Best Barns the Meadowbrook Assembly Book

16' x 10'
Hide thumbs Also See for the Meadowbrook:

Advertisement

Quick Links

Download this manual
Best Barns
Assembly Book
Revised November 20, 2024
the Meadowbrook
16' x 10'
Manufactured by RBS Holdings, LLC
205 Arlington Drive
Greenville, PA 16125
This manual is copyrighted. Under the copyright laws, this manual
may not be copied, in whole or in part, without consent from
RBS Holdings, LLC
© Copyright 2022

Advertisement

loading
Need help?

Need help?

Do you have a question about the the Meadowbrook and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Best Barns the Meadowbrook

Summary of Contents for Best Barns the Meadowbrook

  • Page 1 Best Barns Assembly Book Revised November 20, 2024 the Meadowbrook 16' x 10' Manufactured by RBS Holdings, LLC 205 Arlington Drive Greenville, PA 16125 This manual is copyrighted. Under the copyright laws, this manual may not be copied, in whole or in part, without consent from RBS Holdings, LLC ©...
  • Page 2 Unpack all items & organize according to size and type. This will make items easier to find when instructed. Review the parts list on the back page. Should there be missing items or sub-par material contact Best Barns Customer Service. DO NOT discard any material including the pallet until your project is complete. Assembly: Review all instructions before you begin.
  • Page 3 Constructing Details for Deluxe Floor System Deluxe floors include 4x4 runners, standard floors do not Foundation size is 10'-0" x 15'-9". Check local building codes in your area, the construction may have to change. For a concrete slab, install sill sealer as a moisture barrier between the concrete and the wall plates.
  • Page 4 Step 1 Assemble 116" Bottom Cords 1. Locate (2) two 58" long 2x4s with an angle cut on one end. Butt the square ends together and secure together with (1) one 24" long 3/4" thick gusset to make a 116" long bottom cord. Use (12) twelve 6d common nails evenly spaced.
  • Page 5 Step 2A Assemble Trusses Continued OSB Gusset with 2x4 Block 8. Assemble another truss without a bottom cord. Locate OSB gussets with a 2x4 block attached to one side. 9. Attach this block/gusset to the bottom of each truss leg. Secure to leg with 6d common nails. 10.
  • Page 6 Step 3B Assemble Gable with Loft Doors Continued If you don't need loft access from the outside, attach loft door frames to the gable to create a decorative look and weather tight storage area. Tip: Slide gable over edge of work area so the 24" long 2x4 blocks are past the edge.
  • Page 7 Step 4 Install 2x3, Trim and Loft Doors If loft doors are to be decorative install door trim and frames over siding with 6d galv. nails. 1. Apply 47" long 2x3 boards to the front gable. Install flush with the top of the gable frame. Use 10d sinkers spaced 6"...
  • Page 8 Step 5 Assemble Gable without Loft Doors 1. Select (2) two 47" long 2x4s, (2) two 38" long 2x4s with angle cuts on both ends, (2) two 58" long 2x4s with angle cuts on one end and all necessary gussets. 2.
  • Page 9 Step 6 Install Gable Overhang & Trim 1. Apply 47" long 2x3 boards to the gable. Install boards flush with the top of the gable frame. Use 10d sinkers. 2. Install a 42-1/4" long 2x3 at the sides of the gable, flush with the frame. Board will extend below siding.
  • Page 10 Step 7A Assemble Front Walls Frames 1. Locate (2) two 65-1/2" long 2x4s. Cut each to a length of 36". Position boards together. Measure and indicate with 'X' marks, where the wall studs will be located. 2. Position (2) two 78-1/2" long 2x4 boards together. Measure and indicate with 'X' marks where the wall studs wil be located.
  • Page 11 Step 7B Assemble Front Walls Continued 6. Install a 70-1/2" long 2x6 as a tie plate across the top of the 78-1/2" wall frame. Install the 2x6 extending 3-1/2" beyond wall frame. Use 10d sinkers spaced 6" apart. 7. Locate (2) two 16" wide x 77-1/4" long siding panels. Cut these panels to a length of 75-3/4". 8.
  • Page 12 Step 8 Assemble End Wall Frames 1. Position (4) four 60" boards together and indicate with 'X' marks, where the wall studs will be located. Mark the ends that will butt together with the letters 'A' and 'B'. 60" Wall Plate 60"...
  • Page 13 Step 9 Apply Siding to End Wall 1. Locate a 36-3/4" x 77-1/4" siding panel with the 'tongue' edge. Install the siding panel on the left corner, with the cut edge flush with the end of the wall and flush with the top of the 2x4 tie plate.
  • Page 14 Step 11 Assemble Back Wall 1. Position 68-1/2", 48", and 65-1/2" long 2x4 boards together and mark where the wall studs will be located. Mark the ends that will butt together with the letters 'A', 'B' and 'C'. 68-1/2" Wall Plate 48"...
  • Page 15 Step 12 Set Lower Walls & Install Header Front and back walls set inside end walls. 1. Erect wall panels. IMPORTANT: Make sure walls are plum and square. Secure wall panels together at the corners. Use (4) four 10d sinkers per corner. Use 10d sinkers or, if erecting on a concrete slab, concrete anchor bolts (not included) spaced 24"...
  • Page 16 Step 13 Install Front Wall Tie Plates 1. Select (2) two 70-1/2" long and (1) one 48" long 2x6 boards. Install (1) one 70-1/2" long board over 78-1/2" wall panel. Use 10d sinkers. 2. Next install the last 70-1/2" long board and finish with the 48" long board. 48 Long 2x6 70-1/2"...

  • Page 17: Step 14 Install Trim

    Step 14 Install Trim 1. Locate (2) two siding panels that are 32" wide x 6" in height. Cut these panels to a height of 4-1/2". Install these siding panels over the door header. Siding will extend below header. 2. Install (2) two 1x4-72" boards along each side of the door opening, flush with the bottom edge of the siding.
  • Page 18 Step 15 Set Gables Decide which end you want to install gable without loft doors IMPORTANT: Do Not set gables until all the siding and trim are installed on walls. 1. Install the gable without loft doors on an end wall. The gable siding will extend over the 1x3 trim on the lower wall.
  • Page 19 Step 16 Layout for Truss Spacing 1. Layout the truss spacing starting from gable without loft doors. Measure from the inside face of the wood gusset when marking the location of the first truss. 2. Locate the truss hangers, there are left and right hangers. Select the right hangers. 3.
  • Page 20 Step 17 Install Trusses & Loft Floor 1. Starting from gable without loft doors install (3) three trusses with a bottom cord over the 'X' marks. Secure truss to metal hangers using 1-1/2" hanger nails. 2. Next install truss without a bottom cord. 3.
  • Page 21 Step 18 Install Roof Sheathing Install roof sheathing on the steep side of the roof. Use a straight edge to align the top of the sheathing with the top of the truss. See Detail 'B'. Make sure the trusses are plumb and the roof sheathing meets the center of the truss.
  • Page 22 Step 19 Install Doors & Hardware 1. Lay the left door with the trim facing up. The siding on the left door extends past the door trim. See detail below. 2. Install 5" hinges to the left side of the door frame. To position the hinge properly, hold the rectangular plate against the frame.

  • Page 23: Material List

    Install Shingles - not included in kit Install roof shingles per instructions on outside of wrapper. Building Tip: Install ridge vent in lieu of shingles caps. Ridge vent provides ideal ventilation, preventing heat or moisture build-up from damaging your building or its contents. Shingles Material Description Quantity...
  • Page 24 Material List Qty 2x4 Framing Size Qty 2x6 Framing Size Wall Plates 78-1/2" Tie Plates for Side Walls 70-1/2" Tie Plates for Side Walls 48" Wall Studs 72" Wall Plates 68-1/2" Qty OSB Loft & Roof Size Door Headers 67-1/2" Roof Sheathing 42"x80"...
