- Page 1 Installation and Care Guide Cleansing Seat with Remote Control Français, page “Français-1” Español, pagina “Español-1” 1093479-2-B...
- Page 2 Use this product only for its intended purpose as described in the manual. Do not use attachments not recommended by Kohler Co. Never operate this product if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped into water.
-
Page 3: Tools And Materials
NOTICE: To avoid possible product malfunction, do not plug in the seat until instructed. NOTICE: Do not use an extension cord with this product. Kohler Co. 1093479-2-B... - Page 4 Unplug the seat and drain the seat if the functions of the seat will not be operated for an extended period of time. *Outside North America, this device may be known as a Residual Current Device (RCD). 1093479-2-B Kohler Co.
-
Page 5: Grounding Instructions
The temporary connection may not be permitted by local electrical codes. NOTICE: To avoid possible product malfunction, do not plug in the seat until instructed. Preferred Connection Connect the grounding plug into a grounded outlet that has the same configuration as the plug. Kohler Co. 1093479-2-B... - Page 6 NOT ground the unit. If there is any doubt whether the cover screw is grounded, have it checked by a qualified electrician or service professional. A temporary connection with a two-prong adapter may be used where local codes permit, provided the adapter is grounded. 1093479-2-B Kohler Co.
- Page 7 Do not plug in the seat until instructed to do so. *Outside North America, this device may be known as a Residual Current Device (RCD). Kohler Co. 1093479-2-B...
-
Page 8: Install The Mounting Plate
Do not fully tighten at this time. For All Other Installations Insert the bolts through the washers and into the mounting holes. Thread a nut onto each bolt. Do not fully tighten at this time. 1093479-2-B Kohler Co. -
Page 9: Install The Seat
To adjust the seat position, remove the seat by pressing in the release button and sliding the seat forward. Reposition the mounting plate as needed. Reinstall the seat. Repeat the adjustment procedure as needed until the seat is properly aligned. Kohler Co. 1093479-2-B... - Page 10 Install the Seat (cont.) Once the seat is positioned as desired, remove the seat and tighten the mounting plate. Reinstall the seat. 1093479-2-B Kohler Co.
-
Page 11: Connect The Water Supply
Connect the T-valve to the water inlet on the toilet tank. Connect the seat hose to the T-valve. Connect the supply hose to the T-valve and supply stop. Turn on the water supply. Check all connections for leaks and make any adjustments as needed. Kohler Co. 1093479-2-B... - Page 12 Install the caps to cover the screws. Position the remote control into the holder with the user preset icons facing up. Install Using Double-Sided Tape Remove the paper from one side of each of the tape squares. 1093479-2-B Kohler Co.
- Page 13 NOTE: Before mounting the remote control holder, verify that the rectangular indent is toward the bottom. Remove the paper from the tape squares. Press the remote control holder into place. Position the remote control into the holder with the user preset icons facing up. Kohler Co. 1093479-2-B...
-
Page 14: Installation Checkout
Plug the power cord into the electrical outlet. The seat will go through a power-up sequence. The seat will go silent when the power-up is complete. Proceed to the “Remote/Keypad Diagram” and “Operation” section to test the various seat functions. 1093479-2-B Kohler Co. - Page 15 FRONT REAR OSCILLATE PULSATE ENERGY-SAVE STOP POWER NOZZLE NOZZLE FORWARD LIGHT BACKWARD DEODORIZER Panel H20 TEMP. SEAT TEMP. AIR TEMP. AIR SPEED Remote Remote/Keypad Diagram Kohler Co. 1093479-2-B...
-
Page 16: Operation
M – Air Temp: This icon changes the heated air temperature from low (100°F, 37.7°C), to medium (122°F, 50°C), to high (140°F, 60°C), to OFF. N – Air Speed: This icon changes the heated air speed from low, to medium, to high. 1093479-2-B Kohler Co. -
Page 17: Care And Cleaning
• Do not allow cleaners to soak on surfaces. • Never use an abrasive material such as a brush or scouring pad to clean surfaces. For detailed cleaning information and products to consider, visit kohler.com/clean. To order Care & Cleaning information, call 1-800-456-4537. Kohler Co. 1093479-2-B... - Page 18 Press the “FRONT” icon on the panel to extend that spray wand forward for cleaning. Clean the spray wand with a soft-bristled brush. Press the “FRONT” icon on the panel again to retract the spray wand. Repeat above steps for the “REAR” spray wand. 1093479-2-B Kohler Co.
- Page 19 NOTE: The seat will contain water until drained. Refer to the ″Drain the Seat″ section. Unplug the seat from the electrical outlet. Disconnect the water supply hose from the T-valve. Push in the release button. Slide the seat forward to disengage the seat from the mounting plate. Kohler Co. 1093479-2-B...
-
Page 20: Clean The Screen
Reinstall the seat. IMPORTANT! Risk of product damage. Use care not to crossthread the connection. Reconnect the water supply hose to the seat. Turn on the water supply. Check all connections for leaks and make any adjustments as needed. 1093479-2-B Kohler Co. -
Page 21: Troubleshooting
Troubleshooting For service and installation issues and concerns, call 1-800-4-KOHLER. This troubleshooting guide is for general aid only. A Kohler Authorized Service Representative or qualified electrician should correct any electrical problems. For warranty service, contact your dealer or wholesale distributor. - Page 22 C. Circuit breaker has C. Reset the circuit been tripped. breaker and locate the problem. D. None of the above D. Contact a Kohler actions correct the Service symptom. Representative. Seat is loose. B. Bolts and nuts are B. Tighten the bolts and loose.
- Page 23 B. See activating the not detecting the seat information in the ″Operation″ user. section. Odor is not A. Deodorizer is off. A. Press the ″Deodorizer″ icon to removed. turn on. B. Some people are B. None more sensitive to odor. Kohler Co. 1093479-2-B...
- Page 24 Remote Control Symptoms Probable Causes Recommended Action The remote A. The batteries are A. Replace the batteries. control does getting old. not operate the seat. B. The batteries are B. Insert the batteries not placed correctly. correctly. 1093479-2-B Kohler Co.
-
Page 25: Warranty
United States of America, Canada and Mexico (″North America″). If a defect is found in normal residential use, Kohler Co. will, at its election, repair, provide a replacement part or product, or make appropriate adjustment where Kohler Co.’s inspection discloses any such defect.
