Acer D626D+ User Manual page 16

5
Rear side (Type A)
1 2
3 2
3 13 2
# Description
1 Power socket
2 HDMI connector
3 HDMI connector
4
DC 5V output (service)
5 PC analog signal/HDTV/component
video input connector
6 RS232 connector
7 Kensington™ lock port
Note: Functions vary depending on model definition.
3 4 5 6 7
3 4 5 8
4 5 11 5
4 5 8
#
8
9
10
11
12
13
8 9 10
9
6 8 9 10
12
9 10 11 6
Description
Composite video input connector
Audio in connector
Audio out connector
Monitor loop-through output
connector (for VGA IN 1, VGA IN only)
3D SYNC connector
LAN (RJ45) connector
