Key Fob
(VS-SKEY2-345)
Quick Reference (User Manual)
The Vivint Key Fob (SKEY2) works with any Vivint Smart Home system, letting users control
their system with the touch of a button. Combining style and convenience, the key fob
allows you to arm (Stay or Away) and disarm your system anywhere within transmission
range of the panel. Users can disarm their system as they pull up to their house or arm it
on their way out the door. The Vivint Key Fob is suitable for both commercial and
residential use as a burglar alarm device. A total of 20 key fobs can be added to a system
with a maximum of 4 in Secure Mode (see below).
The SKEY2 also provides added protection by letting you send an encrypted panic signal to
the panel when the first and third buttons are held down.
Programming Instructions
Use these instructions to add an SKEY2 device to the Vivint system and program its operating mode.
OPERATING MODE PROGRAMMING:
When programming an SKEY2 key fob in Secure Mode (IMPORTANT: up to 4 devices can be in Secure Mode),
it must be within 5 ft/1.5 m of the panel and kept there until the LED stops flashing (about 10-15 seconds).
• Open the SKEY2 device, insert the battery, and close the device tightly.
• Within 60 seconds of inserting the battery, press one of the buttons (described below) for 10 seconds.
• Disarm Button (1) — Legacy Mode (the LED blinks once to indicate successful mode selection)
• Stay Button (2) — Legacy Mode + GDR1 (the LED blinks twice to indicate this mode)
• Away Button (3) — Secure Mode (the LED blinks three times to indicate this mode)
Secure Mode should always be used if possible. Once the key fob is programmed in Secure Mode it cannot be
changed to either of the Legacy Modes (1 or 2).
IMPORTANT: If the panel is replaced when a key fob is using Secure Mode,
the device's operating mode must be reprogrammed with the new panel.
Button Functionality
Disarm: Press until the red LED illuminates to disarm the system.
Stay: Press until the red LED illuminates to arm in stay mode.
Away: Press until the red LED illuminates to arm in away mode.
Panic (Disarm + Away): Hold down both buttons until the red LED begins
blinking rapidly (for about 4 seconds) to send a panic signal.
Installer / User Test
Test each button's functionality by holding it down separately (for approximately 2 seconds) until the red LED
flashes. (IMPORTANT: If the panel is NOT in Test Mode, the signals will activate the actual designated event.)
Technical / Hardware Specifications
Vivint Part Number (P/N) V-SKEY2-345
Model Number (M/N)
Wireless Signal Range
Battery
Battery Life
Transmitter Frequency
Code Outputs
Supervisory Interval
Operating Temperature.
Limits
Relative Humidity
Standards Certifications & Listings
Conforms to
UL 1023
KF01
Conforms to
300 ft. (91.4 m), open air
UL 2610
Panasonic CR2032 (or
Certified to
equivalent lithium batt.)
ULC S304
3-5 years (normal usage)
345 MHz
FCC ID
Arm Away, Arm Stay,
IC
Disarm, Panic, Auxiliary
Not applicable
*For complete regulatory compliance
32° to 120°F (0° to 49°C)
information, go to: vivint.com/fcc.
5-95% Non-Condensing
4931 N 300 W Provo, UT 84604
Standard for Household Burglar-
Alarm System Units
Standard for Commercial Premises
Security Alarm Units and Systems
Standard for Control Units,
Accessories and Receiving Equip-
ment for Intrusion Alarm Systems
2AAAS-KF01
10941A-KF01
5021666
