Summary of Contents for Ryobi R18PS1800CP
- Page 1 FRONT PAGE R18PS1800CP...
-
Page 2: Intended Use
■ Do not operate the product in explosive atmospheres, IMPORTANT! such as in the presence of flammable liquids, gases, or It is essential that you read the instructions in this manual dust. The product creates sparks that may ignite the dust before assembling, operating, and maintaining the or fumes. -
Page 3: Maintenance
■ Do not wire the product into an AC distribution circuit. ■ When transporting the product in a vehicle, secure it against movement or falling to prevent injury to persons ■ Do not hardwire the product into a circuit. or damage to the product. ■... -
Page 4: Symbols In This Manual
Note Isolated inverter Warning Indoor use only USING THE MOBILE APPLICATION Installing the RYOBI GENCONTROL application on your BLUETOOTH-enabled iOS or ANDROID device allows you to view and control many of the product’s functions from USB-C output your device. ■... -
Page 5: Lcd Screen Overview
LCD SCREEN OVERVIEW The LCD screen displays the status and condition of the product. 01:58 0000 INPUT WATTS CHARGING 0000 INPUT WATTS 1. Session runtime - indicates the current runtime of the product. 2. BLUETOOTH connection - indicates that BLUETOOTH connection is active. -
Page 6: Troubleshooting
BATTERY PORT LED FUNCTIONS LED indicator Battery pack Green Yellow Description status Power on Without Solid Ready to charge the battery pack battery pack Testing Hot battery Flashing When the battery pack reaches cooled pack temperature, the charger begins charge mode. - Page 7 The charger does not work. The battery pack temperature Make sure that the battery pack temperature is is outside of normal operating between 0 °C and 45 °C. range. The connection between the Reinstall the battery pack. If the problem persists, battery pack and inverter is not use another battery pack.
- Page 8 High temperature The product is nearing the Allow the product to cool down warning maximum high or minimum or warm up as needed to an HIGH TEMPERATURE low operating temperature. acceptable temperature, then press WARNING Low temperature the AC output button to continue PRESS RESET warning operation.
- Page 9 R18PS1800CP Operator's manual LED task light USB-C charging ports LED task light control button LCD panel LCD backlight control button USB-A charging ports BLUETOOTH pairing / Session runtime button USB-C input charging port AC output / reset button Main power / restart button...
- Page 10 NOTE: Properly align the battery packs Insert the battery packs into the battery ports on the right side of the product. with the battery port. Insert the battery packs into the battery ports on the left side of the product. Press and hold the power button for 3 seconds to power on the product.
- Page 11 Using the control Charging the Using the AC and p.12 p.14 p.15 p.xxx Title header panel battery packs DC outlets Title header p.xxx Connecting two Title header Storing the product Title header p.16 p.xxx p.17 p.xxx power inverters...
- Page 12 USING THE AC AND DC OUTLETS 1. Insert the battery packs into the battery ports. 2. Press and hold the main power button for 3 seconds. NOTE: The LCD panel turns on, and the USB charging ports and LED task light can be used.
- Page 13 4. Press and hold the AC output button for 3 seconds. 5. Open the AC outlet covers. 6. Connect the device to be powered to the AC outlet. Operation...
-
Page 14: Using The Control Panel
USING THE CONTROL PANEL 1. Insert the battery packs into the battery ports. 2. Press the LED task light button to turn on the LED task light. 3. Press the LCD backlight control button to: a. turn off the LCD backlight. b. -
Page 15: Charging The Battery Packs
CHARGING THE BATTERY PACKS 1. Insert the battery packs into the battery ports. 2. Connect one end of the USB-C cable to the charging adaptor. Connect the other end of the cable to the USB-C input charging port. WARNING: Make sure to connect the USB-C charging cable into the charging input port. - Page 16 CONNECTING POWER INVERTERS 1. Connect one end of the parallel kit cable to the parallel kit terminals of a power station inverter. Connect the other end of the cable to the parallel kit terminals of another power station inverter of the same model, or with other compatible power station inverters listed in this manual.
-
Page 17: Storing The Product
STORING THE PRODUCT 1. Press and hold the main power button for 3 seconds to power off the product. 2. Press the latches and remove the battery packs from the battery ports on the right side of the product. 3. Press the latches and remove the battery packs from the battery ports on the left side of the product. - Page 18 5. Store the product in a cool, dry, and well-ventilated place that is inaccessible to children. Keep the product away from corrosive agents, such as garden chemicals and de-icing salts. Do not store the product outdoors. Storage...
-
Page 19: Product Specifications
Charge rate 65 W Cordless power station inverter Charger input 220–240 V a.c., 50 Hz, 1.7 A Model R18PS1800CP Charger output 5 V d.c. / 3 A, Rated input voltage 18 V d.c. 9 V d.c. / 3 A, 12 V d.c. / 3 A, USB-C input 5/9/12/15/20 V d.c., 3 A... - Page 20 COMPATIBLE BATTERY PACKS AND POWER OUTPUT The working AC power output depends on the battery capacity and the number of battery packs installed in the product. Compatible No. of cells Battery pack Number of battery packs and power output battery packs for battery capacity R18BL13...
- Page 24 Unit C, 70 Business Parade South, Highbrook, Auckland 2013, New Zealand RYOBI is a trade mark of Ryobi Limited, and is used under license. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc., and any use of such marks by Techtronic Power Tools Technology Limited is under license.
