EN
Description
091325711
Toilet Frame Days Free Standing 091325711
091438191
Toilet Surround With Floor Fixing Adj Height
Introduction
The Homecraft 091325711 and 091438191 toilet frames are
manufactured from powder coated tubing with moulded plastic
arms and non-slip rubber grips. Both models are adjustable in
height.
Fitting Instructions
The 091325711 is a free standing model that is positioned around
the toilet bowl.
For greater stability the 091438191 model can be fixed to the floor
using standard woodscrews and/or rawl-plug fittings.
Height Adjustment
To adjust the height press the two buttons in. Push the leg in and
turn slightly.
Adjust the leg to the required position, then turn and relocate,
ensuring buttons are protruding through the holes.
Repeat the height adjustment procedure for all legs ensuring that
all four legs are adjusted to the same height.
Maintenance
The Homecraft toilet frames are designed for minimum
maintenance. They are manufactured from non-corroding material
and require the occasional wipe over with a soft cloth. Use general
purpose neutral detergent and warm water. Do not use harsh
abrasive materials.
To disinfect clean as above and wipe over with solution of one
thousand parts per million available chlorine disinfectant
(haztabs/precept), rinse and dry.
Periodically check for elongated or stressed adjustment holes.
Check for split, worn or loose ferrules. Check that all fastenings
are secured.
Specification
Model No. Width
Depth
091325711 590mm 460mm 695-850mm 160 Kg
091438191 590mm 460mm 695-850mm 160 Kg
Serious events experienced from using this product should be reported immediately to Performance Health and to the local Competent Authority.
These user instructions are available in large print, please contact Performance Health Customer Services for a copy.
Performance Health International Ltd.
Nunn Brook Road
Huthwaite, Sutton-in-Ashfield
Nottinghamshire, NG17 2HU, UK
Tel: +44 1623 448 706
www.performancehealth.co.uk
Performance Health France
13 rue André Pingat CS 10045
51 724 Reims Cedex France
71276 Is2 © Performance Health International Ltd. 2021
Adjustable Steel Toilet Surround
Height
Max. User Weight
Symbols Glossary located at http://www.performancehealth.com/medical-device-glossary.
Please retain these instructions for future reference.
Distributed in the United States By:
Performance Health Supply, LLC
W68 N158 Evergreen Blvd
Cedarburg, WI 53012, USA
+1800-323-5547
www.performancehealth.com
Distributed in Australia By:
Ausmedic Australia, Trading as
Performance Health ANZ
Unit 3, 3 Basalt Road
Pemulwuy NSW, 2145, Australia
1300 473 422
www.performhealth.com.au
Homecraft™ is trademark of Performance Health International Ltd.
Warranty Information
The Homecraft model no. 503 frames are
warranted for one year from date of purchase
due to faulty workmanship and materials. Please
contact your supplier/dealer should a fault occur.
The warranty does not extend to the
consequential costs resulting from fault
clearance, in particular freight and travel costs,
loss of earnings, expenses etc.
The manufacturer will not accept responsibility
for any damage or injury caused by misuse or
non observance of the instructions set out above.
160
25
Maximum
st
kg
user weight
Distribué en France par:
Performance Health France
13 rue André Pingat CS 10045
51 724 Reims Cedex France
00(33) 03 10 00 79 30
www.performancehealth.fr
Floor Fixing
Ext Leg
for Model
091438191
CEpartner4U
Esdoornlaan 13
3951 DB Maarn
The Netherlands
www.cepartner4u.com
1
