- Page 1 Welcome Lightcloud High Bay Low-Voltage Microwave Sensor MVS50/LCB, MVS50B/LCB Low Bay Low-Voltage Microwave Sensor MVS20/LCB, MVS20B/LCB WE’RE HERE TO HELP: 1(844) LIGHTCLOUD 1(844) 544-4825...
-
Page 2: Product Specifications
Microwave (MVS) Sensor is a sensor with 12V AUX supply and intergrated with dual-techology motion detector and daylight sensor that can switch and dim both local and remote circuits. The Lightcloud Blue High Bay/Low Bay Low-Voltage Sensor can be quickly and easily installed on compatible LED xtures. -
Page 3: Setup And Installation
• Turn o the main power at the breaker panel or remove the fuse from the fuse box. Find a suitable location • Lightcloud Blue devices should be positioned within 60 ft. of each other. • Building materials such as brick, concrete and steel construction may require additional Lightcloud Blue devices to extend around an obstruction. - Page 4 Setup & Installation (Cont’d) OUTDOOR Add an additional Lightcloud Blue Device to extend network range < 18ft. <=60 ft. around corners < 18ft. <=60 ft. Lightcloud DRYWALL OR SIMILAR Blue APP Recommend <30ft (varies based on mobile device's BLE capability)
-
Page 5: Wiring Diagram
Setup & Installation (Cont’d) Wiring Diagram MVS Sensor The Lightcloud Blue Low-Voltage installs in compatible sensor ports using a 3-pogo pin connection. Black White +12V 12VDC input Pink GND 0/1-10V DIM Purple DIM+ 0/1-10V DIM+ GND/DIM- DIM+ LED+ LED- Install Luminaire Low-Voltage MVS Sensor is onlycompatible with select sensor-ready fxtures. - Page 6 Setup & Installation (Cont’d) Mount the Low-Voltage MVS Sensor to a compatible fxture. Unscrew the 1/2" knockout out with a screwdriver and screw on the Low-Voltage MVS Sensor. 1/2” knockout sensor Mount using the Right Angle Arm Support (RAAS): Connect the Low-Voltage MVS Sensor to the RAAS by turning clockwise.
-
Page 7: Restore To Factory Settings
Setup & Installation (Cont’d) Restore to Factory Settings To restore your Lightcloud Blue Low-Voltage MVS Sensor to factory settings, you can reset it using the following methods: Method 1: Delete from app If the sensor was previously paired, open the mobile app and access the device settings for the paired device. - Page 8 Controlling your Lightcloud Blue Device Confirm your devices are powered on. Download the Lightcloud Blue app from the Apple® App Store or Google® Play store. Launch the App and create an account. Tap the "add device" icon in the app to start connecting devices.
- Page 9 Sensor Coverage Ceiling Mounted Mounting Height(ft) 0.5-1.0M/S Mounting Height(m) Highest mounting height is: MVS20x/LCB: 6m/20ft, MVS50x/LCB: 15m/49ft This gure indicates the maximum distance at the highest mounting height with 100% sensitivity. Well Detected Area Possibly Detected Area...
- Page 10 FCC Information: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation.
-
Page 11: We're Here To Help
CAUTlON: Changes or modifcations to this equipment not expressly approved by RAB Lighting may void the user's authority to operate this equipment. WE’RE HERE TO HELP: 1 (844) LIGHTCLOUD 1 (844) 544-4825 support@lightcloud.com... - Page 12 Lightcloud Lightcloud Blue is a Bluetooth mesh wireless lighting control system that allows you to control RAB’s various compatible devices. With RAB’s patented Rapid Provisioning technology, devices can be quickly and easily commissioned for residential and large commercial applications using the Lightcloud Blue mobile app. Each...
