IR Illuminators 5000 Table of contents | en Table of contents Safety Installation Connection Connecting the IIR-50xx0 Connecting the NIR-50xx0 Setting up Troubleshooting Technical data Bosch Security Systems B.V. 2025-03 | V03 | DOC Installation manual...
Unless qualified, do not attempt to service a damaged device yourself. Refer all servicing to qualified service personnel. – Install in accordance with the manufacturer's instructions in accordance with applicable local codes. – Use only attachments/accessories specified by the manufacturer. 2025-03 | V03 | DOC Bosch Security Systems B.V. Installation manual...
Page 5
Dispose such equipment according to local laws and regulations, to allow their reuse and/or recycling. This will help in conserving resources, and in protecting human health and the environment. Bosch Security Systems B.V. 2025-03 | V03 | DOC Installation manual...
Ensure that the parts are mounted in the following order: – Socket head screw – Lock washer – Washer – Illuminator – Bracket Use the supplied socket wrench to secure the bracket on both sides of the illuminator. 2025-03 | V03 | DOC Bosch Security Systems B.V. Installation manual...
Page 7
Remove the top cover. Peel back the protective foil from the adhesive points. Attach the selected beam-angle filter with the label side up to the adhesive points. Bosch Security Systems B.V. 2025-03 | V03 | DOC Installation manual...
Page 8
| Installation IR Illuminators 5000 Click the top cover back into place. 2025-03 | V03 | DOC Bosch Security Systems B.V. Installation manual...
Page 9
IR Illuminators 5000 Installation | en Bosch Security Systems B.V. 2025-03 | V03 | DOC Installation manual...
Camera masters the illuminator To control illuminator switching from the camera: Turn the Photocell adjust control fully counterclockwise. Connect a relay output from the camera to wires 3 (- green) and 4 (+ blue). 2025-03 | V03 | DOC Bosch Security Systems B.V. Installation manual...
Put the protective sealing cap back in place and secure. Connecting the NIR-50xx0 Power To power the illuminator, connect a PoE power supply to the RJ45 connector of the illuminator. Bosch Security Systems B.V. 2025-03 | V03 | DOC Installation manual...
Mount and connect the illuminator as described above. Complete the following steps at night and view the results on a monitor. Adjust the pan of the illuminator to match the camera’s field of view. 2025-03 | V03 | DOC Bosch Security Systems B.V. Installation manual...
Page 13
– Slowly tilt the unit upwards until the furthest part of the required field of view is illuminated correctly on the monitor. Re-tighten the bolts. Bosch Security Systems B.V. 2025-03 | V03 | DOC Installation manual...
| Troubleshooting IR Illuminators 5000 Troubleshooting Recommended Bosch PSU for SR/MR illuminators: PSU-IIR-36 Recommended Bosch PSU for LR/XR illuminators: PSU-IIR-60 The following table is intended to help diagnose and resolve common issues with Infrared illuminators in security systems. Malfunction...
Page 15
If the voltage is inadequate, replace the Power Supply Unit (PSU) with a suitable one to stabilise the power source and resolve the pulsing LED issue. Bosch Security Systems B.V. 2025-03 | V03 | DOC Installation manual...
Page 16
We strongly recommend the use of regulated switch mode 24V DC PSUs for use with the illuminator range. In particular the Bosch PSU-IIR-35, PSU-IIR-60 and PSU-IIR-100. https://commerce.boschsecurity.com/gb/en/Power-Supply-Units-for-IR-Illuminators/ p/23863891851/ Due to variations in mains voltage, we would not recommend the use of AC supplies with illuminator products.
Adjustable IR intensity (10% to 100%) Day/night switch Photocell, sensitivity adjustable (20 lx to 70 lx) Beam angles 10°, 30°, 60°, and 95° Environmental Operation Temperature -50 °C to +50 °C (-58 °F to +122 °F) Range Protection IP66 Bosch Security Systems B.V. 2025-03 | V03 | DOC Installation manual...
Page 18
M6 socket-head wrench) Cable 3 m (9 ft) Dimensions 110 x 68 x 75 mm (4.33 x 2.68 x 2.95 in) (W x H x D) Bracket dimensions 110 x 125 x 35 mm (4.33 x 4.92 x 1.38 in) (W x H x D) Weight 750 g (1.6 lbs) Bracket weight 0.2 kg (0.44 lbs) 2025-03 | V03 | DOC Bosch Security Systems B.V. Installation manual...
Page 19
M6 socket-head wrench) Cable 3 m (9 ft) Dimensions 110 x 114 x 75 mm (4.33 x 4.49 x 2.95 in) (W x H x D) Bracket dimensions 110 x 125 x 35 mm (4.33 x 4.92 x 1.38 in) (W x H x D) Weight 1.06 kg (2.3 lbs) Bracket weight 0.2 kg (0.44 lbs) Bosch Security Systems B.V. 2025-03 | V03 | DOC Installation manual...
Page 20
M6 socket-head wrench) Cable 3 m (9 ft) Dimensions 110 x 161.5 x 75 mm (4.33 x 6.36 x 2.95 in) (W x H x D) Bracket dimensions 110 x 125 x 35 mm (4.33 x 4.92 x 1.38 in) (W x H x D) Weight 1.4 kg (3.1 lbs) Bracket weight 0.2 kg (0.44 lbs) 2025-03 | V03 | DOC Bosch Security Systems B.V. Installation manual...
Page 21
M6 socket-head wrench) Cable 3 m (9 ft) Dimensions 110 x 214 x 75 mm (4.33 x 8.43 x 2.95 in) (W x H x D) Bracket dimensions 110 x 125 x 35 mm (4.33 x 4.92 x 1.38 in) (W x H x D) Weight 1.84 kg (4.1 lbs) Bracket weight 0.2 kg (0.44 lbs) Bosch Security Systems B.V. 2025-03 | V03 | DOC Installation manual...
Page 22
M6 socket-head wrench) Cable 3 m (9 ft) Dimensions 110 x 114 x 75 mm (4.33 x 4.49 x 2.95 in) (W x H x D) Bracket dimensions 110 x 125 x 35 mm (4.33 x 4.92 x 1.38 in) (W x H x D) Weight 1.06 kg (2.3 lbs) Bracket weight 0.2 kg (0.44 lbs) 2025-03 | V03 | DOC Bosch Security Systems B.V. Installation manual...
