Smart balcony solar kit

Advertisement

Quick Links

Smart Balcony Solar Kit
HMK1P-600D-FB
HMK1P-800D-FB
HMK1P-600D-FT420X2
HMK1P-800D-FT420X2
HMK1P-600D-FT440X2
HMK1P-800D-FT440X2
LUMENIA
USER MANUAL QR CODE
Naskenujte QR kód a
Scannen Sie den
stáhněte si tento
QR-Code, um diese
manuál Čeština
Anleitung auf Deutsch
herunterzuladen
NOTE
• Read this user guide carefully before installing as it contains important instructions for the installation process.
• When installing the product, you and/or your assigned technician should always ensure safe conditions. Avoid installation
in rain, wind, or adverse weather conditions. Check a reliable weather forecast before installing.
• Never install the product alone, but preferably seek help from qualified technicians, as the weight of the product exceeds
20 kg. If you seek the help of non-techies, make sure that the person helping is an adult. During installation, make sure
that there are no people, pets, or animals nearby. Cancel the process if there is something damaging underneath.
• After installation, regularly check the screws to make sure they have not loosened. Regularly check the overall stability of
the product (especially after adverse weather conditions). If instability is suspected, a technician must be called in
immediately.
• In instances of uncertainty, seek assistance from a qualified technician or reach out to our customer service for guidance.
You can find our local contact details visiting this web page:
Escanee el código QR
Scansioni il codice QR
para descargar este
riportato sotto per
manual en español
scaricare il manuale in
https://eur.nahui-newenergy.com/services.html
Digitalize o código QR
para descarregar este
manual em português
Italiano

Advertisement

loading
Need help?

Need help?

Do you have a question about the LUMENIA HMK1P-600D-FB and is the answer not in the manual?

Questions and answers

Summary of Contents for Haier LUMENIA HMK1P-600D-FB

  • Page 1 Smart Balcony Solar Kit HMK1P-600D-FB HMK1P-800D-FB HMK1P-600D-FT420X2 HMK1P-800D-FT420X2 HMK1P-600D-FT440X2 HMK1P-800D-FT440X2 LUMENIA USER MANUAL QR CODE Naskenujte QR kód a Scannen Sie den Escanee el código QR Scansioni il codice QR Digitalize o código QR stáhněte si tento QR-Code, um diese para descargar este riportato sotto per para descarregar este...
  • Page 2 V 2.2 EN Quick Installation Guide for Smart Balcony Solar Kit LUMENIA 1. Accessories Top Cover Solar panel Hook+Accessories Microinverter Bracket Hook+Accessories Cable+Strap+Rubber mat +Installation tools Pearl cotton Solar panel Lower cover Serial Designation Image Size Quantity Solar panel 1722 x 1134 x 30 mm 1×2 1135mm 4×2...
  • Page 3: Installation Instruction

    M6 screw M 6x20 2×2 M8 screw M 8 20 2×2 Serial (For Micro inverter) Designation Image Size Quantity 2×2 screw 10×2 screw Railing hook 2×2 Screws are included in the accessories Micro inverter 1 pair DC Cable AC Cable Strap 2×2 Installation tools...
  • Page 4 STEP 1.2 - Mounting the triangular bracket Use M8 screws to connect the triangular bracket.( connector) 6 times M8×20 with one gasket 27° 30° 32° 34° 36° 38° 41° 41° 38° 36° 34° 32° 30° 27° 1135...
  • Page 5 STEP 1.3 - Mounting the crossbar The crossbar gives the additional stability of the substructure and is usually used to mount the micro-inverter directly. Pretighten the M6 screws and slider, When doing so, observe the required cable lengths. Depending on your local requirements, you stability).
  • Page 6: Micro Inverter

    Micro inverter Follow the procedure 1.1-1.3 to install another set of brackets CAUTION Before installing the microinverter, record the information on the label on the microin- STEP 2. Connect the DC Cable with Micro Inverter Connect the PV panel with the micro inverter via the MC4 connector on the DC cable.
  • Page 7 STEP 3. Connect The AC Cable of The Micro Inverter Connect the AC cable to the micro inverter via male and female clamp CAUTION DO NOT CONNECT AC PLUG TO THE SOCKET BEFORE SETTING UP WIFI CONNECTION. STEP 4. Set up The Fixed Network Find an eight-digit string below the barcode on the sticker.
  • Page 8 Select your home WIFI SSID and click on OK Enter WIFI password and click on OK WiFi is connected. ADJUSTING POWER 600W AND 800W (Refer to local grid-connection regulations) If there is a change in the policy of the place where the product is used, or if the user's needs change, the output power needs to be changed, please make sure to disconnect AC and follow these steps.
  • Page 9 STEP 5. Mounting the railing hooks M6×20 with two gaskets Place the hook on the railing, adjust the bar diameter and lock the bolt at A. Connect the hook to the triangular bracket by screw at B. Hang the bracket on the railing (two persons are required to work on it). Attach the hooks to the railing with the screw at C.
  • Page 10 STEP 6. Insert the AC cable plug into the socket Data will start uploading to server after 10 minutes STEP 7. Micro Inverter Instruction Manual STEP 7.1 - Open Nahui Energy App Search for Nahui Energy in App Store or Google Play User can scan the QR code below for app download.
  • Page 11 STEP 7.2 - Login or Register Enter the information and check that you have read and agreed to the User Agreement and Privacy Policy,then you can enter the App. When registering, please select your region (country) correctly, and it cannot be changed after registration.
  • Page 12 STEP 7.3 - Home Management The App will default to creating a family, and you can also create a new one by yourself. STEP 7.4 - Add Member added account), and the other party can add it successfully after agreeing. This step is not required.
  • Page 13 STEP 7.5 - Add Device Click "Add Device" and scan the QR code (called "Connect the app") on the Micro inverter. to add the device to. refer to step 4 ) without operating within the app.
  • Page 14 STEP 7.6 - Finish setting It's all set! Enjoy your balcony solar renewable energy! STEP 7.7 - Data viewing 1. Click the icon of the inverter to view the real-time power of the inverter, the power generation data of the day and other information. 2.
  • Page 15 Micro inverter 268 x 250 x 42 mm DC Cable 4×2 COMMISSIONING AC Cable 1×2 CONNECT MICRO INVERTER TO THE ELECTRICAL UTILITY GRID ONLY AFTER RECEIVING PRIOR APPROVAL FROM THE UTILITY COMPANY. ENSURE THAT ALL AC AND DC WIRING IS CORRECT. ENSURE THAT NONE OF THE AC AND DC WIRES IS PINCHED OR DAMAGED.
  • Page 16: Packing List

    PACKING LIST Description Quantity Colour Unit PV Panels Black PIECE Haier microinverter Silver PIECE Mounting brackets Silver AC cable Black PIECE DC cable Red+Black PAIR Installation guide PIECE NOTE: Nominal Power of PV Panels and Max AC Power of microinverter depends on the specific...
