- Page 1 OWNER’S MANUAL LED TV* * Disclaimer LG LED TV applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 22LB480A www.lg.com www.lg.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS CUSTOMIZING TV SETTING LICENSES Accessing main menus Customizing Settings OPEN SOURCE SOFTWARE SETUP Settings NOTICE PICTURE Settings AUDIO Settings TIME Settings ASSEMBLING AND PREPARING OPTION Settings Unpacking LOCK Settings Parts and buttons ENTERTAINMENT Settings Using the Joystick button Lifting and moving the TV TELETEXT... -
Page 3: Licenses
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping and handling) upon email request to opensource@lge.com. -
Page 4: Assembling And Preparing
ASSEMBLING AND PREPARING NOTE Image shown may differ from your TV. Your TV’s OSD (On Screen Display) may differ slightly from that shown in this manual. The available menus and options may differ from the input source or product model that you are using. - Page 5 ASSEMBLING AND PREPARING Remote control, CD (Owner's Manual), Stand Base batteries (AAA) Cards (See p.15) (See p.9) Power Cord AC-DC Adapter AC-DC Adapter (Depending on model) (See p.10) (See p.10) (See p.10) (Depending on model)
-
Page 6: Parts And Buttons
ASSEMBLING AND PREPARING Parts and buttons Screen Speakers Joystick button Remote Control sensor (* This button is located below the TV screen.) Power Indicator Red : When the power is turned off Off : When the power is turned on Using the Joystick button You can simply operate the TV functions, pressing or moving the joystick button up, down, left or right. -
Page 7: Adjusting The Menu
ASSEMBLING AND PREPARING NOTE When your finger over the joystick button and push it to the up, down, left or right, be careful not to press the joystick button. If you press the joystick button first, you can not adjust the volume level and saved programmes. -
Page 8: Lifting And Moving The Tv
ASSEMBLING AND PREPARING Lifting and moving the TV When transporting the TV, do not expose the TV to jolts or excessive vibration. When transporting the TV, keep the TV Please note the following advice to prevent the upright, never turn the TV on its side or tilt TV from being scratched or damaged and for towards the left or right. -
Page 9: Setting Up The Tv
ASSEMBLING AND PREPARING Setting up the TV CAUTION Image shown may differ from your TV. Do not carry the TV upside-down by holding the stand body (or stand base) Attaching the Stand as this may cause it to fall off, resulting in damage or injury. -
Page 10: Mounting On A Table
ASSEMBLING AND PREPARING Mounting on a table Connect the AC-DC Adapter and Power Cord to a wall outlet. Lift and tilt the TV into its upright position on a table. - Leave a 10 cm (minimum) space from the wall for proper ventilation. DC-IN (19V 10 cm... -
Page 11: Using The Kensington Security System
TV might be damaged internally. If you use improper screw, the product might be damaged and drop from mounted position. In this case, LG Electronics is not responsible for it. VESA compatible only with respect to screw mounting interface dimensions and mounting screw specifications. - Page 12 If you install the TV on a ceiling or slanted VESA (A x B) wall, it may fall and result in severe injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel. Do not over tighten the screws as this may cause damage to the TV and void your warranty.
-
Page 13: Making Connections
MAKING CONNECTIONS MAKING CONNECTIONS Antenna connection Connect various external devices to the TV and switch input modes to select an external device. For more information about an external device’s connection, refer to the manual supplied with each device. Available external devices are: HD receivers, DVD players, VCRs, audio systems, USB storage devices, PC, camcorders or cameras, ANTENNA... -
Page 14: Other Connections
MAKING CONNECTIONS Other connections Connect your TV to external devices. For the best picture and audio quality, connect the external device and the TV with the HDMI cable as shown. Some separate cable is not provided. DVD/ Blu-Ray / HD Cable Box / HD STB / Gaming device HDMI OUT USB / HDD... -
Page 15: Remote Control
REMOTE CONTROL REMOTE CONTROL The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully and use the TV correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching the ends to the label inside the compartment, and close the battery cover. -
Page 16: Watching Tv
WATCHING TV WATCHING TV When the basic settings are complete, press the OK Turning the TV on for the first NOTE time If you do not complete the Initial setting, it will appear whenever the TV turns on. When you turn the TV on for the first time, the Disconnect the power cord from the Initial setting screen appears. -
Page 17: Manually Setting Up Programme
WATCHING TV Manually setting up programme Assigning a station name You can assign a station name with five Manual Tuning lets you manually tune and ar- range the stations in whatever order you desire. characters to each programme number. Press SETTINGS and the Navigation Press SETTINGS and the Navigation buttons to scroll to SETUP. -
Page 18: Editing Your Programme List
WATCHING TV Selecting a programme on the Editing your programme list programme list When a programme number is skipped, it means Press LIST to access the programme list. that you will be unable to select it using Press the Navigation buttons to select to button during TV viewing. -
Page 19: Using Additional Options
WATCHING TV Using additional options - 4:3: Resizes images to the previous standard 4:3. Adjusting aspect ratio Resize an image to view at its optimal size by pressing Q.MENU or accessing Aspect Ratio in the PICTURE menu. NOTE - 14:9 : You can view a picture format of 14:9 or a general TV programme in the The available ratio varies depending on 14:9 mode. -
Page 20: Changing Av Modes
WATCHING TV Changing AV modes Using the input list Each AV MODE has optimized image and sound Selecting an input source settings. Press AV MODE repeatedly to select an ap- propriate mode. Press INPUT to access the input sources. - The connected device displays on each Mode Description input source. -
Page 21: Entertainment
ENTERTAINMENT ENTERTAINMENT Tips for using USB storage devices Only a USB storage device is recognizable. If the USB storage device is connected Image shown may differ from your TV. through a USB hub, the device is not recognizable. Connecting USB storage devices A USB storage device using an automatic recognition programme may not be Connect USB storage devices (external HDD,... -
Page 22: Browsing Files
ENTERTAINMENT Any device with more than the recommended capacity may not work PHOTO LIST USB Device Page1/1 No Marked Free Space 4 GB properly. Drive A Up Folder KY103 09/15/2014 GUU.JPG USB storage devices below USB 2.0 are 04/03/2014 KY101 KY104 10/12/2014 09/03/2014... -
Page 23: Viewing Photos
ENTERTAINMENT Supported file format Viewing photos Type Supported file format View image files saved in a USB storage device. The displays on the screen may differ from the Photo JPEG model. Available size Baseline : 64 pixel (W) x 64 pixel (H) Press SETTINGS to access the main - 15360 pixel (W) x 8640 pixel (H) menus. - Page 24 ENTERTAINMENT The following options are available while Q.MENU options for photo list viewing photos. Press Q.MENU. A pop-up window will appears. Press the Navigation buttons to scroll to Set photo view. and press OK Press the Navigation buttons to scroll to one of the following options and press OK Set photo view.
-
Page 25: Listening To Music
ENTERTAINMENT Listening to music When playing, When you press the button, Press SETTINGS to access the main menus. the previous music file will be Press the Navigation buttons to scroll to played. ENTERTAINMENT and press OK When you press the button, Press the Navigation buttons to scroll to the next music file will be played. -
Page 26: Viewing Movies
ENTERTAINMENT Viewing movies Control playback by using the following buttons. Press SETTINGS to access the main menus. Press the Navigation buttons to scroll to ENTERTAINMENT and press OK Press the Navigation buttons to scroll to MOVIE LIST and press OK Press the Navigation buttons to scroll to a folder/file you want and press OK Play movie by using the following menus/... -
Page 27: Video Options
ENTERTAINMENT Tips for using playing video files Playing a video via a USB connection that doesn’t support high speed may not work Some user-created subtitles may not work properly. properly. Files encoded with GMC(Global Motion Some special characters are not supported Compensation) and Qpel (Quarterpel in subtitles. -
Page 28: Divx ® Vod Guide
ENTERTAINMENT DivX VOD Guide ® Code Page Support Language Latin1 English, French, Spanish, Portuguese, Malaysia, ® DivX VOD Registration Indonesia Cyrillic In order to play purchased or rented DivX Russian ® contents, you should register your device with 10 Thai Thai digit DivX registration code from your device at Hebrew... -
Page 29: Customizing Tv Setting
ENTERTAINMENT / CUSTOMIZING TV SETTING CUSTOMIZING TV ® DivX VOD Deregistration SETTING You should deregister your device with 8 digit DivX deregistration code from your device at Image shown may differ from your TV. www.divx.com/vod. NOTE Accessing main menus Once the deregistration is executed, you Press SETTINGS to access the main must register your device again to see menus. -
Page 30: Customizing Settings
CUSTOMIZING TV SETTING PICTURE Settings Customizing Settings Press SETTINGS and the Navigation buttons to scroll to PICTURE. SETUP Settings Press the Navigation buttons to scroll to the Press SETTINGS and the Navigation setting or option you want and press OK buttons to scroll to SETUP. - Page 31 CUSTOMIZING TV SETTING Setting Description Setting Description Picture Selects one of the preset image Screen Customizes the PC display Mode or customizes options in each (RGB- options in RGB mode. mode for the best TV screen Option performance. You are also able Resolution Sets the desired to customize advanced options of resolution.
- Page 32 CUSTOMIZING TV SETTING Basic image options Advanced image options (Depending on model) Setting Description Backlight Adjusts the brightness of the Setting Description screen by controlling the LCD Dynamic Adjusts the contrast to keep it at backlight. If you decrease the Contrast the best level according to the brightness level, the screen...
-
Page 33: Audio Settings
CUSTOMIZING TV SETTING Setting Description Setting Description Colour Gamut Advanced Control Sound Selects one of the preset sound Mode modes or customizes options in Maximizes the utilization of colour each mode. to increase colour quality. Mode Standard: Displays standard set of colours. - Page 34 CUSTOMIZING TV SETTING Stereo/Dual Reception Sound output can be selected according to the type of broadcast received. This feature may not be applied based on coun- When NICAM mono is received, you can try broadcasting circumstance. select NICAM MONO or FM MONO. When NICAM stereo is received, you can When a programme is selected, the sound select NICAM STEREO or FM MONO.
-
Page 35: Time Settings
CUSTOMIZING TV SETTING TIME Settings OPTION Settings Press SETTINGS and the Navigation Press SETTINGS and the Navigation buttons to scroll to TIME. buttons to scroll to OPTION. Press the Navigation buttons to scroll to the Press the Navigation buttons to scroll to the setting or option you want and press OK setting or option you want and press OK When you return to the previous menu,... -
Page 36: Lock Settings
CUSTOMIZING TV SETTING LOCK Settings ENTERTAINMENT Settings Press SETTINGS and the Navigation Press SETTINGS and the Navigation buttons to scroll to LOCK. buttons to scroll to ENTERTAINMENT. Press the Navigation buttons to scroll to the Press the Navigation buttons to scroll to the setting or option you want and press OK setting or option you want and press OK When you return to the previous menu,... -
Page 37: Teletext
TELETEXT TELETEXT Programming a colour button in LIST mode This feature is not available in all countries. If the TV is in SIMPLE text or FASTEXT mode, Teletext is a free service broadcast by most TV press the LIST button to switch to LIST mode. stations which gives up-to-the minute informa- Four teletext page numbers of your choice can tion on news, weather, television programmes,... -
Page 38: Special Teletext Function
TELETEXT Special Teletext Function Index Select the each index page. Time When viewing a TV programme, select this menu to display the time at the top right hand corner of the screen. In the teletext mode, press this button to select a sub page number. -
Page 39: Maintenance
MAINTENANCE MAINTENANCE Cleaning your TV Clean your TV regularly to keep the best performance and to extend the product lifespan. CAUTION Make sure to turn the power off and disconnect the power cord and all other cables first. When the TV is left unattended and unused for a long time, disconnect the power cord from the wall outlet to prevent possible damage from lightning or power surges. -
Page 40: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING General Problem Solution Cannot control the Check the remote control sensor on the product and try again. TV with the remote Check if there is any obstacle between the product and the remote control. control. Check if the batteries are still working and properly installed No image display Check if the product is turned on. - Page 41 TROUBLESHOOTING Video Problem Solution An image displays in black Adjust the color setting in the menu option. and white or the color Keep a sufficient distance between this product and other quality is poor. electronic products. Scroll to other programme. There may a problem with the broadcast.
-
Page 42: Specifications
Product specifications shown above may be changed without prior notice due to upgrade of product functions. For the power supply and power consumption, refer to the label attached to the product. MODELS 22LB480A With stand (mm) 609.9 x 360.8 x 140.6 Dimensions... -
Page 43: Note
SPECIFICATIONS HDMI (DTV) supported mode RGB (PC) supported mode Horizontal Vertical Resolution Frequency Frequency Horizontal Vertical (kHz) (Hz) Resolution Frequency Frequency (kHz) (Hz) 720 x 480 31.469 59.94 31.5 60.00 640 x 480 31.469 59.94 720 x 576 31.25 50.00 800 x 600 37.879 60.317... - Page 44 Make sure to read the Safety Precautions before using the product. Keep the Owner’s Manual (CD) in an accessible place for future reference. The model and serial number of the TV is located on the back and one side of the TV.
