QUALIFIED TECHNICIAN. IF YOU DO NOT HAVE THE REQUIRED QUALIFICATION, CONTACT YOUR DEALER TO MAKE THESE SETTINGS FOR YOU.
  • Page 6 Using your Product- The Basics: Operation Basics: Connections: When connecting this unit to AC mains, please note: • Check whether the AC mains voltage and frequency matches the product’s specification (rear panel). If the specified voltage does not match your AC plug, do NOT plug it in and contact your dealer immediately.
  • Page 7 File Sorting: Files are stored alphanumerically using the first 8 digits. File System Cache: To allow quick access to the file directory during navigation, the player loads a copy of the file directory to its own memory, when the solid media state is inserted. A countdown will be displayed.
  • Page 8 Controls and Connections: Connections - Rear:...
  • Page 10 Controls and Connections: Controls - Front:...

  • Page 12: Controls And Connections

    Controls and Connections: 52 53 Display - Elements: Remote Control - Elements:...
  • Page 13 Controls and Connections: No. Function Time Display: In Media Mode: Remaining or elapsed time are displayed, depending on setting of component (50) / FM Mode: (Station Scroll Mode)- The station preset number is displayed, (Frequency Scroll Mode)- Remains blank. Time Mode Display - Elapsed (Media Mode Only): Elapsed time of current track. Time Mode Display - Remaining (Media Mode Only): Remaining time of current track.

  • Page 14: Remote Volume Control

    • Wait for single beep from the QMEDIAMIX52. • The devices are now paired (QMEDIAMIX52 can now receive audio via Bluetooth from the device). NOTE: The QMEDIAMIX52 will only support the pairing of one device. To Disconnect a Device: •...
  • Page 15 This product should not be mixed with other commercial wastes for disposal. Thank you for taking the time to read this manual. For further enquiries, please contact us at: Q-Audio (Products) Limited, Unit 15, Rochester Airport Industrial Estate, Laker Road, Rochester, Kent, ME1 3QX.
  • Page 16 www.q-audio.co.uk...
