NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
OPERATING INSTRUCTIONS AND OWNER'S MANUAL
READ INSTRUCTIONS CAREFULLY: Read and follow all instructions. Place instructions in a safe
place for future reference. Do not allow anyone who has not read these instructions to assemble,
light, adjust or operate the heater.
WARNING: If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
— Service must be performed by a qualified service agency.
This is an unvented portable heater. It uses air (oxygen) from the area in which it is used. Adequate
combustion and ventilation air must be provided. Refer to page 3.
KEROSENE FORCED-AIR HEATER
www.mrheater.com
WWW.MRHEATER.COM/WARRANTY-REGISTRATION
WWW.MRHEATER.COM/WARRANTY-REGISTRATION
800-25 1-0001
Model #
MH140CKT
MH185CKT
MH220CKT
SCANNEZ LE CODE QR OU ALLEZ SUR
POUR ENREGISTRER VOS PRODUITS MR. HEATER®
ESCANEE EL CÓDIGO QR O VISITE
PARA REGISTRAR SUS PRODUCTOS MR. HEATER®
28920 REV B
