Summary of Contents for Lightcloud LCLCSENSE/M/EG/A
- Page 1 Welcome MVS Micro Sensor LCLCSENSE/M/EG/A WE’RE HERE TO HELP: 1(844) LIGHTCLOUD 1(844) 544-4825...
- Page 2 Hello The Lightcloud Blue MVS Micro Sensor is a dual-technology motion detector and daylight sensor that can switch and dim both local and remote circuits. The MVS Micro Sensor is compatible with Lightcloud Blue Controllers and fixtures. WE’RE HERE TO HELP:...
- Page 3 Specifications PART NUMBER OPERATING TEMPERATURE LCLCSENSE/M/EG/A -4°F to 113°F (-20°C to 45°C) SENSOR COVERAGE MOUNTING HEIGHT 8 to 12 ft. 26 ft. diameter at 9 ft. CONNECTOR INPUT RJ09 5VDC DIMENSIONS 1.30”W x 1.33”H x 2.64”D...
- Page 4 Setup & Installation The MVS Micro Sensor is only compatible with select sensor-ready fixtures. Visit www.rablighting.com to see the full compatibility list. Mount the MVS Micro Sensor with the screw/tape included. Example shown using RAB's EZPAN fixture. MVS Micro Sensor EZPAN...
- Page 5 Setup & Installation (Cont’d) Connect the MVS Micro Sensor to the Lightcloud Blue Controller. Lightcloud Blue Controller: Use the enclosed RJ09 adapter to connect the MVS Micro Sensor to the Controller. ADAPTER MVS MICRO SENSOR CONTROLLER Wire Female to Short, Wire...
- Page 6 Sensor Coverage (LCBS MVS) 9’ 13’ 7.5’ 0’ 7.5’ 13’ 20’ 7.5’ 0’ 40’ 7.5’ 20’...
- Page 7 Configuration All configuration of Lightcloud Blue products may be performed using the Lightcloud Blue mobile app. Learn more at www.rablighting.com 1(844) LIGHTCLOUD 1(844) 544-4825 ©2022 RAB LIGHTING Inc. Custom manufactured in China Pat. rablighting.com/ip...
