Page 1 RA3100 Omniace Instruction Manual 1WMPD4004444D...
Page 2 Microsoft, Windows, and Windows 10 IoT are trademarks or registered trademarks of Microsoft Corporation in the United States and other countries. Product names and company names in this manual are trademarks or registered trademarks of their respective owners in Japan and other countries.
Page 3: Introduction
OMNIACE RA3100 (hereinafter "the RA3100" or "this product"). This instruction manual explains cautions and methods for handling the RA3100 and its optional input modules. Please read this manual before operating this instrument. If you encounter any problems in the manual, please contact our company.
Page 4: Examining Contents In Package
Also, examine the specifications of the input units and accessories. If there are any missing or damaged items, please contact our sales representative.
Page 5: To Safely Use Products
If any voltage exceeding the rated voltage was supplied, there would be risk of damage to this product, or even a fire. Also, in order to prevent electric shock and hazards such as a fire, be sure to use only the AC power cable supplied with this product.
Page 6: Protective Grounding
Protective Grounding Be sure to ground this product before supplying power. Grounding is necessary to use this product safely, as well as to protect the user and peripheral equipment from injury or damage. Be sure to observe the following instructions: The AC power cable included with this product contains a ground lead.
Page 7: Caution In Handling
Store this product in the following storage environments. Avoid storing in places where the temperature could rise over the storage temperature and where there is direct sunlight exposure such as inside an automobile. Storage temperature range: -20 to 60°C...
Page 8 When storing recording paper for an extended period of time before recording, remove the recording paper from the main unit and insert it in a plastic bag, or as-is if it is still in its original packaging, and then store it in a dark location with a temperature of 25°C or less and humidity of 70% RH or less.
Page 9: Disposing Of The Used Product
The Windows 10 IoT operating system used in this product is provided with a license for embedded use only. This product cannot function as a general purpose PC, and it is limited exclusively for RA3100 use. The embedded system of this product is not allowed to be duplicated and used.
Page 10: Fcc Compliance Information
To Safely Use Products FCC Compliance Information This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Page 11: Symbols In This Manual
Example Used for selecting or setting screen keys. A swipe is the act of pressing the screen with a finger and moving it in a specific direction. Example Used on screens such as the [Thumbnail] screen and [Channel Setup] screen.
Page 12: Warranty
The internal SSD, fan, and backup coin-type battery are treated as consumables and not covered by the warranty. Data recorded on the SSD and external media is not covered by the warranty, regardless of the cause and type of product failure. Make sure to back up your recorded data. Liability: We do not assume any liability for equipment other than A&D equipment.
Page 13: Table Of Contents
DISPOSING OF THE USED PRODUCT ......................9 FCC COMPLIANCE INFORMATION ......................10 SYMBOLS IN THIS MANUAL ........................... 11 WARRANTY ..............................12 NAME AND FUNCTION OF EACH BLOCK ................20 1.1. Name of Each Block ......................... 20 1.2. Display Block ..........................22 1.3.
Page 14 CONTENTS 4.2. Reducing the Input Sensitivity and Connecting the Input Cable ..........43 4.3. Setting the Input Channel ......................45 4.3.1. Channel setup sub menu (for RA30-101) ................45 4.3.2. Setup the input channels ...................... 46 4.4. Selecting the Recording Method ....................51 4.4.1.
Page 15 Search Display Menu ......................105 7.6. Jump Function ........................106 7.6.1. Jump Types and Operations ....................107 7.6.2. Jump Condition Types and Settings ................... 108 7.6.3. Data beginning, center, end ....................109 7.6.4. Date Setup .......................... 109 7.6.5. Time Setup ......................... 110 7.6.6.
Page 16 2ch Frequency Module (RA30-108) ..................201 9.8.1. Overview ..........................201 9.8.2. Relationship between Channels and Settings ..............201 9.8.3. Setting the Input Voltage and Measurement Mode ............202 9.8.4. Measurement Setup ......................203 9.8.5. Reference Materials ......................213 9.9. 2ch Acceleration Module (RA30-109) ..................214 9.9.1.
Page 17 10.10.2. Starting/Stopping Pen Recording ..................259 10.10.3. Starting/Stopping Feeding ....................260 10.11. Relationship between AD Count Value and Measured Value ..........261 10.12. Converting AD Count Values to Physical Quantities .............. 263 MAINTENANCE ........................264 11.1. Managing/Handling Recording Paper and Printer Recorded Data ..........264 11.1.1.
Page 18 11.7. Battery Replacement ......................267 11.8. Fan Replacement ........................268 11.9. Cautions for Disposing This Product ..................268 11.10. Troubleshooting and Inspection ..................... 268 SPECIFICATIONS ........................270 12.1. General Specifications ......................270 12.1.1. Main Unit Basic Specifications ................... 270 12.1.2.
Page 19 CONTENTS OPTIONAL PARTS ........................313 13.1. List of Cables .......................... 313 13.2. List of Probes/Clamp Meters ....................314 13.3. Accessory ..........................315 13.4. List of Spare Parts ........................315 SOFTWARE LICENSE INFORMATION ......................316 1WMPD4004444D...
Page 20: Name And Function Of Each Block
1. Name and Function of Each Block - 1.1. Name of Each Block Name and Function of Each Block This product consists of the following blocks. 1.1. Name of Each Block Front view Handle (retractable) SD card slot Display Block...
Page 21: Top View
1. Name and Function of Each Block - 1.1. Name of Each Block Top view Handle (retractable) Rear view Stand 1WMPD4004444D...
Page 22: Display Block
Pinch in (reduce)/pinch out (expand) the waveform Control Bar Waveform monitor: You can observe the state of the input signal and play back the recorded data on the waveform monitor. Pinch in/out to enlarge or reduce the waveform or scroll the waveform.
Page 23: Operation Panel
Press it during playback to print the waveform between cursors A and B on the monitor. TRIG Press and hold it to print a copy of the screen (screenshot), which can be saved to the main unit or external media in the .png file format. TRIG START Press the key to output a forced trigger.
Page 24: Interface Block
1. Name and Function of Each Block - 1.4. Interface Block 1.4. Interface Block (1) KEY LOCK Disables the operation panel keys to prevent misoperations. (2) SCREEN LOCK Disables the touch panel keys to prevent misoperations. (3) USB Used to save recorded data, etc. Supports USB 3.0.
Page 25: Screen And Setup Menu
Displays the remaining amount of recording paper in the printer block. Displayed in red when the remaining recording paper capacity is at 30% or lower. Press and hold this key to initialize the recording paper type (roll paper or Z-fold paper) and usage amount. When replacing the recording paper, press and hold this key to initialize the remaining amount of recording paper.
Page 26: Control Bar
1.6.2. Control Bar The control bar provides a menu for the functions frequently used with the waveform monitor, such as waveform display control of sampling, etc., thumbnail display, cursor display, and the pen recorder function. Tap the (7) Display switch key on the right edge of the control bar to switch the functions in the order indicated below.
Page 27 1. Name and Function of Each Block - 1.6. Screen and Setup Menu Control bar when playback Touch the PLAYBACK key on the side menu to enter the playback mode and switch the control bar to the menu for playback.
Page 28: Screen Input Operations
Turn the rotary knob clockwise or counterclockwise to change numeric values and selections. The rotary knob is enabled when the area around it is lit. The area lights blue in the standard mode and orange in the fine adjustment mode.
Page 29: Input Keys
(8) Input position operations: Moves the text cursor position left or right. (9) OK: Reflects the numeric value that has been input and closes the dialog box. (10) Cancel: Closes the dialog box without reflecting the numeric value that has been input.
Page 30: Pre-Measurement Procedures
Do not use this product at the following locations. In addition, carefully check the environment when using this product. Locations where the temperature and humidity rise due to direct sunlight or heaters Wet locations Locations where salt, oil, or corrosive gases exist...
Page 31 Connect the input signal to the module after connecting the power cable of the RA series main unit where the module is installed to a 3-pole AC outlet, grounding it, and then turning on the power of the main unit.
Page 32: Installing Optional Modules
Step 2. Disconnect the power cable. Step 3. Grip the handles on both edges and insert the module straight in along the guide rails. The module type should be on the operation panel side. Step 4. Tighten the screws on both edges with a Phillips head screwdriver (No. 2).
Page 33: Paper Loading
When loading a partially used roll, trim the edges for ease of loading, as shown in the figure. The inside of the roll paper is the back side and the outside is the thermal surface that is printed on. 1WMPD4004444D...
Page 34 Insert the recording paper from above the platen roller of the printer block (black roller) from the recording paper outlet of the printer cover and pull it out about 10 cm. Step 4-1. Feed the paper to the recording paper outlet from above the platen roller.
Page 35 Put the paper in the case. Step 2-1. Remove the contents from the case, open the plastic bag and take out the piece of cardboard covering the paper. Use the top cover of the case as a receptacle for the recorded paper.
Page 36 Thermal sensitive side Z-fold paper stock box Step 2-3. Position the stock box so the thermal sensitive side of the paper is facing up and insert the box into the case opening. Thermal sensitive side Z-fold paper case Step 3.
Page 37: Connecting An External Device
2.1.4. Connecting an External Device Connect the DVI-D, LAN, and COM ports of this product with the power off. NOTE If you remove or insert the DVI-D cable after the power has been turned on, the screen may not be displayed, which will make it impossible to operate this product.
Page 38: Turning The Power On/Off
WARNING This product must be grounded before turning on the power. This grounding protection is for the safety of this product, as well as for that of the user and peripheral equipment. If the AC power cable that comes with this product is connected to a 3-pin power outlet equipped with a protective conductor pin, this product is automatically grounded.
Page 39: Power Switch
Turn the power switch of this product on. When the Power switch on the operation panel of this product is turned on, the green LED lights up and the power turns on. NOTE Standby current flows to this product when the AC power cable is connected to the power outlet.
Page 40: Flow Of Measurement
This product records and play back input signals following the procedures described below. 3.1. Flow of Measurement Perform the check "Chapter 2" Confirm that this product has been set in a safe place, and that all the before applying power accessories are properly attached. and turn on the power. "Chapter Select the Select the R&D mode (for research and development) or the MFG...
Page 41: Configuring Measurement
Tips The R&D mode is recommended for those that want to adjust waveform analysis and settings while recording, and the MFG mode is recommended for those that want to perform continuous recording with settings determined in advance.
Page 42: Selection Method
4. Configuring Measurement – 4.1. Selecting the Measurement Mode 4.1.3. Selection Method Setup in the Side menu to display the settings screen. R&D to select the measurement mode. 1WMPD4004444D...
Page 43: Reducing The Input Sensitivity And Connecting The Input Cable
The area around the rotary knob turns blue, and the rotary knob can be used to change the setting. Step 4. Turn the rotary knob counterclockwise to set the minimum input sensitivity.
Page 44 4. Configuring Measurement – 4.2. Reducing the Input Sensitivity and Connecting the Input Cable Step 7. Next, connect the insulation BNC cable (standard) to the BNC terminal of the input module. WARNING Do not input voltages that exceed the maximum allowed input voltage or withstand voltage to an input module.
Page 45: Setting The Input Channel
Set (by tapping the key and turning the knob) the display lower limit value (scale value) of the bottom of the display range. (13) Disp. max: Set (by tapping the key and turning the knob) the display upper limit value (scale value) of the top of the display range.
Page 46: Setup The Input Channels
Tap the Coupling key and turn the rotary knob to change the setting in the order DC → GND → AC. Coupling Contents Enables measurement of the actual input signal, including the DC and AC component.
Page 47 The value displayed for the measurement range (RANGE) indicates the input (measurement) maximum value and corresponds to 10 div on the waveform monitor. When the display position is 50%, the full measurement range of ±RANGE (20 div) is displayed.
Page 48 4. Configuring Measurement – 4.3. Setting the Input Channel Description of Step 4 (setting graph division) "Graph" refers to the area in the Y-T waveform monitor where a channel waveform can be displayed. The graph area can be divided into 1 to 18 graphs. →...
Page 49 Disp. pos. key is tapped, the rotary knob is enabled and the setting value can be changed by turning the knob. The key can also be pressed and held to display numeric keys for directly entering values. Relationship between the display range and display position of the input channel...
Page 50 If the amplitude of the input signal is smaller than the set range, the signal change may be hard to recognize. In this case, you can change the scale of the upper limit value and lower limit value for the display range to enlarge the amplitude of the displayed signal.
Page 51: Selecting The Recording Method
Function". 4.4.2. Recording to a File and Recording Paper Save the measurement data to a file and print it to recording paper. This function provides the following. Nine types of recording modes (start trigger, interval, etc.) Simultaneous recording to three recording devices (printer, SSD, and memory)
Page 52: Recording Setup
4. Configuring Measurement – 4.5. Recording Setup 4.5. Recording Setup 4.5.1. Setup the Sampling Speed An image of the waveform recorded on the selected recording device (PRINTER, SSD, or MEMORY) is displayed on the waveform monitor. The sampling speed of the image waveform recorded on the selected recording device is displayed on the left edge of the control bar.
Page 53: Sampling Speed Of Recording Device
4.5.2. Sampling Speed of Recording Device There are three types of recording device (PRINTER, SSD, and MEMORY). The sampling speed setting range and characteristics of each device are indicated below. 100 ms/div (1 kS/s) 10 min/div (10 S/min), Setting range EXT.
Page 54: Maximum Recordable Times
4. Configuring Measurement – 4.5. Recording Setup 4.5.3. Maximum Recordable Times The maximum recordable times when the internal SSD is empty are indicated in the table below. 4.5.3.1. Printer recording Number of measurement channels Sampling speed 1 channel 2 channels 8 channels 18 channels 36 channels...
Page 55 4. Configuring Measurement – 4.5. Recording Setup 4.5.3.3. SSD Recording (P-P) Number of measurement channels Sampling speed 1 channel 2 channels 8 channels 18 channels 36 channels 500 kS/s 23 hours, 15 minutes 13 hours, 57 minutes 4 hours, 6 minutes 1 hour, 53 minutes 57 minutes, 22 seconds 200 kS/s...
Page 56 4. Configuring Measurement – 4.5. Recording Setup 4.5.3.4. Memory recording Number of measurement channels Sampling speed 1 channel 2 channels 8 channels 18 channels 36 channels 20 MS/s 1 minute, 40 seconds 50 seconds 10 seconds 5 seconds 10 MS/s 3 minutes, 20 seconds 1 minute, 40 seconds 20 seconds 10 seconds...
Page 57: Trigger Setup
When a trigger is detected, memory recording is performed with the data count set in the pre-trigger and memory block size, which represents a single recording operation. When the number of blocks to record is set to a multiple number, recording starts for the next block when one block has finished recording.
Page 58 The trigger level is a value relative to the set measurement range. The value also changes when the measurement range is changed. (Example) When the trigger level is set to 10 mV when the range is 100 mV, and then the measurement range is changed to 200 mV, the trigger level is changed to 20 mV. 1WMPD4004444D...
Page 59 Description of trigger source (3) Detection (4) Threshold When the OR/AND trigger is used: (3) Trigger detection when the UP/DOWN trigger is selected for detection. Trigger UP Threshold Input signal...
Page 60: Pre-Trigger
Trigger level CHn input signal T Trigger filter 5.3. Pre-Trigger When performing memory recording, a pre-trigger can be set to adjust the recording length before and after the trigger detection point in the memory block. Trigger detection Trigger level End measurement...
Page 61: Start Trigger
Press the START key on the operation panel to put this product in the standby state. Printer recording, SSD recording, and memory recording start when the start trigger is detected. Press START key Start trigger occurs...
Page 62: Measuring Input Signals
Measuring Input Signals 6.1. State Transition of Main Unit Operation This product is divided into three states according to the operation state: measure, record, and playback. PRINT key can also be pressed in the measurement state to perform pen recording (real-time waveform printing).The...
Page 63: Monitor Display And Pen Recording
6. Measuring Input Signals – 6.2. Monitor Display and Pen Recording 6.2. Monitor Display and Pen Recording 6.2.1. Monitor Display Function Tap the recording device selection in the side menu to display the image waveform recorded on the selected device on the waveform monitor.
Page 64: Trigger Synchronization
6. Measuring Input Signals – 6.2. Monitor Display and Pen Recording Pausing Tap the PAUSE key on the waveform monitor to stop the monitor. In this state, you can pinch in (reduce) or pinch out (expand) the waveform on the waveform monitor.
Page 65 When is selected as the recording device and NORMAL is selected as the data format, FFT analysis and the X-Y waveform display for the control bar waveform format are enabled. X-Y waveform conditions Recording device: Sampling speed: 1 kS/s or lower...
Page 66: Pen Recording
PRINT key on the operation panel when the waveform format is set to Y-T to perform real-time waveform printing of the displayed sheet. The chart speed (sampling speed) and input module settings can be changed while executing pen recording. Press the...
Page 67 6. Measuring Input Signals – 6.2. Monitor Display and Pen Recording Setting the Chart Speed Keys Follow the procedure below to set the chart speed keys. Step 1. Tap the SETUP key on the side menu to display the setup menu.
Page 68: Text To Print Function
6.2.3. Text to Print Function This product has a function for printing header, annotation, and footer text before, during, and after waveform recording with the printer. Annotations are automatically overlaid on the waveform and printed every 300 mm. Tap the...
Page 69 6. Measuring Input Signals – 6.2. Monitor Display and Pen Recording Setting the Text to Print Step 1. Tap the SETUP key on the side menu display the setup menu. Step 2. Printer in [■ Recording setup] to display the printer related setup menu.
Page 70: Importing And Exporting
The text file is "filename.txt" and the file extension is ".txt". To create a text file using the text editor on a computer and import it to the RA3100, create the above folder and insert the file in that folder.
Page 71: Print Setup
6. Measuring Input Signals – 6.2. Monitor Display and Pen Recording Import Reads a text file saved to external media to the main unit. Place a check mark on the file to import in the text file list on the right of the import/export screen and tap the Import key on the center to display the dialog box for selecting the import destination.
Page 72: Starting And Ending Recording
6. Measuring Input Signals – 6.3. Starting and Ending Recording 6.3. Starting and Ending Recording This product has three recording devices: printer, memory, or SSD. When recording is enabled for a device, the data recorded to each device is recorded to the SSD while it is recorded to the device.
Page 73 This product has nine recording modes to enable complex measurement to be easily set. Press the Mode key to display an explanation of each recording mode on the monitor and select a mode suitable for the measurement to perform. (1) Standard...
Page 74 6. Measuring Input Signals – 6.3. Starting and Ending Recording (1) Standard Press START key End recording Recording time During record Printer recording SSD recording Memory recording Trigger occurred Trigger occurred Trigger occurred When the START key on the operation panel is pressed, recording to the various devices specified...
Page 75 Memory recording Trigger occurred Trigger occurred Trigger occurred When the START key on the operation panel is pressed, recording to the various devices starts and continues until the time set in Recording time in the recording setup elapses, and then the next...
Page 76 Trigger occurred Trigger occurred Trigger occurred When the START key on the operation panel is pressed, this product enters the measurement standby state and recording starts when the channel trigger specified in Start trigger is occurred. Measurement continues until the time set in...
Page 77 Trigger occurred Trigger occurred Trigger occurred When the START key on the operation panel is pressed, this product enters the measurement standby state and starts the procedure indicated in "(6) Start trigger + Interval (N times)" at the time set Start time . 1WMPD4004444D...
Page 78 Recording time Window recording SSD recording When the START key on the operation panel is pressed, recording to the various devices starts, and continues until the STOP key on the operation panel is pressed. The data of the time set in Recording time until stop is recorded to the SSD.
Page 79: Starting And Ending Recording
6. Measuring Input Signals – 6.3. Starting and Ending Recording 6.3.2. Starting and Ending Recording Start recording When you perform either of the following operations, recording starts and this product switches to the recording screen. The screen is enclosed in a red frame.
Page 80: Pausing Recording And Scrolling Back
Scroll the waveform monitor to the right in this state to scroll the waveform back and check the past waveform that has already been recorded. Scroll the waveform monitor to the left to display the waveform recorded after pausing. You can also pinch in (reduce)/pinch out (expand) the waveform.
Page 81: Playback Recorded Data
The recording name set in the recording settings. Setting an easy-to-understand name when recording makes it easier to search for the data to playback. Date/Time: The date and time that the data was recorded Recording info: Displays information on the selected recorded data.
Page 82: Selection Procedure
For information on the versions, see "10.1 Version Information". 7.2. Playback Recorded Data By displaying recording data in the waveform monitor and selecting a device in the side menu, the waveform for each device when recording is displayed. Select recording device...
Page 83: Playback Screen Operations
Pinch in/out the waveform monitor in the time axis direction to enlarge/reduce in the time axis direction and pinch in/out in the amplitude direction to enlarge/reduce in the amplitude direction. The enlargement ratio is displayed in the zoom ratio on the top left of the monitor.
Page 84 Making the scale smaller (with a larger decimation number for the data to display) displays a wider time range of the waveform, because the number of points to display is the same. 1/10 is the 10 x time range, and 1/50 is the 50 x time range. 1/All cannot be selected in the measurement mode.
Page 85: Cursor
(1) Cursor position data information Recorded data information of the cursor A position X is the time from the first of cursor A, and Y is the data value at the position of cursor A. Recorded data information of the cursor B position X is the time from the first of cursor B, and Y is the data value at the position of cursor B.
Page 86: Printing Out
A and B on the monitor. NOTE After reading recorded data, cursor A indicates the start of the data and cursor B indicates the end of the data. Even if the time axis or waveform amplitude is enlarged on the monitor, the printer prints the recorded time axis and amplitude set in the channel setup.
Page 87: X-Y Waveform
X-Y Display Setup The horizontal axis of the display settings box indicates the setting state of waveforms X-Y1 to X-Y4 and allows the display to be switched on or off. With the single screen display, specifies the scale of which channel to display.
Page 88: X-Y Control
(6) CH setup: Configures the channel settings for waveforms X-Y1 to X-Y4. Tap this key to switch to the [X-Y channel settings] screen to configure the X axis and Y axis channel settings for each waveform. (7) All pen down: Resumes waveform display when it has been paused with [All pen up].
Page 89: Fft Analysis
Window function: Select the window function for analysis. Change the setting according to the state of the input signal. AVG processing: Specify the type of averaging for the analysis results and the number of additions for the averaging. 1WMPD4004444D...
Page 90: Analysis Settings
Analysis settings Analysis selection: Select Analysis1 or Analysis2. Analysis Function: Select Analysis1 or Analysis2. The X axis, Y axis, and CH selection are limited by the analysis type. Available setting keys are brighter. X axis: Sets the X axis of the analysis waveform.
Page 91: Search Function
7. Playback Recorded Data – 7.5. Search Function 7.5. Search Function The search function searches for recorded data with the specified search conditions and displays the S mark (search mark) and the waveform near the results on the Y-T waveform.
Page 92 When the settings are complete, tap the Execute key. The search starts, and when the search is complete, the S mark and the waveform near the results are displayed on the Y-T waveform, and side menu switches to the "7.5.10. Search Display Menu."...
Page 93: Search Method Types And Settings
For "Mode" For "X-Y Display" For "FFT Display" When memory recording or search detection is set to "Mark" When the search channel is the logic module and "10.2.2. P-P Sampling" Conditions for redisplay Redisplay key is enabled when a search has been executed.
Page 94 A. B/W CURSOR The data between A and B is the target and the number of detection results is 1. Cursor A moves to the point where the search result is Cursor A, according to the cursor link set to A.
Page 95: Peak Value Search (Maximum/Minimum)
Threshold 0 For [ALL] For [B/W CURSOR] The figure above is the search result when the search setting is LEVEL UP and the threshold is set to 0. The search is executed for the topmost sine wave (1,000 waves or more).
Page 96: Peak Value Search (Local Maximum/Local Minimum)
If there is no sample data equal to the length of the filter before and after the search point, that detection point is disabled. When the filter is set to 10 (samples), searching is performed from the 11th item of sample data.
Page 97: Search Example
Because the local maximums are valid from the 11th item of sample data, those local maximums are the detection points. The 13th, 15th, 17th, 19th, and 21st items of sample data are not deemed to be local maximums due to filtering.
Page 98: Level Search (Level Up/Level Down)
7. Playback Recorded Data – 7.5. Search Function Search example 4 The local maximum and local minimum markers are the detection points. The red circle will not be a detection point. This is because there is no data of the filter length after that point.
Page 99 LEVEL UP search example 2 This section is an example of when LEVEL UP is set and filtering is set to 10. The marker is the detection point. The data is the same as "LEVEL UP search example...
Page 100: Window Search (Into Win/Out Win)
LEVEL DOWN search example 2 This section is an example of when LEVEL DOWN is set and filtering is set to 10. The marker is the detection point. The data is the same as "LEVEL DOWN search example...
Page 101 "10.2.2. P-P Sampling" When INTO WIN is set, the samples where the conditions lower threshold < maximum data value and minimum data value < upper threshold are met are the detection points. When OUT WIN is set, the samples where the condition lower threshold >...
Page 102 7. Playback Recorded Data – 7.5. Search Function INTO WIN search example 2 This section is an example of when INTO WIN is set and filtering is set to 10. The marker is the detection point. The data is the same as "INTO WIN search example...
Page 103: Logic Search
The channels are divided into two groups (Channel A and Channel B), with CH1 to CH8 corresponding to Channel A and the rest corresponding to Channel B. The detection points are the samples where the AND or OR operation in each group can be performed and the setting conditions are met.
Page 104: Trigger Search
"9.10.6. Reference Materials". For a mark, the S mark on the Y-T waveform is not displayed. A mark search cannot be performed for memory recording. See "Conditions where searching cannot be performed" in "7.5.2. Search Method Types and Settings". 1WMPD4004444D...
Page 105: Search Display Menu
Tap (1) to enable the jog dial. The jog dial works in increments of 10 for the standard mode and increments of 1 for the fine adjustment mode. For information on each mode, see "1.3.
Page 106: Jump Function
7. Playback Recorded Data – 7.6. Jump Function 7.6. Jump Function Set the following jump conditions to jump to the corresponding location. (The Y-T waveform display is updated.) BEGINNING: Jumps to the beginning of the recorded data CENTER: Jumps to the center of the recorded data END: Jumps to the end of the recorded data DATE:...
Page 107: Jump Types And Operations
For numeric entry, tap the target settings key to change the frame to orange. The area around the rotary knob turns blue, and the rotary knob can be used to change the setting. Pull-down list settings (Type 1) Orange Counterclockwise...
Page 108: Jump Condition Types And Settings
Move (link) Cursor A to the S mark. Link with Cursor B. When the cursor link setting is "B", the jump destination is "CURSOR", and the cursor setting is "A", Cursor B moves to the same point as Cursor A.
Page 109: Data Beginning, Center, End
Date Setup Tap the red frame to display the setup screen. Tap the date and set the year, month, and day by swiping, then tap the time and set the hour and minute by swiping. Tap the remaining second, millisecond, and microsecond, and nanosecond, and use the jog dial to specify the settings or press and hold to specify the settings on the numeric entry screen.
Page 110: Time Setup
Tap the red frame to display the setup screen. Tap the day, hour, minute, second, millisecond, and microsecond, and nanosecond, and use the jog dial to specify the settings or press and hold to specify the settings on the numeric entry screen.
Page 111: Cursor
Cursor", set Cursor A or Cursor B. Cursor Setup Tap the cursor and use the jog dial to specify the settings or press and hold to specify the settings on the numeric entry screen. Setting range: 0 to recorded sample count - 1 Cursor B time before jump execution Cursor B (time 1 s) is displayed in the center of the Y-T waveform.
Page 112: Setup Details
Configures settings related to recording, such as the recording conditions and channel. “8.2 Recording Setup” (4) Main Unit Setup: Configures settings related to the main unit, such as the time and communication. “8.3 Main Unit Setup” (5) Management: Performs management of the main unit, such as file operations and maintenance.
Page 113: Create A Config File
8.1. Create a config file Create configuration data containing the current measurement mode, recording setup, and main unit setup. The created configuration data is recorded to the SSD in the main unit and displayed in the list setup management. Settings can be restored from the configuration data.
Page 114: Recording Setup
8.2. Recording Setup Configure Recording , Channel list , Sheet , Printer , and Other . Tap a settings category to display the detailed settings screen for that category. 8.2.1. Recording Recording in the Recording setup to display a list of the settings related to recording.
Page 115: Common Setup
8.2.2.1. Common Setup When Common is tapped, the settings common to all input modules are displayed, and you can tap a cell to change the setting value of that cell. The items in the list are indicated below. Batch: Enables the batch configuration of the selected channels.
Page 116 = y1 - ax1 = y1 - x1(y2 - y1)/(x2 - x1) Unit: Sets the unit for the output of the physical quantity conversion. Tap to display the unit table and select the target unit. If the target unit is not in the table, tap the...
Page 117 Enables the batch configuration of the selected channels. You can tap Select all on the top right to select all the channels. Displays the slot number and channel number, connected with a hyphen. Module: Displays the model of the input module. Sheet: Displays the registered sheet number.
Page 118: Sheet Setup
8. Setup Details – 8.2. Recording Setup 8.2.3. Sheet Setup Sheet in the recording settings to display the graph settings and a list of the monitor display and printer waveform sheet settings. 8.2.3.1. Graph Graph to display the settings related to the number of divisions (number of graphs) of the Y-T waveform.
Page 119 SHEET3 keys on the bottom left enable you to check the display of each sheet. You can check the signal names and scale values. Whole view: When the display is enlarged, tap the Whole view key to resize the display to match the height.
Page 120 When the signal unit is set to "1 CH" in "9.5.2 Setting the Input Channel" ("16 Channel Logic Module (RA30-105)"), assignment is performed on a single channel basis. Tap the channel key to display a dialog and assign the selected channel to the graph of the sheet. 1WMPD4004444D...
Page 121 Tap to assign all channels of all modules to the graph of the sheet. Up to 48 channels can be enabled for a single sheet, and the current number of channels used is displayed on the right side of the table. When the number of channels used exceeds 48, tap Cancel and assign the channels on another sheet.
Page 122: Printer
8. Setup Details – 8.2. Recording Setup 8.2.4. Printer Printer in the recording settings to configure the various print functions for printer output. 8.2.4.1. Printing Setup Printing to configure the various information printed at the same time as the waveform. Header: This product prints the header Text/CH name before printing the waveform.
Page 123 Sampling speed , Chart speed , or as the recording speed to print below the waveform. Time Recording speed Feed length: Sets the length to feed after all printing is complete, including waveform printing and screen copy (screenshot) printing. 1WMPD4004444D...
Page 124 8. Setup Details – 8.2. Recording Setup Printing example 1st printed line Header CH name Annotations Footer 86th printed line 1WMPD4004444D...
Page 125 8. Setup Details – 8.2. Recording Setup 8.2.4.2. Text to Print Header , Annotation , or Footer to display the corresponding settings screen for the text to print. The setting method is the same for each. For details, see "6.2.3 Text to Print Function".
Page 126: Other Setup
"10.3.2 External Sampling" X axis notation: Set the time, date, and point. X axis notation settings Waveform monitor X axis display Output recording info XML file: Enable this setting to read the recording file in a custom application. When enabled, an XML format file containing the recording information is added to the recording data.
Page 127: Main Unit Setup
8. Setup Details – 8.3. Main Unit Setup 8.3. Main Unit Setup Configure Environment , Comm. , Display , and Other . Tap a settings category to display the detailed settings screen for that category. 8.3.1. Environment Setup Tap the Environment in the main unit settings to display the [Environment] screen.
Page 128 Sets the time of this product. Tap the Date and time key to display the [Date and time] dialog box. Tap and set the year, month, day, hour, and minute. (6) Display brightness: Changes the screen brightness. Set a value between 1 and 10.
Page 129: Communication Setup
8.3.2. Communication Setup Tap the Comm. in the main unit settings to display the [Comm.] screen. The communication, Web server, FTP server, and data transfer settings of this product can be configured on the [Comm.] screen. 8.3.2.1. Communication Tap the Comm.
Page 130 8. Setup Details – 8.3. Main Unit Setup (1) IP address setup: Select whether to automatically retrieve (using DHCP) or manually set the IP address of the LAN, etc. The settings in (2) to (4) are not required for automatic retrieval. (2) IP address: Manually sets the IP address of the LAN.
Page 131 8. Setup Details – 8.3. Main Unit Setup RS-232C Setup CAUTION Caution Regarding RS-232C Settings When using the RS-232C port of this product to communicate with an external device, match the RS-232C settings with those of the host device. Tap the RS-232C box on the [Comm.] settings screen to display the RS-232C settings...
Page 132: Authentication Settings
Select this check box to display the characters that are input for the password. Tips The available characters for the user name and password are a to z, A to Z, 0 to 9, and hyphen. If any other characters are entered, the key is disabled.
Page 133: Web Server Settings
Enables/disables the Web server function. (2) Authentication: Enables/disables the authentication function. When enabled, the Web server is used with authentication. (The user name and password in the authentication settings are input from the computer when connecting.) (3) Access restrictions: Selects the access restrictions for the Web browser.
Page 134 (2) Authentication: Sets whether to use basic or anonymous authentication. When enabled, basic authentication is used. (The user name and password in the authentication settings are input from the client when connecting.) When disabled, anonymous authentication is used. (Enter "anonymous" as the user name and leave the password blank when connecting from the client.)
Page 135: Data Transfer
The data transfer function is stopped Transferring ● Data is being transferred Standby ■ A connection has been established with the destination and the data transfer process is waiting to start Not connected □ A connection has not been established with the destination Error...
Page 136 Sets the type of measurement data to transfer. (5) Protocol: Sets the protocol for communication with the PC. (6) UDP destination: Sets the IP address and port number of the PC. This is enabled when UDP is set as the protocol. (7) Transfer data: Sets one-shot or continuous as the type of data to transfer.
Page 137: Display Setup
Mark line is available when the optional remote control module is installed. Search result line: Switches the search result line on or off. Displaying the Trigger Line, Mark Line, and Search Result Line in the waveform monitor Trigger line Search result line...
Page 138: Other
Other main unit settings can be configured on the [Other setup] screen. Follow cursor: When enabled, the waveform and cursor are displayed when the cursor moves outside the waveform monitor. When disabled, the cursor moves but the waveform does not when the waveform moves outside the waveform monitor.
Page 139: Management
8.4.1. File Management File management in the management settings to display the [File management] screen. Operations can be performed on the recorded data, image data, and configuration data saved to this product on the [File management] screen. 8.4.1.1. Recording Tap the...
Page 140 The recording settings of this product are saved together with the recorded data. Select the data for the recording conditions to restore/set again on the [Recording] management screen, and tap the Restore setting key to set the recording conditions to the main unit.
Page 141 Updating a File You can update the file format of recorded data that cannot be played back because the file version is too old. Select the file to update on the [Recording] management screen, and tap the Update file key to update the file.
Page 142 Recorded data list on internal SSD Recorded data list on external media Place a check mark (✔) on the data to back up Place a check mark (✔) in the selection field of the data to back up and tap the Export key in the center to export the recorded data.
Page 143 Open the [Import/Export] screen in the same way as when exporting data, and import backup data backed up to external media to the main unit. When importing, place a check mark (✔) in the recorded data list for external media on the right, and tap the Import key in the center.
Page 144: Image Management
Image key in the center of the [File management] screen to display the [Image] management screen. Press and hold the PRINT key on the [Image] management screen to manage the screenshot images of the monitor. A list of the image data on the internal SSD of this product is displayed on the left side of the screen.
Page 145: Exporting Images
Tap the Export key to display the external media selection dialog box and select the target external media. to switch to the [Export] screen. Place a check mark (✔) in the selection field of the data to export and tap the...
Page 146 8. Setup Details – 8.4. Management 8.4.1.3. Setup Tap the Setup key in the center of the [File management] screen to display the [Setup] management screen. The [Setup] management screen enables you to manage the configuration data created with [Create a config file].
Page 147: Restore Setting
Tap the key to switch to the [Import/Export] screen. Place a check mark (✔) in the selection field of the configuration data to back up and tap the Export key in the center to export the configuration data.
Page 148: Importing Settings
8. Setup Details – 8.4. Management Importing Settings Open the [Import/Export] screen in the same way as when exporting data, and import backup data backed up to external media to the main unit. When importing, place a check mark (✔) in the configuration data list for external media on the right,...
Page 149: Maintenance
SSD, as data will not be able to be retained in the long term. If [Stop] is displayed for the state of the fan, the fan has failed and needs a repair. The check passes if there are three or less pixel defects in the LCD at the time of delivery.
Page 150 Test printing prints the date and time and serial number of the main unit on recording paper, then prints a test pattern over the entire surface of the paper. The test pattern can be used to check for horizontal density variation and damage to the thermal head for printing.
Page 151: Operation History
8. Setup Details – 8.4. Management (9) KEY: Use this to check the rotary knob and keys of the operation panel. The display on the screen is highlighted when a key on the operation panel is pressed or the rotary knob is turned clockwise or counterclockwise.
Page 152: Version Management
This product can perform the update by itself. An upgrade file or other file is not required. (3) Warning display: This is displayed when the versions of the main unit software and module do not match. Need module update: This is displayed when the version of the module is older than the main unit software.
Page 153: Using Optional Modules
This two channel voltage input module samples a DC to 100 kHz signal at 16-bit 1 MS/s within the measurement range of ±100 mV to ±500 V and can perform A/D conversion. It includes an antialiasing filter and analog filter. It is insulated between each channel and between input and output.
Page 154: Measurement Setup
When the input exceeds the measurement range, "OVER RANGE" is displayed on the bottom right of the screen, and the main unit emits a warning beep. Reduce the sensitivity with the measurement range so that the input signal does not exceed the range. To silence the warning beep, disable the buzzer sound setting.
Page 155 To perform zero cancellation, tap the Zero adjust key (14) after waiting for a warm-up period of 60 minutes. NOTE This function is for canceling internal offset and drift, and does not cancel the offset of the input signal. 1WMPD4004444D...
Page 156: Reference Materials
9.1.4. Reference Materials CAUTION Ensure that the voltage between each input and the chassis (GND) and between each channel does not exceed 300 V(DC+ACpeak) . Damage may be caused if the voltage is exceeded. Input cable The input connectors for CH1 and CH2 are insulated BNC connectors. Do not connect metallic BNC plugs, as they may damage the connectors or cause connection problems.
Page 157: 4Ch Voltage Module (Ra30-102)
This four channel voltage input module samples a DC to 100 kHz signal at 16-bit 1 MS/s within the measurement range of ±1 V to ±200 V and can perform A/D conversion. It includes an analog filter for waveform observation. It is insulated between each channel and between input and output.
Page 158: Measurement Setup
When the input exceeds the measurement range, "OVER RANGE" is displayed on the bottom right of the screen, and the main unit emits a warning beep. Reduce the sensitivity with the measurement range so that the input signal does not exceed the range. To silence the warning beep, disable the buzzer sound setting.
Page 159: Reference Materials
Zero adjust key (14) after waiting for a warm-up period of 60 minutes. NOTE This function is for canceling internal offset and drift, and does not cancel the offset of the input signal. 9.2.4. Reference Materials CAUTION Ensure that the voltage between each input and the chassis (GND) and between each channel does not exceed 300 V(DC+ACpeak).
Page 160 300 V (DC + AC peak) 3ch H ±200 V 300 V (DC + AC peak) 4ch H ±200 V Between each channel and the chassis, to ground (connect to power cable with ground terminal) 300 V (DC + AC peak) 1WMPD4004444D...
Page 161: 2Ch High Speed Voltage Module (Ra30-103)
This two channel high voltage input module samples a DC to 5 MHz signal at 16-bit 20 MS/s within the measurement range of ±100 mV to ±500 V and can perform A/D conversion. It includes an analog filter for waveform observation. It is insulated between each channel and between input and output.
Page 162: Measurement Setup
When the input exceeds the measurement range, "OVER RANGE" is displayed on the bottom right of the screen, and the main unit emits a warning beep. Reduce the sensitivity with the measurement range so that the input signal does not exceed the range. To silence the warning beep, disable the buzzer sound setting.
Page 163 To perform zero cancellation, tap the Zero adjust key (14) after waiting for a warm-up period of 60 minutes. NOTE This function is for canceling internal offset and drift, and does not cancel the offset of the input signal. 1WMPD4004444D...
Page 164: Reference Materials
Input frequency and input voltage derating characteristics A maximum of 1000 Vp-p can be input for the voltage and 5 MHz for the frequency, but there are restrictions on the relationship between the voltage and frequency. These set limits to avoid damage to devices and enable safe measurement.
Page 165: 2Ch Ac Strain Module (Ra30-104)
500(μm/m=με) to 80000 (μm/m=με) and performs A/D conversion. It is used by connecting the output of a strain gauge type converter or strain gauge. It includes an auto balance and simple bridge check function. It is insulated between each channel and between input and output. NOTE When using this module, the Remote Control Module (RA30-112) must be installed to slot 9 of the RA3100 main unit.
Page 166: Setting The Input Channel
9. Using Optional Modules – 9.4. 2ch AC Strain Module (RA30-104) 9.4.3. Setting the Input Channel <This section describes the setting switches and setting values of the RA3100 main unit. > Channel setup sub menu 1 <Channel setup sub menu 1>...
Page 167 Perform a simple bridge check. If a bridge error is detected, an error message is displayed. (The message "Bridge is in error." is displayed if an error is detected.) If this error message is displayed, check the connection between the bridge and the sensor. (24) Close:...
Page 168: Measurement Setup
9. Using Optional Modules – 9.4. 2ch AC Strain Module (RA30-104) 9.4.4. Measurement Setup Check the slot number and channel, connect the signal to the corresponding input module, and enable Meas. key to display the input waveform on the monitor screen. Perform adjustment for the required signal waveform while viewing the waveform.
Page 169 When the input exceeds the measurement range, "OVER RANGE" is displayed on the bottom right of the screen, and the main unit emits a warning beep. Reduce the sensitivity with the measurement range so that the input signal does not exceed the range. To silence the warning beep, disable the buzzer sound setting.
Page 170: Reference Materials
Do not input voltage or current. Doing so may lead to failure. Ensure that the voltage between each input and the chassis (GND) and between each channel does not exceed 100 V (DC + AC peak). Damage may be caused if the voltage is exceeded.
Page 171 Maximum rated voltage to ground RA3100 main Input module Slots Between channels 100 V (DC + AC peak) Between each channel and the chassis, to ground (connect to power cable with ground terminal) 100 V (DC + AC peak) 1WMPD4004444D...
Page 172 9. Using Optional Modules – 9.4. 2ch AC Strain Module (RA30-104) With bridge box connection An A&D bridge box is described in this example. The bridge box includes a terminal box, cables, and connectors. The terminal box has a terminal for connecting the strain gauge and three high-performance resistors.
Page 173 Refer to "Correcting the Measured Strain Value (3) When the cable distance between the bridge box and converter is too long" in "9.4.5 Reference Materials"...
Page 174 The elastic body is also referred to as the sensor. The sensor is made of a material with a high proportional limit and low creep and hysteresis. The sensor is connected to the strain gauge to form the bridge circuit. Temperature compensation and anti-humidity treatment are performed.
Page 175 For information on the compensation method, see "Measurement Value Compensation". Use a converter with the E terminal of this product and the other A, B, C, and D terminals not connected.
Page 176 2, and 4 gauges can be used. This enables different combinations where the gauges are separated by the strain received by the strain gauge, such as same sign same value, different sign same value, and different sign constant proportion value. The properties of the bridge can also be effectively utilized to implement measures for temperature compensation, error elimination, and output boosting.
Page 177 Strain value = measurement value / N Twisting strain detection only Rg2 Rg1 Rg1 Rg2 Rg1 Rg4 Four Eliminate pulling, compressing, Output active and bending strain Rg2 (e) gauge D C B A Temperature compensation method Bridge output coefficient N = 4 Rg3 Rg4 Rg2 Rg3...
Page 178 Tips When the chassis of the bridge box or strain gauge type converter has GND potential, not connecting the E terminal to the chassis of the bridge box or strain gauge type converter may improve stability and reduce noise. Strain Measurement Value Compensation (1) When the gauge factor differs The gauge factor of this product is assumed to be 2.00.
Page 179 (3) When the cable distance between the bridge box and converter is too long If the cable connecting the bridge box, converter, and RA30-104 is too long, the cable conductor resistance will cause the bridge voltage to decrease and cause a difference between the strain value and the value measured with this module.
Page 180: 16Ch Logic Module (Ra30-105)
It supports voltage (high level /low level) detection and non-voltage contact (open/close) of input signals. Pulses can respond at 1 μs or lower. 16 channel data synchronizes for measurement and recording. The probe that can connect to this...
Page 181 Specified as the percentage of the display width when the full range of each graph is 100%. The eight channel signals are displayed at equal intervals and the overall display width can be set. (10) Signal amplitude: Sets the high level (waveform) height as a percentage to the low level of each channel.
Page 182 9. Using Optional Modules – 9.5. 16ch Logic Module (RA30-105) (12) Graph/Wave display: Tap inside the Graph/Wave display frame to display the setting dialog. Set G1 to G18 for the graph using the graph keys. When waveform display is enabled, the waveform is displayed in the waveform monitor.
Page 183: Measurement Setup
Take care, as applying high voltage can damage the module. Use the 1539S floating voltage probe when inputting high voltage. Check the slot number and channel, connect the signal to the corresponding input module, and enable Meas. to display the input waveform on the monitor screen. Perform adjustment for the required signal waveform while viewing the waveform.
Page 184: Reference Materials
+5VA2 Connector for input signal: DF02R020NA3 (Japan Aviation Electronics Industry) The A series and B series are complementary. GND (B series) is the input common for A series signals. The plugs (manufacturer model numbers) corresponding to each input signal connector are indicated below.
Page 185 (connect to power cable with ground terminal) CAUTION Ensure that the voltage between each input and the chassis (GND) does not exceed 42 V (DC+ACpeak).Damage may be caused if the voltage is exceeded. There is no insulation between the inputs. L (GND) is connected internally.
Page 186: Options
9. Using Optional Modules – 9.5. 16ch Logic Module (RA30-105) 9.5.5. Options Connection cables and terminal blocks The following cables, terminal blocks, and probes are provided for signal input. Name (type) Shape/characteristics For logic input 8 ch logic cable 20P - 4CH x 2,...
Page 187 9. Using Optional Modules – 9.5. 16ch Logic Module (RA30-105) Pin layout Pin layout of RA30-105 input connectors and correspondence chart of remote control cables and terminal block connection cables. For a combination of AX-PCX-10S20 terminal block and RA30-504 cable...
Page 188 9. Using Optional Modules – 9.5. 16ch Logic Module (RA30-105) ⑧ ⑦ ⑥ For a round connector 8 channel logic cable ⑤ ④ ③ RA30-503 RA30-105 ② ① CHA / CHB connecter 8 channel logic cable (round connector conversion) Pin number Pin number Mark indication Mark color...
Page 189: 2Ch Temperature Module (Ra30-106)
16-bit sampling with a three-stage data update rate to enable A/D conversion. It includes functions for switching the internal/external reference junction and checking for disconnections. It is insulated between each channel and between input and output, to safely support general temperature measurement.
Page 190: Measurement Setup
Displays the current available measurement range and measurement value. 9.6.3. Measurement Setup Check the slot number and channel, and set the sensor type, etc. to use for the corresponding input module. Follow the procedure below to set the input channel.
Page 191 Refresh data . Select high speed, medium speed, or low speed as the data refresh rate. With low speed (1s), the response speed is slower but there is less variation in data and accurate measurement can be performed. At medium speed (100 ms), the data is updated 10 times per second. This provides more stable measurement accuracy than with high speed.
Page 192: Reference Materials
(TC). Leave the S terminal unconnected for the grounded type. NOTE When using the non-contact type sensor, the S terminal must be insulated from the + terminal and - terminal. If they are connected, correct measurement will not be able to be performed and failure may occur.
Page 193 After screwing the platinum resistance temperature detector into the temperature sensor connector, insert it into the connector of the front panel. The terminal names of the input connectors are indicated on the right side of the panel as A, B, and b. + /A terminal Connect the A side wire of the platinum resistance temperature detector (RTD).
Page 194 Secure the socket to the connector of the input panel using the socket fixing screw. Input connectors Connector fixing screw NOTE Socket fixing screw tightening torque: 0.2 Nm to 0.25 Nm The cable cover protects the terminal and cable fixing screw areas from static electricity, etc. 1WMPD4004444D...
Page 195 This module has an LFD function that can be enabled or disabled when performing TC measurement. When enabled, 0.5 μA current is supplied and + side over range output occurs when the sensor is open (at 300 kΩ or higher). (Over range detects the possibility of a disconnection.)
Page 196: Spare Parts
9. Using Optional Modules – 9.6. 2ch Temperature Module (RA30-106) 9.6.5. Spare Parts Two sets of temperature sensor connectors are included as standard, and they can be connected to an alternate sensor in advance to allow easy changing. Name (type)
Page 197: 2Ch High Voltage Module (Ra30-107)
This two channel high voltage input module samples a DC to 100 kHz signal at 16-bit 1 MS/s within the measurement range of ±2 V to ±1000 V and can perform A/D conversion. It has functions for voltage measurement, effective value measurement, and analog filtering. It is insulated between each channel and between each channel chassis.
Page 198: Measurement Setup
9. Using Optional Modules – 9.7. 2ch High Voltage Module (RA30-107) 9.7.3. Measurement Setup Check the slot number and channel, connect the signal to the corresponding input module, and enable Meas. key to display the input waveform on the monitor screen. Perform adjustment for the required signal waveform while viewing the waveform.
Page 199 When the input exceeds the measurement range, "OVER RANGE" is displayed on the bottom right of the screen, and the main unit emits a warning beep. Reduce the sensitivity with the measurement range so that the input signal does not exceed the range. To silence the warning beep, disable the buzzer sound setting.
Page 200: Reference Materials
9.7.4. Reference Materials CAUTION Ensure that the voltage between each input and the chassis (GND) and between each channel does not exceed 1000 V (DC + AC peak). Damage may be caused if the voltage is exceeded. Input cable The input connectors for CH1 and CH2 are safety banana terminals.
Page 201: 2Ch Frequency Module (Ra30-108)
±1 V to ± 500 V. It has nine measurement modes (Period, Frequency, Rotation speed, Power freq., Freq. deviation, Pulse width, Duty cycle, Pulse count, and Pulse integ.) and a function for constantly monitoring the input signal. It is insulated between each channel and between each channel chassis.
Page 202: Setting The Input Voltage And Measurement Mode
9. Using Optional Modules – 9.8. 2ch Frequency Module (RA30-108) 9.8.3. Setting the Input Voltage and Measurement Mode <This section describes the setting switches and setting values of the RA3100 main unit. ＞ (11) (12) (13) (14) (10) (15) (16)
Page 203: Measurement Setup
9.8.4. Measurement Setup Check the slot number and channel, connect the signal to the corresponding input module, and enable the Meas. key to display the input waveform on the monitor screen. Perform adjustment for the required signal waveform while viewing the waveform.
Page 204 When the input exceeds the measurement range, "OVER RANGE" is displayed on the bottom right of the screen, and the main unit emits a warning beep. Reduce the sensitivity with the measurement range so that the input signal does not exceed the range. To silence the warning beep, disable the buzzer sound setting.
Page 205: Setting The Measurement Mode
Set the display range and display position. See the description in "4.2.2 Set the input channels - Display Range and Display Position (Display Area)". Disp. range: The display width in the amplitude direction of the waveform display area on the waveform monitor Disp.
Page 206 When the input exceeds the measurement range, "OVER RANGE" is displayed on the bottom right of the screen, and the main unit emits a warning beep. Reduce the sensitivity with the measurement range so that the input signal does not exceed the range. To silence the warning beep, disable the buzzer sound setting.
Page 207 9. Using Optional Modules – 9.8. 2ch Frequency Module (RA30-108) For the Pulse width mode and Duty cycle mode Tap the Pulse polarity key, and set the pulse polarity. <When the Pulse width mode is set> Positive: Measure the pulse width (Tp) from the rise to fall of the measurement pulse.
Page 208 Tap the Pulse polarity key, and set the pulse polarity. Positive: Detect from the rise to the fall of the measurement pulse, and increments the count value when the measurement pulse is confirmed. Measurement pulse Increment count value Negative: Detect from the fall to the rise of the measurement pulse, and increments the count value when the measurement pulse is confirmed.
Page 209 9. Using Optional Modules – 9.8. 2ch Frequency Module (RA30-108) For the Pulse integ. mode Tap the Auto reset key, and set the count value reset operation. OFF: Stop the count value at the range upper limit. Start: Reset the count value when recording starts and stop the count value at the range upper limit.
Page 210 Set the pulse average. The pulse average can be set in the Period mode, Frequency mode, Rotation speed mode, Pulse width mode, Duty cycle mode, Power freq. mode, and Freq. deviation mode. It is effective for eliminating variation in the input signal.
Page 211 Step 5. Set smoothing. Smoothing can be set in the Period mode, Frequency mode, Rotation speed mode, Pulse width mode, Duty cycle mode, Power freq. mode, and Freq. deviation mode. It converts a stepped waveform into a smooth waveform. <Smoothing process>...
Page 212 Set the display range and display position. See the description in "4.2.2 Set the input channels - Display Range and Display Position (Display Area)". Disp. range: The display width in the amplitude direction of the waveform display area on the waveform monitor Disp.
Page 213: Reference Materials
9.8.5. Reference Materials CAUTION Ensure that the voltage between each input and the chassis (GND) and between each channel does not exceed 300 V (DC + AC peak). Damage may be caused if the voltage is exceeded. Input cable The input connectors for CH1 and CH2 are insulated BNC connectors. Do not connect metallic BNC plugs, as they may damage the connectors or cause connection problems.
Page 214: 2Ch Acceleration Module (Ra30-109)
9.9.1. Overview This two channel acceleration module samples an acceleration signal at 16-bit 1 MS/s and performs A/D conversion. In addition to an acceleration sensor incorporating a preamp, it can use a charge converter to support a charge output type acceleration sensor.
Page 215: Measurement Setup
Step 2. Connect the sensor, set [Meas. mode] to Acceleration, and enable [Meas.] to display the input waveform on the monitor screen. Perform adjustment for the required signal waveform while viewing the waveform.
Page 216 9. Using Optional Modules – 9.9. 2ch Acceleration Module (RA30-109) Step 3. Set the type and sensitivity of the sensor to connect. Tap the Sensor key to open the sensor settings sub menu. (20) (20) (24) (21) (22) (25) (23) (23) <When [Preamp] is selected as the sensor>...
Page 217 <When using a charge output type acceleration sensor> When using a charge output type acceleration sensor, a charge converter is required. Follow the procedure below to configure the settings according to the sensor and charge converter to use. Use the...
Page 218 When the input exceeds the measurement range, "OVER RANGE" is displayed on the bottom right of the screen, and the main unit emits a warning beep. Reduce the sensitivity with the measurement range so that the input signal does not exceed the range. To silence the warning beep, disable the buzzer sound setting.
Page 219: Cables
Cables 9.9.4.1. Installing the Included Ferrite Core Open the ferrite core and clasp it around the BNC cable near the BNC connector on the module side. Close the ferrite core and secure both ends using commercially-available cable ties. BNC cable...
Page 220: Reference Materials
Reference Materials CAUTION Ensure that the voltage between each input and the chassis (GND) and between each channel does not exceed 42 V (DC + AC peak). Damage may be caused if the voltage is exceeded. Connecting the Acceleration Sensor When using an acceleration sensor incorporating a preamp, connect the sensor directly.
Page 221 When the amplitude of the acceleration is constant, the attenuation is -6 dB/oct for the velocity and -12 dB/oct for the displacement when at approximately 16 Hz.
Page 222: Remote Control Module (Ra30-112)
Carrier function for AC strain module Waveform confirmation output for confirming the voltage input module The remote function includes both remote input for control from an external device and remote output for performing synchronized operation with another RA3100 and this product acting as the master.
Page 223: Channel Setting
Select "Internal" or "External" as the carrier signal source for the AC strain module. (7) EXT.1: Enables/disables the state of this product set to output externally for system errors, printer errors, and overranges. Tap to display the EXT.1/EXT.2 setting dialog. (8) EXT.2: The same as EXT.1.
Page 224: Output Terminal For Waveform Confirmation
9.10.4. Output terminal for waveform confirmation A square wave is output from the output terminal of this module at 0 to 5 V and 1 kHz. This square wave signal can be connected to the voltage input module and waveform monitored to check module operation.
Page 225: Reference Materials
Connector for input signal: DF02R020NA3 (Japan Aviation Electronics Industry) The A series and B series are complementary. GND (B series) is the input common for A series signals. The plugs (manufacturer model numbers) corresponding to each input signal connector are indicated below.
Page 226 Connector for output signal: DF02R014NA3 (Japan Aviation Electronics Industry) The A series and B series are complementary. GND (B series) is the common for A series signals. The plugs (manufacturer model numbers) corresponding to each output signal connector are indicated below.
Page 227 42 V (DC + AC peak) CAUTION Ensure that the voltage between each input/output and the chassis (GND) does not exceed 42 V (DC+ACpeak). Damage may be caused if the voltage is exceeded. There is no insulation between the inputs/outputs.
Page 228 9. Using Optional Modules – 9.10. Remote Control Module (RA30-112) Connection method 5.1 For remote control Omniace RA3100 Remote control Terminal Host RA30-112 block controller Terminal block AX-PCX-10S20 Terminal block connection cable RA30-504 Omniace RA3100 Remote control Host RA30-112 controller Remote control cable (discrete wires) RA30-506 5.2 When connecting multiple RA3100...
Page 229 9. Using Optional Modules – 9.10. Remote Control Module (RA30-112) Equivalent circuit 6.1 IN The equivalent circuit schematic of START/STOP IN, MARK IN, FEED IN, PRINT IN, EXT SMPL IN, TRIG IN, and OSC IN. 6.2 OUT The equivalent circuit schematic of START/STOP OUT, MARK OUT, FEED OUT, PRINT OUT, EXT SMPL OUT, TRIG/EXT.1 OUT, OSC/EXT.2 OUT.
Page 230: Options
9. Using Optional Modules – 9.10. Remote Control Module (RA30-112) 9.10.7. Options Connection cables and terminal blocks The following cables and terminal blocks are provided for signal input and synchronized connection. Name (type) Shape/characteristics Terminal block For MDR 20 pole terminal block connection...
Page 231 9. Using Optional Modules – 9.10. Remote Control Module (RA30-112) RA30-112 Combination of AX-PCX-10S20 terminal connector block and RA30-505 cable Sig name Pin no. Pin no. START/STOP OUT (+) START/STOP OUT (-) 11/13 MARK OUT (+) MARK OUT (-) FEED OUT (+)
Page 232 9. Using Optional Modules – 9.10. Remote Control Module (RA30-112) 3.2 RA30-505 Cable Shield 3.3 RA30-506 Cable Shield 1WMPD4004444D...
Page 233: 4Ch Voltage Module (Ra30-113)
This four channel voltage input module samples a DC to 100 kHz signal at 16-bit 1 MS/s within the measurement range of ±2 V to ±500 V and can perform A/D conversion. It includes an analog filter for waveform observation. It is insulated between each channel and between input and output.
Page 234: Measurement Setup
When the input exceeds the measurement range, "OVER RANGE" is displayed on the bottom right of the screen, and the main unit emits a warning beep. Reduce the sensitivity with the measurement range so that the input signal does not exceed the range. To silence the warning beep, disable the buzzer sound setting.
Page 235 To perform zero cancellation, tap the Zero adjust key (17) after waiting for a warm-up period of 60 minutes. NOTE This function is for canceling internal offset and drift, and does not cancel the offset of the input signal. 1WMPD4004444D...
Page 236: Reference Materials
9. Using Optional Modules – 9.11. 4ch Voltage Module (RA30-113) 9.11.4. Reference Materials CAUTION Ensure that the voltage between each input and the chassis (GND) and between each channel does not exceed 300 V(DC+ACpeak). Damage may be caused if the voltage is exceeded. Input cable The input connectors for CH1 to CH4 are insulated BNC connectors.
Page 237: Appendix
10. Appendix – 10.1. Version Information Appendix This chapter provides additional explanations of various functions. 10.1. Version Information The versions handled on the management screen of this product are as indicated below. Name Overview (1) Windows OS The version of the embedded Windows 10 IoT operating system (2) Software The version of the RA3100 software (3) Main hardware...
Page 238: Sampling Data Format
Sampling period Analog input Time Playback the input waveform from sampling data If the input signal is too fast for the sampling period, the waveform reproducibility may drop and lead to the unexpected loss of pulses. Sampling data Sampling period Time Raising the sampling speed improves the waveform reproducibility but increases the recorded data.
Page 239: Sampling
10. Appendix – 10.3. Sampling 10.3. Sampling 10.3.1. Internal Sampling The sampling speed can be set for printer recording, SSD recording, and memory recording separately. The maximum sampling speed differs for each recording. For information on specifications, see "12.1.1 Main Unit Basic Specifications".
Page 240: Scale Conversion (Physical Quantity Conversion)
Method 1 Direct conversion with two point values The Y = AX + B formula is derived by specifying the input and output values a [Xa, Ya] and b [Xb, Yb] of the two points a and b.
Page 241: Wave Inversion
10. Appendix – 10.5. Wave Inversion 10.5. Wave Inversion For channels with wave inversion enabled, the waveform and values are inverted. The following functions are processed with inverted values. Y-T waveform X-Y waveform FFT analysis Digital view Cursor Thumbnail Search function Trigger 10.5.1.
Page 242: Fft Analysis
Each frequency component G of the linear spectrum is defined as G = R + jI (with R being the real number part and I being the imaginary number part). The frequency domain waveform of the input signal enables the amplitude and phase of each frequency component to be understood.
Page 243 The cross power spectrum derives the power between two signals. It is derived as this product of the linear spectrum Gy of the signal to compare and the complex conjugate Gx* of the linear spectrum Gx of the base signal.
Page 244 The transfer function indicates the frequency characteristics of the input and output of the transfer system. It is derived as the ratio of the cross power spectrum Gyx and input (reference) power spectrum Gxx. Transfer function = Hyx = Gyx/ Gxx...
Page 245: Avg Process
10. Appendix – 10.6. FFT Analysis 10.6.2. AVG process Averaging is not performed when set unless valid settings are specified for the analysis function. The enabled/disabled state of averaging for different analysis settings is indicated in the table. AVG method Analysis Y axis Frequency...
Page 246 10. Appendix – 10.6. FFT Analysis Exponentially Weighted Average The averaging process for the frequency component of the analysis results, which performs averaging by exponentially weighting each element to average. (Example) When the number of additions N = 3 E1 = Y1 E2 = (1 - α) E1 + αY2 E3 = (1 - α) E2 + αY3 α: Weighted average constant α...
Page 247: Units Of Analysis Results
10. Appendix – 10.6. FFT Analysis 10.6.3. Units of Analysis Results The units of the analysis results are indicated below. Analysis X axis Unit Time scale waveform Time Other analysis Frequency Analysis Y axis Unit Time scale waveform Amplitude Linear Real number part Lin-Rel Imaginary number part...
Page 248: Connecting To This Product Via A Web Browser
(3) Enable the Web server function of the RA3100. 10.7.3. Connection Method Start the Web browser on the computer and enter "http://" followed by the IP address of the RA3100. Example When the IP address of the RA3100 is 192.168.0.1 When connection with the RA3100 is complete, the [Remote] screen is displayed in the Web browser.
Page 249: Remote Screen
The [Remote] screen is displayed when connection is complete or when the Remote button is clicked. It enables you to perform remote operations on and view the screens of the RA3100. (1) Save: Saves an image file (in the PNG format) of the RA3100 screen to the computer.
Page 250: Info Screen
The [Info] screen is displayed when connection is complete or when the Info button is clicked. It enables you to check the main unit information of the RA3100 and configure the time and other settings. (1) Sync: Sync the time of the RA3100 with the time of the computer.
Page 251: Remotely Operating The Ra3100 From A Web Browser
10. Appendix – 10.7. Connecting to This Product via a Web Browser 10.7.6. Remotely Operating the RA3100 from a Web Browser You can remotely operate the RA3100 screen on a Web browser using mouse operations and the Ctrl, Shift, and Alt keys combined with the mouse wheel.
Page 252: Switching The Web Browser Display Language
10. Appendix – 10.7. Connecting to This Product via a Web Browser 10.7.7. Switching the Web Browser Display Language The display language of the [Remote] screen and [Info] screen automatically switches according to the language set in the Web browser. The supported languages are Japanese, English, Korean, and Traditional Chinese, and English is displayed if another language is set.
Page 253: Downloading The Data Of This Product Via Ftp
(3) Enable the FTP server function of the RA3100. 10.8.2. Download Method In this example, the Explorer of Windows 10 is used. (1) Start the Explorer on the computer and enter "ftp://" followed by the IP address of the RA3100. Example When the IP address of the RA3100 is 192.168.0.1...
Page 254: Transferring Data
(3) Enable the data transfer function of the RA3100. (4) Connect the PC to the RA3100 via TCP or UDP. (5) After connecting the RA3100 and the PC, the sampling data starts transferring according to the setting of [Transfer mode].
Page 255: Sampling Data
The data length differs measurement according to the data format of the sampling and the number data of channels with measurement enabled. For details, see "10.9.3 Measurement data block”.
Page 256: Measurement Data Block
Measurement data is two bytes of binary data. Measurement data can be divided into the analog channel data of a module such as an analog input module and the logic channel data of a logic module. The format of the measurement data also differs according to the data format.
Page 257 The measurement data of channels with measurement enabled is output in order. Analog channel data is ordered with the minimum value before the maximum value. Logic channel data is ordered with the level before the flag and has both CHA and CHB values if measurement is enabled for either CHA or CHB.
Page 258: Remote Control
Recording starts when the Low level signal is input to the START/STOP IN of the remote control module. However, depending on the state of this product, recording may not start when a Low level signal is input or recording may not start immediately and instead start after the processing of this product is complete.
Page 259: Starting/Stopping Pen Recording
Pen recording starts when the Low level signal is input to the PRINT IN of the remote control module. However, depending on the state of this product, pen recording may not start when a Low level signal is input or pen recording may not start immediately and instead start after the processing of this product is complete.
Page 260: Starting/Stopping Feeding
Feeding (idle feeding of recording paper) starts when the Low level signal is input to the FEED IN of the remote control module. However, depending on the state of this product, feeding may not start when a Low level signal is input or feeding may not start immediately and instead start after the processing of this product is complete.
Page 261: Relationship Between Ad Count Value And Measured Value
RA30-101/500 V range, the measured value Relationship between AD Count Value and equals (+12800/32000) × 500 [V] = +200 [V] Measured Value The calculation formulas for the measured values of each module and measurement target are indicated in the table below. Module Measurement target...
Page 262 10. Appendix – 10.11. Relationship between AD Count Value and Measured Value Module Measurement target AD count value Calculation formula Measured value = (AD count value + 32000) Pulse integ. -32000 to 18000 Measurement range RA30-108 50000 Voltage -32000 to +32000...
Page 263: Converting Ad Count Values To Physical Quantities
(Formula) Physical quantity (unit) = AD count ✕ gain + offset The unit, gain, and offset are obtained with the I09 command for reading the physical quantity calculation coefficient or the <ToPhysical> tag of the recorded information XML file. Item...
Page 264: Maintenance
Remaining Paper Monitor Operations <After replacing recording paper> <During use> <No paper remaining> Reset the remaining paper monitor after replacing the recording paper. Press and hold PAPER (remaining paper monitor) on the side menu to display the dialog box for resetting.
Page 265: Storing Recording Paper
When storing recording paper, remove it from the main unit and insert it in a plastic bag, or as-is if it is still in its original packaging, and then store it in a dark location with a temperature of 25°C or less and humidity of 70% RH or less.
Page 266: Backing Up Recorded Data
The SSD remaining capacity monitor (SSD) is displayed on the side menu of the monitor, and maintenance can be performed based on that display. For information on backing up recorded data and deleting it from the SSD, see “Recording” of "8.4.1 File Management ".
Page 267: Thermal Head Cleaning/Life
Foreign material or dust adhering to the platen roller may cause damage to the thermal head or may cause printing to become unclear and reduce the image quality. In this case, gently wipe the platen roller clean using gauze dampened with ethanol.
Page 268: Fan Replacement
11.8. Fan Replacement If the internal fan stops due to failure, the internal temperature of this product will rise and may cause damage to other devices inside this product. The state of the fan can be checked in on the [Maintenance] screen.
Page 269 11. Maintenance – 11.10. Troubleshooting and Inspection Symptom Possible cause Countermeasure Memory data is not saved Memory recording Cause a manual trigger using the TRIG key on because the trigger is not cannot be replayed. the operation panel. enabled. The recording mode is set to Disable the START trigger.
Page 270: Specifications
12. Specifications – 12.1. General Specifications Specifications 12.1. General Specifications 12.1.1. Main Unit Basic Specifications Item Specifications Number of module slots 9 slots Input block Analog input Maximum 36 channels Logic input Maximum 144 channels Internal SSD 256 GB Recording device Internal memory 4 GB Internal printer...
Page 271: General Specifications
Rated power frequency 50/60 Hz Allowed range of variation 47 to 63 Hz in power frequency Withstand voltage Between power and case 1500 V AC for 1 minute Power Insulation resistance Between power and case 100 MΩ or more at 500 VDC...
Page 272 The Measurement Category categorizes a testing or measurement circuit according to the type of main power circuit intended to be connected for testing or measurement, and differs according to the modules installed to this product. Use this product within the Measurement Category that meets the module specifications.
Page 273: Functional Specifications
(7) Start time + Interval (N times) (8) Start time + Start trigger + Interval (N times) (9) Window recording Recording to SSD, memory, or printer, and recording to various recording Recording device devices at the same time Y-T waveform...
Page 274: Ssd Recording
Synchronization clock: 250 kHz or less Records information related to the recorded data, such as the version of this Information data product, module configuration, channel settings, data format, and recording time. Recorded data Records input data and event data (trigger information, marks).
Page 275: Printer Recording
(to ensure that a trigger is not generated by noise, etc.) Filter time 0 to 100 s Available when the optional remote control module is installed. Analog input and logical input triggers (triggers from input channels) are collectively referred to as channel triggers. 1WMPD4004444D...
Page 276: Waveform Monitor Function
Display screen PLAYBACK Playback the memory, SSD, or printer recorded data Y-T waveform, X-Y waveform, FFT waveform Enables waveform display for an arbitrary analog signal and logic signal Enables 48 channel/sheet signal display Waveform type Y-T waveform Enables a maximum of four X-Y waveform sets to be...
Page 277: X-Y Waveform
Clear waveform time or all waveforms at once Refresh graph Redraws the X-Y waveform between cursors A and B on the Y-T waveform. Dot/line Renders the X-Y waveform with dots or lines Scale Input signal scale display of X axis and Y axis...
Page 278: Fft Analysis
Average number of additions 1 to 10 Identifies a maximum of 10 local maximums or global maximums from the Peak value display analysis results. Displays two cursors for each analysis and displays the X value and Y value Cursor of each cursor. Pinch in/out Enlarges/reduces the FFT analysis results with pinch in/pinch out operations.
Page 279: Setup/Record Management
Sets the channels to displayed in the thumbnails on the monitor and the compression ratio for the display from 1/10 to 1/100. Common Displays and configures a list of common settings set in modules and the input module installed in this product. Display items: Channel number, module type.
Page 280: Interface Specifications
Sets whether to output an XML format file of the recording info to XML file the recorded data. PC name Sets the name of the main unit using 15 characters or less. This name is used for identification purposes on the network and in recorded data. Language English Environment Time zone Sets the time zone (regional standard time).
Page 281: Communication Setup
Save screen Saves the screen of the RA3100 to the PC in the PNG format Time synchronization Synchronizes the date and time of the RA3100 with a PC File transfer File transfer of recording/image/configuration data Authentication Restricts login via a user name and password...
Page 282: Other Setup (Maintenance/Operation History/Version Management)
Returns the settings of this product to the factory defaults. Operation history display Displays the history of the past 100 operations. Displays the serial number and version of this product and the version Version management information of each module 1WMPD4004444D...
Page 283: Module Specifications
DC to 100 kHz (-3 dB to 1 dB) (with L.P.F. and A.A.F. disabled) Frequency characteristics AC coupling 0.3 Hz to 100 kHz (-3 dB to 1 dB) (with L.P.F. and A.A.F. disabled) Low-pass filter Cutoff frequency 3 Hz, 30 Hz, 300 Hz, 3 kHz, OFF (-1.6 dB ±1 dB) (L.P.F.)
Page 284: 4Ch Voltage Module (Ra30-102)
300 V (DC + AC peak) CAT II ground Withstand voltage AC 3 kV, 1 minute (between input terminals and chassis, between channels) Usage environment Temperature: 0 to +40 °C, humidity: 35 to 85 %RH or less (without condensation) Storage environment Temperature: -20 to +60 °C, humidity: 20 to 85 %RH or less (without condensation)
Page 285: 2Ch High Speed Voltage Module (Ra30-103)
300 V (DC + AC peak) CAT II ground Withstand voltage AC 3 kV, 1 minute (between channels and between channels and chassis) Usage environment Temperature: 0 to +40 °C, humidity: 35 to 85 %RH or less (without condensation) Storage environment Temperature: -20 to +60 °C, humidity: 20 to 85 %RH or less (without condensation)
Page 286: 2Ch Ac Strain Module (Ra30-104)
100 kS/s Auto balance function Cancel imbalance in the strain gauge bridge. Simple bridge check Enables bridge edge short circuits and some bridge edge and cable open circuits to be detected. Maximum rated voltage to 100 V (DC + AC peak)
Page 287: 16Ch Logic Module (Ra30-105)
Maximum rated voltage to 42 V (DC+ACpeak) ground Withstand voltage AC 300 V, 1 minute (between channels and between channels and chassis) Power output for options +5 V (±5 %) Usage environment Temperature: 0 to +40 °C, humidity: 35 to 85 %RH or less (without condensation) Storage environment Temperature: -20 to +60 °C, humidity: 20 to 85 %RH or less (without condensation)
Page 288: 2Ch Temperature Module (Ra30-106)
Number of input channels 2 ch Removable socket (front panel) Input connectors Temperature sensor connector coupling wire: 0.2 SQ to 1.5 SQ (AWG24 to AWG16) Unbalanced input (insulation between channels and between channels and Input format chassis) Input impedance 5 MΩ or higher...
Page 289 Maximum rated voltage to 300 V (DC + AC peak) ground Withstand voltage AC 3 kV, 1 minute (between channels and between channels and chassis) Usage environment Temperature: 0 to +40 °C, humidity: 35 to 85 %RH or less (without condensation) Storage environment Temperature: -20 to +60 °C, humidity: 20 to 85 %RH or less (without condensation)
Page 290: 2Ch High Voltage Module (Ra30-107)
250 ms ±10 % or less Low speed 1000 ms ±10 % or less All of the above are rise 0 % → 90 % of RANGE and fall 100 % → 10 % of RANGE Measurement range DC mode:...
Page 291 600 V (DC + AC peak) CAT III Withstand voltage AC 3 kV, 1 minute (between channels and between channels and chassis) Usage environment Temperature: 0 to +40 °C, humidity: 35 to 85 %RH or less (without condensation) Storage environment Temperature: -20 to +60 °C, humidity: 20 to 85 %RH or less (without condensation)
Page 292: 2Ch Frequency Module (Ra30-108)
CH2: Meas. mode, CH4: CH2 input volt channels Input connectors Insulated BNC Input format Unbalanced input (insulation between channels and between channels and chassis) Coupling AC/DC/GND Input impedance 1 MΩ ±1 % Measurement mode Period, Frequency, Rotation speed, Pulse width, Duty cycle, Power freq., Freq.
Page 293 12. Specifications – 12.3. Module Specifications Item Specifications Duty cycle mode Measurement 100 % (20 Hz), 100 % (200 Hz), 100 % (2 kHz), 100 % (20 kHz) range (RANGE) Measurement ±0.25 % (1 kHz) to ±5 % (20 kHz) of 100 % (20 kHz) RANGE probability ±5% ×...
Page 294 Automatically resets the measured data of the Pulse integ. mode. (Auto reset) The count is reset when recording starts (Start) and when the range upper limit is reached (Over). OFF, Start, Over, Start & Over can be selected. Integrated manual Manually resets the measured data of the Pulse integ.
Page 295: 2Ch Acceleration Module (Ra30-109)
Input connectors BNC (metallic) Input format Unbalanced input (insulation between channels and between channels and chassis) Measurement mode OFF, Acceleration, Velocity, Displacement Sensor supply power 4.2 mA ±5 %, 22.5 V ±5 % Measurement range All the values below are when using a sensor incorporating a preamp. When...
Page 296 Acceleration ±1% rdg probability Velocity ±2% rdg Displacement ±3% rdg All of the above values are at 23 °C ±5 °C, with an 80 Hz sine wave, and L.P.F. A.A.F. disabled Temperature ± (300 ppm of RANGE)/°C coefficient Frequency Acceleration 5 Hz to 20 kHz (-0.5 dB to +0.5 dB)
Page 297 Medium speed: 600 ms ±10 % or less Low speed: 2.4 s ±10 % or less All of the above are rise 0 % → 90 % of RANGE and fall 100 % → 10 % of RANGE, with the acceleration mode Measurement ±1% rdg (10 Hz to 1 kHz, at low speed)
Page 298: Remote Control Module (Ra30-112)
Function: Externally output external input control signal External output START/STOP and TRIG are the OR output with the external input signal and output signal from the RA3100 main unit START/STOP, MARK, FEED, PRINT, TRIG, EXT.1/EXT.2 (outputs the state of this...
Page 299 12. Specifications – 12.3. Module Specifications Maximum rated voltage 42 V (DC+ACpeak) to ground Usage environment Temperature: 0 to +40 °C, humidity: 35 to 85 %RH or less (without condensation) Storage environment Temperature: -20 to +60 °C, humidity: 20 to 85 %RH or less (without condensation) Dimensions Approx.
Page 300: 4Ch Voltage Module (Ra30-113)
300 V (DC + AC peak) CAT II to ground Withstand voltage AC 3 kV, 1 minute (between input terminals and chassis, between channels) Usage environment Temperature: 0 to +40 °C, humidity: 35 to 85 %RH or less (without condensation) Storage environment Temperature: -20 to +60 °C, humidity: 20 to 85 %RH or less (without condensation)
Page 301: Exterior
12. Specifications – 12.4. Exterior 12.4. Exterior 12.4.1. Main Unit Exterior 1WMPD4004444D...
Page 302: 2Ch Voltage Module (Ra30-101) Exterior
12. Specifications – 12.4. Exterior 12.4.2. 2ch Voltage Module (RA30-101) Exterior 1WMPD4004444D...
Page 303: 4Ch Voltage Module (Ra30-102) Exterior
12. Specifications – 12.4. Exterior 12.4.3. 4ch Voltage Module (RA30-102) Exterior 1WMPD4004444D...
Page 304: 2Ch High Speed Voltage Module (Ra30-103) Exterior
12. Specifications – 12.4. Exterior 12.4.4. 2ch High Speed Voltage Module (RA30-103) Exterior 1WMPD4004444D...
Page 305: 2Ch Ac Strain Module (Ra30-104) Exterior
12. Specifications – 12.4. Exterior 12.4.5. 2ch AC Strain Module (RA30-104) Exterior 1WMPD4004444D...
Page 306: 16Ch Logic Module (Ra30-105) Exterior
12. Specifications – 12.4. Exterior 12.4.6. 16ch Logic Module (RA30-105) Exterior 1WMPD4004444D...
Page 307: 2Ch Temperature Module (Ra30-106) Exterior
12. Specifications – 12.4. Exterior 12.4.7. 2ch Temperature Module (RA30-106) Exterior 1WMPD4004444D...
Page 308: 2Ch High Voltage Module (Ra30-107) Exterior
12. Specifications – 12.4. Exterior 12.4.8. 2ch High Voltage Module (RA30-107) Exterior 1WMPD4004444D...
Page 309: 2Ch Frequency Module (Ra30-108) Exterior
12. Specifications – 12.4. Exterior 12.4.9. 2ch Frequency Module (RA30-108) Exterior 1WMPD4004444D...
Page 310: 2Ch Acceleration Module (Ra30-109) Exterior
12. Specifications – 12.4. Exterior 12.4.10. 2ch Acceleration Module (RA30-109) Exterior 1WMPD4004444D...
Page 311: Remote Control Module (Ra30-112) Exterior
12. Specifications – 12.4. Exterior 12.4.11. Remote Control Module (RA30-112) Exterior 1WMPD4004444D...
Page 312: 4Ch Voltage Module (Ra30-113) Exterior
12. Specifications – 12.4. Exterior 12.4.12. 4ch Voltage Module (RA30-113) Exterior 1WMPD4004444D...
Page 313: Optional Parts
13. Optional Parts – 13.1. List of Cables Optional Parts 13.1. List of Cables Name (type) Shape/characteristics Remarks RA3100 main unit AC 125 V system AC power cable Japan, PSE, UL/CSA standard 1KO6165-200 United States Length 2 m Canada RA30-101 Insulated BNC RA30-102 Insulated BNC cable...
Page 314: List Of Probes/Clamp Meters
13. Optional Parts – 13.2. List of Probes/Clamp Meters Name (type) Shape/characteristics Remarks For remote control input Remote control cable RA30-105 (discrete wires) 20P - discrete wire RA30-112 RA30-506 Length 2 m Temperature sensor Top cable cover connector Bottom cable cover RA30-106 Two sets of cable ties RA30-555...
Page 315: Accessory
13. Optional Parts – 13.3. Accessory 13.3. Accessory Name (type) Name Shape Remarks Z-fold paper adapter RA30-551 Z-fold paper box Including RA12-301 RA30-552 Dedicated delivery box RA23-183 Carrying case 13.4. List of Spare Parts Model Name Rating Remarks Paper roll YPS106 Recording paper 219.5 mm x 30 m...
Page 316: Software License Information
The OFL allows the licensed fonts to be used, studied, modified and redistributed freely as long as they are not sold by themselves. The fonts, including any derivative works, can be bundled, embedded, redistributed and/or sold with any software provided that any reserved names are not used by derivative works.
Page 317 The Font Software, modified or unmodified, in part or in whole, must be distributed entirely under this license, and must not be distributed under any other license. The requirement for fonts to remain under this license does not apply to any document created using the Font Software.
Page 318 MEMO 1WMPD4004444D...
Page 319 Omniace RA3100 Instruction Manual 1WMPD4004444D 5th Edition...
Page 320 A&D Company, Limited 3-23-14 Higashi-Ikebukuro, Toshima-ku, Tokyo 170-0013, JAPAN Telephone: [81] (3) 5391-6132 Fax: [81] (3) 5391-1566 A&D ENGINEERING, INC. 47747 Warm Springs Blvd, Fremont, California 94539, U.S.A. Tel: [1] (800) 726-3364 Weighing Support:[1] (888) 726-5931 Inspection Support:[1] (855) 332-8815 A&D INSTRUMENTS LIMITED Unit 24/26 Blacklands Way, Abingdon Business Park, Abingdon, Oxfordshire OX14 1DY United Kingdom Telephone: [44] (1235) 550420...

AND Omniace RA3100 Instruction Manual

Quick Links

Need help?

Questions and answers

Related Manuals for AND Omniace RA3100

Summary of Contents for AND Omniace RA3100
