STAR INDUSTRIES 1150A Operator's Manual

Crane
Spreader Bar
Operator's Manual
for Model 1150A
BEFORE USE, READ AND UNDERSTAND THE
COMPLETE OPERATOR'S MANUAL.
If you need clarification or any additional information call
your Star dealer or call Star Industries @ 1-800-541-1797
during normal business hours.
Installation, Use & Safety Precautions
The model 1150A Adjustable Spreader Bar is
designed for use with a crane of adequate capacity
to safely handle the load. The Spreader Bar is
adjustable from 8 ft to 12 ft. in width and comes
equipped with a crane picking point on top of the
unit. Be aware that the information contained in
this manual is intended as a guide and does not
replace the need for the user to know, understand,
and observe all applicable company, local, state,
and federal safety codes and or requirements. The
model 1150A meets/exceeds the requirements of
ASME B30.20-2006 and is classified as
Category A and Service Class 0 as defined in
ASME BTH-1-2005.
NOTICE - ATTACHMENT MUST BE VISUALLY
INSPECTED BEFORE EVERY USE
CONTACT STAR INDUSTRIES IN REGARDS
TO ANY/ALL EQUIPMENT REPAIRS
4101 Garland Drive, Fort Worth, TX 76117
Phone 817.485.6073 Fax 817.428.6008
www.starindustries.com
RATED LOAD CAPACITY
Empty Weight - 534 lbs.
Center Hook used alone 6,000 lbs.
At 8 feet wide 8,000 lbs.
Extended to 10 feet wide 6,400 lbs.
5,000 lbs.
Extended to 12 feet wide
