Homecraft 091080027 Quick Start Manual

Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

EN
Intended Uses
• To help increase independence when using the toilet, particularly by
compensating for impaired movement.
Assembly and Use
Standard Homecraft Stirling Toilet Frame
(091080027).
This toilet frame comes with the fixed-width frame assembled. For
height adjustment, see Adjusting the height. For final positioning, see
Positioning the seat and frame.
Width-Adjustable Homecraft Stirling Toilet Frame
(091080068) and Width Adjustable Toilet Frame Stirling With
Padded Arms (091080076).
1. The frame is shipped with the seat (labelled D in Figure 1) attached to the
cross tubes (B). Remove the seat from the cross tubes by pulling at the
front and back.
2. Use a thumb and forefinger to pry the pin-clips (C) from the cross tubes.
3. Lay one of the side frames (A) on the floor and position one of the cross
tubes over the extending rod.
4. Align the holes in the two parts and secure with a pin-clip. For a standard
width, use the holes in the extending tubes that are closer to the frame; for
a wider frame, use the holes that are farther from the frame.
5. Repeat with the second cross bar.
6. Lay the second frame on the floor and put the first frame assembly onto
it, lining up the cross tubes and the extending rods. Turn the frame so the
feet are up and secure the cross tubes.
7. Stand the frame on the floor and position the seat in the middle of the
cross tubes. Push it firmly into place.
Serious events experienced from using this product should be reported immediately to Performance Health and to the local Competent Authority.
70238 Is21 © Performance Health International Ltd. 2021
Stirling Toilet Frame
Symbols Glossary located at http://www.performancehealth.com/medical-device-glossary.
Please retain these instructions for future reference.
Homecraft™ is trademark of Performance Health International Ltd.
091080027
091080068
091080076
Adjusting the height
8. With the frame lying on one side, remove the pin-clips (F) and slide the
leg sleeves (E) to the desired height. Be sure all of the legs are adjusted to
the same height and replace the pin-clips.
Positioning the seat and frame
9. Raise the toilet seat that is attached to the toilet. The Homecraft Stirling
Toilet Seat should be positioned directly over the toilet bowl (see Figure 2).
Care and Cleaning
All parts can be wiped using a brush or cloth and a solution of mild
detergent or household disinfectant.
Cautions
• 091080027, 091080068 and 091080076: The toilet seat is
not to be used to support more than 190 kg / 420 lb. / 30
st.
• Before use, insure the toilet seat and frame are securely in
place before putting weight on them.
Description
Standard
Width Adjustable
Deluxe Version
1
