© 2025 Lennox Industries Inc.
Dallas, Texas USA
WARNING
This furnace is equipped with an ignition control
factory enabled for use with Lennox A2L refrigerant
systems.
Disabling
functionality on A2L system is prohibited by safety
codes. Refer to furnace installation instructions for
non-A2L and non-Lennox refrigerant system setup.
Contents
Unit Dimensions - inches (mm) ......................................2
Parts Arrangement..........................................................3
SL280DFNVK Gas Furnace ...........................................4
Shipping and Packing List ..............................................4
Safety .............................................................................4
Use of Furnace as a Construction Heaterl .....................5
General ...........................................................................5
Combustion, Dilution, Ventilation Air...............................5
Setting Equipment ........................................................10
Filters ............................................................................ 11
Duct System .................................................................12
Venting .........................................................................12
Gas Piping ....................................................................17
the
refrigerant
detection
INSTALLATION
INSTRUCTIONS
SL280DFNVK
DAVE LENNOX SIGNATURE
GAS FURNACE DOWNFLOW
AIR DISCHARGE
508563-01
01/2025
THIS MANUAL MUST BE LEFT WITH THE
HOMEOWNER FOR FUTURE REFERENCE
This is a safety alert symbol and should never be
ignored. When you see this symbol on labels or in man-
uals, be alert to the potential for personal injury or death.
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, personal
injury or loss of life. Installation and service must be
performed by a licensed professional HVAC installer (or
equivalent), service agency or the gas supplier.
A thermostat is not included and must be ordered
separately.
A communicating
communicating applications.
In
non-communicating
conventional thermostat may be used, as well as other
non-communicating thermostats.
In all cases, setup is critical to ensure proper system
operation.
Field
wiring
for
communicating applications is illustrated in diagrams,
which begin on Page 21.
Electrical .......................................................................19
Ignition Control .............................................................29
Blower Motor Performance ...........................................37
Low GWP Application ...................................................39
Unit Start-Up .................................................................42
Gas Pressure Measurement.........................................43
