Predator G3620 FRU List

Category
MB Kit
Chassis
Bezel
CPU
109
Part Number
MB Kit aGoran_M3 Intel B75 uATX W/O 1394 LF
Hon Hai Chassis MicroATX HM105A with front
USB port (vertical) for Predator G3 Bezel BM350
w/o 3.5" HDD carrier (2011 New CI)
Hon Hai Chassis MicroATX HM105B with front
USB port (vertical) for Predator G3 Bezel BM351
w/i one 3.5" HDD carrier (2011 New CI)
Wistron(LY) Predator Bezel BM350 USB 4 port
(vertical) bezel for HM105A, w/o 3.5" HDD carrier
Wistron(LY) Predator Bezel BM351 USB 4 port
(vertical) bezel for HM105B, w/i one 3.5" HDD
carrier
"CPU Intel Core i7 2600 3.4G 8M 1333 95W D-2
LGA-1155, Sandy Bridge"
"Core i3-2120 (3.30G 3M DDR3 1333) , Q0 , 65W ,
Intel HD Graphics 2000"
"Pentium G850 (2.9G/3MB/DDR3 1333) , Q0 ,
65W , Intel HD Graphics "
Pentium Dual Core G630 (2.7G 3M 1066FSB)
Celeron G530 (2.4G 2M 1066FSB LGA1155)
Celeron G460 (1.7G 1.5M 1066FSB LGA1155)
Ivy Bridge E-0 6MB 4c LGA 3.1GHz STD 77W I5-
3450 (FLOOR) GT1 QS
Ivy Bridge E-0 6MB 4c LGA 3.3GHz STD 77W I5-
3550 (HIGH BIN) VPRO GT1 QS
Exploded
Acer P/N
Diagram Item
MB.SJQ0P.001 N/A
HS.13100.241 N/A
HS.13100.242
PZ.11900.226 N/A
PZ.11900.227
KC.26001.CI7 N/A
KC.21201.CI3
KC.85001.DEG
KC.63001.DEG
KC.53001.CDG
KC.G0001.460
KC.34501.CI5
KC.35501.CI5
Chapter 6
