EW7TN3272
EN
Washing Machine
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EW7TN3272 and is the answer not in the manual?

Questions and answers

Related Manuals for Electrolux EW7TN3272

Summary of Contents for Electrolux EW7TN3272

  • Page 1 EW7TN3272 Washing Machine User Manual...

  • Page 2: Table Of Contents

    17. ENVIRONMENTAL CONCERNS..............37 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.

  • Page 3: Safety Information

    ENGLISH SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.

  • Page 4: Safety Instructions

    This appliance is intended to be used in household • and similar applications such as: staff kitchen areas in shops, offices and other – working environments; by clients in hotels, motels, bed & breakfast and – other residential type environments;...

  • Page 5: Electrical Connection

    ENGLISH the drum to prevent an internal cable. Should the mains cable need to damage. be replaced, this must be carried out • Always take care when moving the by our Authorised Service Centre. appliance as it is heavy. Always use •...

  • Page 6: Product Description

    • Do not wash fabrics which are heavily such as detergent dispensers. Please soiled with oil, grease or other greasy note that some of these spare parts substances. It can damage rubber are only available to professional parts of the washing machine.

  • Page 7: Appliance Overview

    ENGLISH 3.2 Appliance overview 9 10 Control panel Drain hose Mains cable Lid push handle Transit bolts Drain pump filter Hose support Feet for levelling the appliance Rating plate Inlet hose Information for register product. The rating plate reports the model name The info label reports the model name (A), (A) , product number (B), electrical product number (B ) and serial number (C).

  • Page 8: Technical Data

    4. TECHNICAL DATA Dimension Width/ Height/ Total depth 39,7 cm /90,8 cm /59,9 cm Electrical connection Voltage 230 V Overall power 2200 W Fuse 10 A Frequency 50 Hz Level of protection against ingress of solid particles IPX4 and moisture ensured by the protective cover, except...

  • Page 9: The Inlet Hose

    ENGLISH We recommend that you keep the packaging and the transit bolts for any transport of the appliance. Adjust the appliance correctly to prevent vibration, noise and movement of the appliance when it operates. WARNING! Do not put cardboard, wood or equivalent materials below the appliance feet to adjust the level.

  • Page 10: Water Drainage

    5.3 Water drainage min.600 mm max.1000 mm The drain hose should stay at a height of no less than 600 mm and not more than 1000 mm. You can extend the drain hose to maximum 4000 mm. Contact the authorised service centre for the other drain hose and the extension.

  • Page 11: Control Panel

    ENGLISH 6. CONTROL PANEL 6.1 Control panel description Programme dial Steam Finish touch button Spin reduction options touch button Soft Plus touch button Extra Rinse touch button Temperature touch button Stain touch button Display Prewash touch button Delay Start touch button On/Off push button Time Manager touch button Start/Pause touch button...
  • Page 12 The Temperature area: Temperature indicator Cold water indicator Child safety lock indicator. Delay start indicator. Lid locked indicator. The digital indicator can show: • Programme duration (e. g. • Delay time (e. g. • Cycle end ( • Warning code (e.g.

  • Page 13: Dial And Buttons

    ENGLISH 7. DIAL AND BUTTONS 7.1 Introduction • Decrease the spin speed. The display shows only the spin speeds The options/functions are available for the set programme. not available with all • Additional spin options No Spin washing programmes. Check the compatibility Set this option to deactivate all spin between options/functions phases.
  • Page 14 The appliance empties this option is deactivated. the water out automatically after 18 7.8 Permanent Soft Plus hours approximately. Set this option to optimise the fabric 7.5 Prewash softener distribution and improve fabric softness.

  • Page 15: Time Manager

    ENGLISH The display shows the indicator indicator the selected delay time. After touching the Start/Pause button, the appliance begins the countdown and the lid is locked. 7.11 Time Manager With this option you can reduce the ■ ■ ■ programme duration depending on the load size and the degree of soiling.

  • Page 16: Programmes

    8. PROGRAMMES 8.1 Programme Chart Programme Reference Maxi‐ Programme description Default tem‐ spin (Type of load and level of soiling) perature speed load Temperature Spin range speed range Washing programmes Eco 40-60 1300 rpm 6 kg White cotton and fast-coloured cotton.
  • Page 17 ENGLISH Programme Reference Maxi‐ Programme description Default tem‐ spin (Type of load and level of soiling) perature speed load Temperature Spin range speed range 1 kg Wool and cashmere. Short programme to re‐ fresh maximum 1 kg of machine and hand Cashmere washable woolen and cashmere garments without washing.
  • Page 18 Programme Reference Maxi‐ Programme description Default tem‐ spin (Type of load and level of soiling) perature speed load Temperature Spin range speed range 1200 rpm 2 kg Do not use fabric softener and (1200- 400 Outdoor make sure that there is no soften‐...
  • Page 19 ENGLISH Programme Reference Maxi‐ Programme description Default tem‐ spin (Type of load and level of soiling) perature speed load Temperature Spin range speed range 1200 rpm 1,5 kg Machine washable wool, hand washable (1200 - wool and other fabrics with «hand washing» Wool/Silk 400 rpm) care symbol...
  • Page 20 Programme ■ ■ Spin/Drain ■ ■ ■ ■ ■ ■ Rinse ■ ■ ■ ■ ■ ■ ■ ■ Baby ■ ■ ■ ■ Rapid 14min ■ ■ ■ ■ ■ ■ ■ ■ ■ Anti-allergy ■ ■ ■...

  • Page 21: Woolmark Apparel Care - Blue

    ENGLISH ▲ = Recommended -- = Not recommended 8.2 Woolmark Apparel Care - Blue The wool wash cycle of this machine has been approved by The Woolmark Compa‐ ny for the washing of wool garments label‐ led as «hand wash» provided that the gar‐ ments are washed according to the instruc‐...

  • Page 22: Daily Use

    11. DAILY USE 11.3 Detergent compartments. WARNING! Using detergent and additives Refer to Safety chapters. 1. Measure out specified detergents and 11.1 Activating the appliance the fabric conditioner. 2. Put the detergent and the fabric 1. Connect the mains plug to the mains socket.

  • Page 23: Liquid Or Powder Detergent

    ENGLISH Detergent compartment for washing phase. The marks MAX are the maximum levels of the quantity of detergent (powder or liquid). Compartment for liquid additives (fabric conditioner, starch). The mark is the maximum level for the quantity liquid additives. Flap for powder or liquid detergent. 11.4 Liquid or powder detergent CLICK CLICK...

  • Page 24: Starting A Programme With The Delay Start

    11.8 The SensiCare System The drain pump can operate load detection shortly before the appliance fills water. The programme duration in the display is referred to a 11.7 Starting a programme with medium/high load. the delay start After touching the Start/Pause 1.

  • Page 25: Interrupting A Programme And Changing The Options

    ENGLISH 1. Rotate the selector knob to the "Reset" The SensiCare detection is position carried out with complete 2. Wait for 1 second. The display shows washing programmes only and if the programme duration has not been Now, you can set a new washing reduced by means of the programme.

  • Page 26: Stand-By Option

    2. Remove the laundry from the 3. When the programme is completed appliance. and the lid locked indicator goes 3. Make sure that the drum is empty. off, you can open the lid. 4. Keep the lid and the detergent 4.

  • Page 27: Stubborn Stains

    ENGLISH a. interrupt the programme and • Use only detergents and other open the door (refer to "Daily treatments specially made for Use" chapter); washing machines. First, follow these b. manually redistribute the load so generic rules: that the items are spaced evenly –...

  • Page 28: Care And Cleaning

    • Loading the appliance to the laundry in a tumble dryer. This will maximum capacity indicated for save energy during drying! each programmes helps to reduce 12.5 Water hardness energy and water consumption. • With adequate pre-treatment, stains If the water hardness in your area is high and limited soiling can be removed;...

  • Page 29: Maintenance Wash

    ENGLISH 13.4 Descaling Clean the drum with special products for stainless steel. If the water hardness in your Always follow the area is high or moderate, we instructions that you find on recommend that you use a the packaging of the water descaling product for product.

  • Page 30: Cleaning The Drain Filter

    13.9 Cleaning the drain filter WARNING! • Disconnect the mains Regularly check the drain pump filter and plug from the mains make sure that it is clean. socket. Clean the drain pump if: • Do not remove the filter while the appliance •...

  • Page 31: Emergency Drain

    ENGLISH 13.11 Emergency drain 1. Disconnect the mains plug from the mains socket. If the appliance cannot drain the water, 2. Close the water tap. carry out the same procedure, described 3. Put the two ends of the inlet hose in in 'Cleaning the drain pump' paragraph.
  • Page 32 • Make sure that the sink spigot is not clogged. • Make sure that the drain hose has no kinks or bends. The appliance does • Make sure that the drain filter is not clogged. Clean the fil‐ not drain the water.
  • Page 33 ENGLISH Problem Possible solution • Set the spin programme. The spin phase does • Make sure that the drain filter is not clogged. Clean the fil‐ not operate or the ter, if necessary. Refer to "Care and cleaning". washing cycle lasts •...

  • Page 34: Consumption Values

    15. CONSUMPTION VALUES 15.1 Introduction See the web link www.theenergylabel.eu for detailed information about Energy Label. The QR code on the energy label supplied with the appliance provides a web link to the information related to the performance of the appliance in the EU EPREL database.
  • Page 35 ENGLISH Power consumption in different modes Off (W) Stand-by (W) Delay start (W) 0.50 0.50 4.00 Time to Off/Standby mode is 15 minutes maximum. 15.4 Common programmes These values are indicative only. Programme Litres h:mm °C Cottons 2.50 4:10 1300 90°C Cottons 1.60...

  • Page 36: Quick Guide

    16. QUICK GUIDE 16.1 Daily use Connect the mains plug to the mains 3. Set the desired options by means of socket. the corresponding touch buttons. 4. To start the programme, touch the Open the water tap. Start/Pause button.

  • Page 37: Environmental Concerns

    ENGLISH 16.3 Programmes Programmes Load Product description White and coloured cottons. Normally Eco 40-60 6 kg soiled garments. 6 kg White cotton and coloured cotton. Cottons 3 kg Synthetic items or mixed fabric items. Synthetics Delicate fabrics such as acrylics, viscose, 2 kg polyester items.
  • Page 38 office.
  • Page 40 www.electrolux.com/shop...
