  • Page 1 CV_3 ETNA USER MANUAL...

  • Page 2: Installation

    INTRODUCTION: Etna is an advanced triple control analog multimode morphing filter, meticulously designed for precise and dynamic sound shaping. It allows for rapid or smooth transitions between diverse filter settings, known as snapshots. Each snapshot comprehensively defines all of the filter’s parameters, which can be adjusted either swiftly or gradually.
  • Page 3 INSTRUCTIONS Audio input filter 1 Stage LED´s Audio input filter 2 Digital control Freq 1 Audio input filter 3 Digital control Freq 2 FM input Digital control Freq 3 CV input Freq 1 Digital control Q for all CV_3 CV input Freq 2 Analog control Freq All CV input Freq 3 Edit, Length, Position LED...
  • Page 4 Filter Structure Etna comprises three analog multi-mode lters, including a low-pass lter with a 24 dB/octave (4-pole) slope, a band-pass lter, and a high-pass lter with a 12 dB/octave (2-pole) slope. The lter circuits deliver ultra-clean sound due to the low distortion of the SSI2164, combined with rail-to-rail op-amps to maximize the threshold without distorting the waveforms.
  • Page 5 Morphing thru the snapshots: The image is showing the digital controls: Each snapshot comprehensively defines all of the filter’s parameters, The LED ring indicates the snapshots where the settings of each filter are stored, which can be adjusted either swiftly or gradually. modified, and activated.
  • Page 6 Etna can be synchronized with an external clock by connecting a signal to the CLOCK input jack. It will advance to the next stage with each pulse, allowing you to send trigger patterns to play the snapshots. By holding the encoder for 3 seconds, you can divide the clock rate to enable slower morphing through the snapshots.
