Track Kit
RT1200 Trencher
Model No. 25462—Serial No. 315000001 and Up
Model No. 25462E—Serial No. 315000001 and Up
This product contains a chemical or chemicals known to the State of California to
Installation
Loose Parts
Use the chart below to verify that all parts have been shipped.
Procedure
1
2
3
© 2015—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
Proposition 65 Warning
cause cancer, birth defects, or reproductive harm.
Description
No parts required
Grease fitting (90° elbow)
Pipe
Coupler
Grease fitting
Kingpin
Bolt (socket-head)—M14—2.00 x 40
mm, Class 12.9
Frame-mount bracket (front left or rear
right)
Frame-mount bracket (front right or rear
left)
Bolt (M16—2.00 x 70 mm)
Jam nut (M16)
Locknut (M16)
Bolt (M14—2.00 x 30 mm, Class 10.9)
Bolt (M14—2.00 x 60 mm, Class 10.9)
Lock washer (M14)
Direction bracket
Bolt (M12—1.75 x 60 mm, Class 8.8)
Flat washer (M12)
Locknut (M12—1.75, Class 8.8)
Hex nut (M16—2.00, Class 8.8)
Register at www.Toro.com.
WARNING
CALIFORNIA
Qty.
–
4
4
4
4
4
4
2
2
8
8
8
8
8
16
4
8
16
8
4
Form No. 3378-106 Rev A
Installation Instructions
Use
Prepare the machine.
Install the bottom kingpin.
Install the frame-mount bracket.
Original Instructions (EN)
All Rights Reserved *3378-106* A
Printed in the USA
Advertisement
Related Manuals for Toro 25462
Summary of Contents for Toro 25462
- Page 1 Form No. 3378-106 Rev A Track Kit RT1200 Trencher Model No. 25462—Serial No. 315000001 and Up Model No. 25462E—Serial No. 315000001 and Up Installation Instructions WARNING CALIFORNIA Proposition 65 Warning This product contains a chemical or chemicals known to the State of California to cause cancer, birth defects, or reproductive harm.
- Page 2 Procedure Description Qty. Top mounting plate Bolt (M14—2.00 x 40 mm, Class 10.9) Jam nut (M14—2.00, Class 10.9) Bolt (M16—2.00 x 50 mm) Lock washer (M16) Install the top mounting bracket. Shim plate Bolt (M14—2.00 x 60 mm, Class 10.9) Flat washer (M14) Hex nut (M14—2.00, Class 10.9) –...
- Page 3 1. Install a 90° elbow grease fitting, a pipe, a coupler, and a grease fitting to the bottom kingpin (Figure g028884 Figure 1 1. Bolt and nut (2) 4. Bolts securing the bottom kingpin 2. Steering limiter 5. Record this measurement. g0291 10 Figure 2 3.
- Page 4 3. Loosely install the frame-mount bracket onto the hub using 2 bolts (M14—2.00 x 30 mm, Class 10.9) and 2 bolts (M14—2.00 x 60 mm, Class 10.9) up through the bottom kingpin and 4 lock washers as shown in Figure Installing the Frame-Mount Note: Apply high-strength, thread-locking compound Bracket...
- Page 5 Installing the Top Mounting Bracket Parts needed for this procedure: Top mounting plate Bolt (M14—2.00 x 40 mm, Class 10.9) Jam nut (M14—2.00, Class 10.9) Figure 5 Bolt (M16—2.00 x 50 mm) 1. Direction bracket 4. Flat washer—M12 (4) Lock washer (M16) 2.
- Page 6 Torquing the Fasteners No Parts Required Procedure Important: Perform this procedure on each hub. 1. Tighten all the hardware from the previous steps except for the direction bracket (step 6). • Torque the 2 bolts (M14—2.00 x 30 mm, Class 10.9) and 2 bolts (M14—2.00 x 60 mm, Class 10.9) that secure the frame-mount bracket (refer to step 3 Installing the Frame-Mount Bracket (page...
- Page 7 Note: Figure 8 Figure 9 show only the outer track adjusters; the inner track adjusters are not shown. Note: Ensure that the grease fittings on the chassis frame face outward. Figure 11 Nut—M16—2.00, Class 10.9 (3) not shown 1. Bolt—M16—2.0 x 50 mm, 5.
- Page 8 7. Secure the sprockets together using 6 sets of fasteners that consist of a bolt (M16—2.00 x 40 mm, Class 10.9), 2 washers, and a hex nut (M16—2.00, Class 10.9) each (Figure 14). Note: Torque the bolts and nuts to 255 to 311 N-m (188 to 230 ft-lb).
- Page 9 Checking and Adjusting the Aligning the Tracks Toe of the Tracks No Parts Required No Parts Required Procedure Procedure Important: Perform this procedure on each hub. Important: Perform this procedure on each hub. To determine whether the tracks are correctly aligned, start the engine, rotate the track at least 6 times, and check whether Note: Check to ensure that the centerlines the tracks on each the wheels remain centered between the teeth of the track...
- Page 10 3. Repeat this procedure until the wheels remain centered between the teeth of the track. Checking the Tension of the Tracks No Parts Required Procedure Important: Perform this procedure on each hub. Important: It is normal for the tracks to stretch the g028917 first time that you use them.
- Page 11 g028915 Figure 20 1. Gap—83 to 89 mm (3-1/4 2. Round bar to 3-1/2 inches) 5. Repeat this measurement 5 pitches ahead and 5 pitches after the location of the model/serial number plate. Note: Rotate the track so that all these positions are located between the 2 smaller wheels.
- Page 13 Notes:...
- Page 14 Notes:...
- Page 15 Notes:...
- Page 16 Countries Other than the United States or Canada Customers who have purchased Toro products exported from the United States or Canada should contact their Toro Distributor (Dealer) to obtain guarantee policies for your country, province, or state. If for any reason you are dissatisfied with your Distributor's service or have difficulty obtaining guarantee information, contact the Toro importer.
