OPERATION MANUAL
–
Advanced Color
Wired Remote Controller
78
˚F
MODEL
CIW04-H
78
ORIGINAL INSTRUCTIONS
A16382F8ED

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the airPoint Room 700 CIW04-H and is the answer not in the manual?

Questions and answers

Related Manuals for Hitachi airPoint Room 700 CIW04-H

Summary of Contents for Hitachi airPoint Room 700 CIW04-H

  • Page 1 – OPERATION MANUAL – Advanced Color Wired Remote Controller ˚F MODEL CIW04-H ORIGINAL INSTRUCTIONS A16382F8ED...

  • Page 2: Table Of Contents

    Table of Contents Table of Contents 1. Safety Summary ................................1 2. Setting Names and Functions ............................4 3. Operation Method ................................5 3.1 Basic Procedures ..............................5 3.2 Operation Mode (Cool, Heat, Dry, Auto and Fan) ....................6 3.3 Temperature Setting ..............................6 3.4 Fan Speed Setting ..............................7 3.5 Louver Swing Direction ............................8 3.6 Operation ................................9 3.7 IR Receiver ................................10...

  • Page 3: Safety Summary

    • Use only Johnson Controls-Hitachi Air Conditioning genuine replacement parts. Johnson Controls-Hitachi Air Conditioning will not assume any liability for injuries or damage caused by not • following steps outlined or described in this manual. Unauthorized modifications to Johnson Controls-Hitachi Air Conditioning products are prohibited as they: ○...

  • Page 4: Installation Precautions

    1. Safety Summary Take the following precautions to reduce the risk of property damage. Do not touch the main circuit board or electronic components in the controller or remote devices. • Make sure that dust and/or steam does not accumulate on the circuit board. •...

  • Page 5: Electrical Precautions

    When shielded cabling is applied, proper bonding and termination of the cable shield is required as per Johnson Controls-Hitachi Air Conditioning guidelines. Plenum and riser ratings for communication cables must be considered per application and local code requirements.

  • Page 6: Setting Names And Functions

    2. Setting Names and Functions 2. Setting Names and Functions The figure below shows all the functions for reference. The actual display during operation is different. Display Screen Room Name Conference Room Set Temperature Operation Mode Louver Direction Temp Fan Speed Louver Menu Cool...

  • Page 7: Operation Method

    3. Operation Method 3. Operation Method 3.1 Basic Procedures 1. Initialisation screen When power is supplied to the system, the screen below is displayed when the controller is establishing communication with the indoor unit. 2. Air Conditioner OFF When air conditioner is off, press " " or " " to switch between the settings below: "Temperature"...

  • Page 8: Operation Mode (Cool, Heat, Dry, Auto And Fan)

    3. Operation Method 3.2 Operation Mode (Cool, Heat, Dry, Auto and Fan) Heat mode is only available when the system is capable of both cooling and heating. The Heat icon is not displayed on cooling only systems. 1. Operation mode setting Step1.

  • Page 9: Fan Speed Setting

    3. Operation Method • Contact your Hitachi service agent for assistance with setting the "Automatic Reset of Setting Temperature" and "Temperature Range Restriction" functions."Temperature Range Restriction" functions. 3.4 Fan Speed Setting 1. This function is used to set fan speed.

  • Page 10: Louver Swing Direction

    3. Operation Method 3.5 Louver Swing Direction 1. This function is used to set the louver direction and is only applicable to indoor units that have an oscillating louver. Step1. Press " " (On/Off). Make sure that the air conditioner is ON. Press " " or " " and select "Louver". Step2.

  • Page 11: Operation

    3. Operation Method 3.6 Operation NOTES: • Once the temperature and Fan speed settings are set, the settings are stored and does not need to be reset. • To change the settings, refer to Page 6 and Page 7 . 3.6.1 Operation Start 1.

  • Page 12: Ir Receiver

    3. Operation Method 3.7 IR Receiver This product supports wireless remote control function and can receive signals from a wireless remote controller (model: CIR01, sold separately). Pointing the wireless remote controller to this product can control the temperature, operating mode, etc. As long as the "Config. next unit" of the wired remote controller is consistent with wireless remote controller, the functions listed in the table below can be achieved.

  • Page 13: Icon Description

    3. Operation Method 3.8 Icon Description The status of the remote controller is displayed on the operation screen. NOTES: • It may not be displayed depending on the type of outdoor unit or indoor unit you are using. If there are multiple status, the high priority icon is displayed first. •...
  • Page 14 (*1) : It depends on the settings of the remote controller. (*2) : The default setting is cooling: set temperature +4°F (+2.5°C), heating: set temperature -4°F -2.5°C). If you want to change the correction value for this setback operation, please contact your Hitachi service agent for assistance with this. A16382F8ED...

  • Page 15: Menu Operation

    4. Menu Operation 4. Menu Operation NOTE: • If " " is displayed and grayed out, these functions are not available and cannot be set. Press " " or " " at home screen to select "Menu". Menu (Mon) 16:30 Function Menu Screen Display Setting Service &...

  • Page 16: Function Menu Screen Display

    5. Function Menu Screen Display 5. Function Menu Screen Display Various function settings are shown in this chapter. For how to enter the Menu screen, please refer to "4. Menu Operation". NOTES: Some functions cannot be set depending on the type, configuration, and usage status of the indoor unit. •...

  • Page 17: Simple Timer Setting

    5. Function Menu Screen Display 5.1 Simple Timer Setting This function is used to start or stop the unit operation at the set time. The timer operation contents can be set from "Not Used", "Once", or "Everyday". NOTES: If "Once" on the timer operation setting is selected, the setting reverts automatically to "Not Used" after the •...

  • Page 18: Operation Schedule Setting

    5. Function Menu Screen Display 5.2 Operation Schedule Setting This function is used to automatically start or stop the unit operation at the set time. The temperature can also be set. Up to 5 schedules can be set for each day of the week. Operation Schedule (Mon) 16:30 Verify Operation Schedule...
  • Page 19 5. Function Menu Screen Display 5.2.1 Schedule Day and Time Setting NOTES: • Scheduled operation (stop) is not possible when the remote control is prohibited. When is displayed, scheduled operation (stop) is not available. • Refer to "6.1 Adjusting Date/Time" to set the date and time. •...
  • Page 20 5. Function Menu Screen Display 5.2.2 Schedule Turn ON/OFF Setting 1. Set schedule ON / OFF Step1. Select "Operation Schedule" on the "Function Menu" Function Menu (Mon) 16:30 screen and press "OK". Simple Timer Operation Schedule If the current time is not set, the "Adjusting Date/ •...
  • Page 21 5. Function Menu Screen Display 5.2.4 Reset the Setting 1. Reset the setting Step1. Select "Operation Schedule" on the "Function Menu" Function Menu (Mon) 16:30 screen and press "OK". Simple Timer Operation Schedule If the current time is not set, the "Adjusting Date/ •...

  • Page 22: Power Savings Setting

    5. Function Menu Screen Display 5.3 Power Savings Setting Item Description ① Reduce the heating and cooling capacity of the indoor unit. Capacity Control Set control mode and power savings level with its corresponding value. ② Interlock with indoor units of the same outdoor unit system and switch to FAN operation in sequence. Rotation Control Set control mode and fan mode time.
  • Page 23 5. Function Menu Screen Display 5.3.2 Power Savings ON/OFF Setting 1. Set the power savings ON/OFF Step1. Select "Power Savings Setting" on the "Function Menu" Function Menu (Mon) 16:30 screen and press "OK". Simple Timer Operation Schedule Power Savings Setting Night Quiet Operation Power Saving/Night Quiet Schedule Select...

  • Page 24: Night Quiet Operation

    5. Function Menu Screen Display 5.3.3 Power Savings Level Setting 1. Set the power savings level Function Menu (Mon) 16:30 Step1. Select "Power Savings Setting" on the "Function Menu" Simple Timer screen and press "OK". Operation Schedule Power Savings Setting Night Quiet Operation Power Saving/Night Quiet Schedule Select...

  • Page 25: Power Saving/Night Quiet Schedule Setting

    5. Function Menu Screen Display 5.5 Power Saving/Night Quiet Schedule Setting This function starts and stops power savings control and operation noise reduction control at the desired time. Up to 5 Power saving/night quiet schedules can be set for each day of the week. The power savings schedule uses the setting made in the Power Saving settings in the function menu(refer to "5.3 Power Savings Setting").
  • Page 26 5. Function Menu Screen Display 5.5.1 Schedule Day and Time Setting NOTE: • indicates that schedule control is not possible. Refer to "6.1 Adjusting Date/Time" to set the date and time. 1. Set the schedule day and time Function Menu (Mon) 16:30 Step1.
  • Page 27 5. Function Menu Screen Display 5.5.2 Schedule Turn ON/OFF Setting 1. Turn ON / OFF the schedule Step1. Select "Power Saving/Night Quiet Schedule" on the Function Menu (Mon) 16:30 "Function Menu" screen and press "OK". Simple Timer • If the sub remote controller or indoor unit does not Operation Schedule support power savings, the power saving schedule Power Savings Setting...

  • Page 28: Power Consumption Display

    5. Function Menu Screen Display 5.6 Power Consumption Display This function displays the power consumption of the outdoor unit compressor. The value of each displayed in Graph/List format is 1 day (24h (- every 2 hrs.)), 1 week (7 days), and 1 year (12 months).

  • Page 29: Autoboost Setting

    5. Function Menu Screen Display 5.7 Autoboost Setting The function is used to provide powerful cooling and heating for 30 minutes once the operation starts. This function is only available when the operation mode is Cool or Heat. Whenever the unit is turned on, the system operates in the Autoboost mode for 30 minutes. NOTES: •...

  • Page 30: Comfort Setting

    5. Function Menu Screen Display 5.8 Comfort Setting This function is used to control discharge or supply air temperature when in the cooling mode. NOTES: This function cannot be set if the indoor unit does not support this function. • •...

  • Page 31: Setback Setting

    5. Function Menu Screen Display 5.9 Setback Setting Setback function is designed to maintain a minimum level of comfort in a room when it is not occupied. Setback function is enabled or disabled at the function selection setting. The setback setting is available only when the setback mode is set as "Schedule"...
  • Page 32 5. Function Menu Screen Display 2. Setback manual setting This function is used to temporarily activate Setback operation. It is available only when Setback mode is set as Manual mode; this function is normally used to set a long vacation. The items cannot be set/modified if indoor unit does not support this function.

  • Page 33: Elevating Grille Setting

    5. Function Menu Screen Display 5.10 Elevating Grille Setting This function available on selected models that use a facia with an elevating grill and is used to raise and lower grille when the air filter and grille need to be cleaned. WARNING When the air inlet grille is set inside the air panel, ensure that the air inlet grille is horizontal and the wire is suspended tightly without loosening.

  • Page 34: Filter Reminder Reset Setting

    5. Function Menu Screen Display 5.11 Filter Reminder Reset Setting This function is used to turn off the filter reminder indication and to reset the time of use for the filter. 1. Reset the filter reminder time Function Menu (Mon) 16:30 Step1.

  • Page 35: Frostwash

    5. Function Menu Screen Display 5.12 FrostWash Frostwash is a function that freezes and frosts the heat exchanger inside the air conditioner, then rapidly melts accumulated frost to flush away dirt. This keeps the unit in a clean status and also helps prevent performance degradation due to dust clogs.
  • Page 36 5. Function Menu Screen Display • FrostWash Intervals (Page 35 ) You can set the total operating time of the indoor unit as below. When the total operating time reaches the set value, FrostWash is performed while Function 1 Auto-FrostWash the operation is stopped.
  • Page 37 5. Function Menu Screen Display Step3. Press " " or " " to select the setting item and press "OK". FrostWash Setting The item changes as follows: FrostWash Start "FrostWash Start" ↔ "Enable/Disable Auto-FrostWash" Enable/Disable Auto-FrostWash ↔ "Set FrostWash Intervals" ↔ "Auto-FrostWash Set FrostWash Intervals Schedule"...
  • Page 38 5. Function Menu Screen Display ③ Set Auto-FrostWash Schedule Step1. Press " " or " " to select "Auto-FrostWash Schedule" and FrostWash Setting press "OK". FrostWash Started • If the current time is not set, the time setting screen Enable/Disable Auto-FrostWash (Page 43 ) is automatically displayed.
  • Page 39 5. Function Menu Screen Display 5.12.4 Display in FrostWash In FrostWash, the following is usually displayed If the indoor or outdoor temperature does not in order. meet the conditions for FrostWash, the following is displayed. ① - 1 When the indoor unit is out of the ①...
  • Page 40 5. Function Menu Screen Display 5.12.5 FrostWash Operation History NOTES • If the current time is not set, the date will be "- -". • The start time is the time when FrostWash is being prepared. 1. FrostWash operation history Step1.

  • Page 41: Individual Louver Setting

    5. Function Menu Screen Display 5.13 Individual Louver Setting This function is to individually set the air direction of multiple air outlets on non-ducted ceiling cassette units. NOTES: This function is available when the indoor unit supports individual louver control. •...
  • Page 42 5. Function Menu Screen Display Step5. Press" " or " " to select the louver angle and press "OK". 00-00 →Return to Step3. The louver angle is changed as follows. Indv. Indv. Indv. Indv. Adjust air direction & louver angle. Indv.

  • Page 43: Louver Open/Close

    5. Function Menu Screen Display 5.14 Louver Open/Close This function is used to fully open louver for adjusting the horizontal (left or right) direction of the air flow. NOTES: • This function cannot be set when the air conditioner is ON. •...

  • Page 44: Humidity Setting

    5. Function Menu Screen Display 5.16 Humidity Setting This function is used to set the humidity setting of indoor unit from wired remote controller. NOTE: • Humidity Setting function is available only when the indoor unit with humidity function is connected. 1.

  • Page 45: Screen Display Setting

    6. Screen Display Setting 6. Screen Display Setting 1. Screen display setting Step1. Select "Screen Display Setting" on the "Menu" screen and Menu (Mon) 16:30 press "OK". Function Menu Screen Display Setting Service & Installation Contact Information Temp Cool Fan Speed Louver Menu Step2.
  • Page 46 6. Screen Display Setting Step3. Press " " or " " to select "yyyy/mm/dd/hh/mm". Adjusting Date/Time Press " " or " " to change the setting. 2020 Step4. After making all settings, If select " " and press "OK", the screen returns to Step2. If press"...

  • Page 47: Run Indicator Brightness

    6. Screen Display Setting 6.2 Run Indicator Brightness 1. Set run indicator brightness Step1. Select "Run Indicator Brightness" on the "Screen Display Screen Display Setting (Mon) 16:30 Adjusting Date/Time Setting" screen and press "OK". Run Indicator Brightness Display Adjustment Temperature Language Setting Select Back...
  • Page 48 6. Screen Display Setting 6.3.2 Backlight on 1. Set backlight on time Step1. Select "Display Adjustment" on the "Screen Display Screen Display Setting (Mon) 16:30 Adjusting Date/Time Setting" screen and press "OK". Run Indicator Brightness Display Adjustment Temperature Language Setting Select Back Step2.
  • Page 49 6. Screen Display Setting 6.3.4 Backlight dim(stop) 1. Set backlight off time Screen Display Setting (Mon) 16:30 Step1. Select "Display Adjustment" on the "Screen Display Adjusting Date/Time Setting" screen and press "OK". Run Indicator Brightness Display Adjustment Temperature Language Setting Select Back Step2.

  • Page 50: Temperature

    6. Screen Display Setting 6.4 Temperature Function Action Unit and Width Change temperature unit and width. Display of Thermistor Temperature Show/hide the thermistor temperature display on the home screen. 6.4.1 Temperature Unit and Width 1. Set temperature unit and width Step1.

  • Page 51: Language Setting

    6. Screen Display Setting 6.4.2 Display of Thermistor Temperature 1. Set thermistor temperature display Screen Display Setting (Mon) 16:30 Step1. Select "Temperature" on the "Screen Display Setting" Adjusting Date/Time Run Indicator Brightness screen and press "OK". Display Adjustment Temperature Language Setting Select Back Step2.

  • Page 52: Keypad Touch Sound

    7. Contact Information 6.6 Keypad Touch Sound This function is to change the touch sound on keypad. 1. Set keypad touch sound Screen Display Setting (Mon) 16:30 Keypad Touch Sound Step1. Select "Keypad Touch Sound" on the "Screen Display Setting" screen and press "OK". Select Back Step2.

  • Page 53: Hotel Mode Setting

    8. Hotel Mode Setting 8. Hotel Mode Setting When the advanced wired remote controller is set to hotel mode, the home screen and menu are changed. For how to set the hotel mode, refer to "Hotel Mode Setting" in the Installation Manual. •...

  • Page 54: Language

    8. Hotel Mode Setting Menu ③ (Mon) 16:30 ② Screen Display Setting ④ Main Reset Controller Setting ⑤ More Settings Contact Information Off Timer Fan Speed Louver Language Off Timer Menu ① ① Language Change to the desired language. ② Off Timer Turn off the air conditioner after the desired time.

  • Page 55: Reset Controller Setting

    9. In Alarm Condition 8.3 Reset Controller Setting 1. Reset controller setting Step1. Press " " or " " to select "Reset Controller Setting" in the Menu (Mon) 16:30 "Menu" screen and press "OK". Screen Display Setting Reset Controller Setting More Settings Contact Information Fan Speed Louver Language Off Timer...
