TTS Blue-Bot TacTile Reader User Manual page 5

Using the Tiles in the Horizontal (Landscape) Position:
Ensure the 'tts' symbols on the tiles are aligned (as shown above), to ensure the correct
orientation. This is especially important for the direction tiles, so the user knows which direction
they are inputting.
Using the Tiles in the Vertical (Portrait) Position:
Ensure the Blue-Bot images on the tiles are aligned (as shown above), to ensure the correct
orientation. This is especially important for the direction tiles, so the user knows which direction
they are inputting.
To Program:
1. Insert the tiles: Ensure that the tiles are placed in the desired order from the end of the
Tactile Reader marked with the 'tts' symbol (see picture below).
• Important Note: If the order is started from the end of the Tactile Reader where the
'SEND' and 'PAIRING' buttons are, Blue-Bot/Rugged Robot will perform the commands in
reverse order.
2. Press the green 'SEND' button (see picture below): If the 'SOUND' is on, three peeps will
sound, and Blue-Bot/Rugged Robot will perform the commands on the tiles in the given
order.
Aligned Blue-Bot
images
Aligned 'tts' symbols
