  • Page 1 MPG Series Motherboard MPG X870E CARBON WIFI User Guide...

  • Page 2: Table Of Contents

    Contents Quick Start ........................4 Specifications ........................17 Special Features ......................22 Package Contents ......................23 Back Panel Connectors ....................24 2.5Gbps LAN Port LED Status Table ............... 26 5Gbps LAN Port LED Status Table ................26 Audio Jacks Connection ..................27 Installing Antennas ....................29 Overview of Components ....................30 CPU Socket ......................
  • Page 3 EZ Digi-Debug LED ....................60 Boot Phases ......................60 EZ Digi-Debug LED Table ..................60 Installing OS, Drivers & MSI Center ................65 Installing Drivers with MSI Driver Utility Installer ..........66 UEFI BIOS ........................69 BIOS Setup ......................70 Entering BIOS Setup ....................71 Resetting BIOS ......................

  • Page 4: Quick Start

    Quick Start This Quick Start provides clear diagrams to help you install the motherboard. Video demonstrations are also available for some installations. Visit these videos by clicking the provided URL on your phone or tablet’ s web browser. Alternatively, you can scan the QR code to access the video directly.

  • Page 5: Safety Information

    Safety Information The components included in this package are prone to damage from electrostatic ● discharge (ESD). Please adhere to the following instructions to ensure successful computer assembly. Ensure that all components are securely connected. Loose connections may cause ● the computer to not recognize a component or fail to start.
  • Page 6 Case stand-off notification To prevent damage to the motherboard, any unnecessary mounting stand-off between the motherboard circuits and the computer case is prohibited. The Case standoff keep out zone signs will be marked on the backside of motherboard (as shown below) to serve as a warning to user.

  • Page 7: Installing A Processor

    Installing a Processor ⚽ https://msi.gm/SDBE5855 ●...
  • Page 8 ⚠ Important If you are installing the screw-type CPU heatsink, please follow the figure below to remove the retention module first and then install the heatsink.
  • Page 9 Installing DDR5 memory ⚽ https://msi.gm/S647FF99 ● DIMMA1 DIMMA2 DIMMA2 DIMMA2 DIMMB2 DIMMB1 DIMMB2...

  • Page 10: Connecting The Front Panel Header

    Connecting the Front Panel Header ⚽ https://msi.gm/S8EF7577 ● Power LED Power Switch JFP1 Reserved HDD LED Reset Switch JFP1 HDD LED - HDD LED HDD LED + POWER LED - POWER LED POWER LED +...

  • Page 11: Installing The Motherboard

    Installing the Motherboard ⚽ https://msi.gm/S4BA9046 ● Torque: 3 kgf·cm* *3 kgf·cm = 0.3 N·m = 2.6 lbf·in...

  • Page 12: Connecting The Power Connectors

    Connecting the Power Connectors ⚽ https://msi.gm/SD937E2C ● ATX_PWR1 CPU_PWR1~2 PCIE_PWR1...

  • Page 13: Installing Sata Drives

    Installing SATA Drives ⚽ https://msi.gm/S9369131 ●...

  • Page 14: Installing A Graphics Card

    Installing a Graphics Card ⚽ https://msi.gm/S6B36811 ●...

  • Page 15: Connecting Peripheral Devices

    Connecting Peripheral Devices...
  • Page 16 Power On...

  • Page 17: Specifications

    Supports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop ● Processors* Processor socket AM5 ● * Please go to www.msi.com to get the newest support status as new processors are released. Chipset AMD X870E Chipset 4x DDR5 memory slots*, supporting up to 256GB** ●...
  • Page 18 Continued from previous column 4x M.2 slots (Key M) ● M2_1 slot (From CPU) ● Supports up to PCIe 5.0 x4 (For Ryzen™ 9000/ 7000 ● Series processors) Supports up to PCIe 4.0 x4 (For Ryzen™ 8000 Series ● processors) Supports 2260/ 2280 storage devices ●...
  • Page 19 Continued from previous column Wi-Fi 7 The Wireless module is pre-installed in the M.2 (Key-E)slot ● Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz* (320MHz) ● up to 5.8Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax/ be Wi-Fi & Bluetooth® ● Supports Bluetooth®...
  • Page 20 Continued from previous column 1x 4-pin RGB LED connector ● 3x 3-pin A-RAINBOW V2 (ARGB Gen2) LED connectors LED Features ● 4x EZ Debug LED ● 1x EZ Digi-Debug LED ● 2x USB 10Gbps Type A ports (From X870E Chipset) ●...
  • Page 21 ● Drivers ● MSI Center ● Acrobat ● Adobe Creative Cloud ● Software AIDA64 Extreme - MSI Edition ● CPU-Z MSI GAMING ● MSI App Player(BlueStacks) ● Norton 360 ● Voicemod ● PCI_E1, PCI_E2 and M2_2 share the bandwidth. Please refer to PCIe configuration table...

  • Page 22: Special Features

    Special Features MSI Center Performance MSI AI Engine Core Boost ● ● Game Highlights VRM Power Design (VCore / SOC / ● ● MISC) Cooling Wizard ● Dual CPU Power Mystic Light ● ● Memory Boost Ambient Link ● ●...

  • Page 23: Package Contents

    There is an ISO file in the supplied USB drive. Please do not delete it accidentally. For ● more information on installing drivers, please refer to Installing OS, Drivers & MSI Center chapter. If any of the above items are damaged or missing, please contact your retailer.

  • Page 24: Back Panel Connectors

    Back Panel Connectors Item Description USB 10Gbps Type-A port (From X870E chipset) Flash BIOS port ● USB 10Gbps Type-A port (From X870E chipset) USB 10Gbps Type-A ports (From RTS5420) Flash BIOS button - Please refer to page 73 for details about updating BIOS with Flash BIOS button.
  • Page 25 Item Description 2.5Gbps LAN(RJ45) port 5Gbps LAN(RJ45) port Wi-Fi antenna connectors Line-out port Mic-in port HDMI™ port USB 40Gbps Type-C ports (From ASM4242) Supports DisplayPort over USB Type-C® ● USB 10Gbps Type C port (From CPU) USB 10Gbps Type A ports (From X870E Chipset) USB 10Gbps Type A port (From CPU) USB 10Gbps Type C port (From X870E Chipset) Optical S/PDIF Out connector...

  • Page 26: 2.5Gbps Lan Port Led Status Table

    2.5Gbps LAN Port LED Status Table Link/ Activity LED Speed LED Link/ Activity LED Speed LED Status Description Status Speed No link 10Mbps Yellow blinking slowly Linked Green 100Mbps/ 1Gbps Yellow blinking rapidly Data activity Orange 2.5Gbps 5Gbps LAN Port LED Status Table Speed LED Link/ Activity LED Link/ Activity LED...

  • Page 27: Audio Jacks Connection

    Audio Jacks Connection Audio jacks to headphone and microphone diagram Audio jacks to stereo speakers diagram AUDIO INPUT Audio jacks to 4-channel speakers diagram AUDIO INPUT Rear Front Front Panel...
  • Page 28 Audio jacks to 5.1-channel speakers diagram AUDIO INPUT Rear Front Center/ Subwoofer Front Panel Audio jacks to 7.1-channel speakers diagram AUDIO INPUT Rear Front Side Center/ Subwoofer Front Panel...

  • Page 29: Installing Antennas

    Installing Antennas 1. Combine the antenna with the base. 2. Connect two antenna cables tight to the Wi-Fi antenna connectors as shown. 3. Place the antenna as high as possible.

  • Page 30: Overview Of Components

    Overview of Components SYS_FAN2 JARGB_V2_3 ATX_PWR1 JAF_2 M2_1 JUSBC1 PCI_E1 M2_2 SATA▼P3▲P4 M2_3 SATA▼S1▲S2 JUSB1 M2_4 PCI_E2 JUSB2 JCI1 PCI_E3 JFP2...

  • Page 31: Cpu Socket

    CPU Socket The AM5 socket is a modern CPU socket designed for AMD processors. It is a key component in contemporary computing systems, providing the foundation for powerful and efficient CPUs. Installing the CPU to the AM5 socket The surface of the AM5 CPU has two notches and a golden triangle to assist in correctly lining up the CPU for motherboard placement.
  • Page 32 ● disconnect the power cord from the power outlet before installing or removing the CPU. Please retain the CPU protective cap after installing the processor. MSI will deal with ● Return Merchandise Authorization (RMA) requests if only the motherboard comes with the protective cap on the CPU socket.

  • Page 33: Ddr5 Dimm Slots

    DDR5 DIMM Slots The DDR5 DIMM slot is a dedicated connector designed to accommodate DDR5 (Double Data Rate 5) memory modules. It represents the latest standard in computer memory, providing enhanced data transfer speeds and efficiency. DIMMA1 DIMMB1 DIMMA2 DIMMB2 Channel A Channel B Memory module installation recommendation...
  • Page 34 It is recommended to use a more efficient memory cooling system for full DIMMs ● installation or overclocking. The stability and compatibility of installed memory module depend on installed CPU ● and devices when overclocking. Please refer to www.msi.com for more information on compatible memory. ●...

  • Page 35: Pci_E1~3: Pcie Expansion Slots

    PCI_E3: PCIe 4.0 x4 ⚠ Important If you install a large and heavy graphics card, you need to use a tool such as MSI ● Graphics Card Bolster to support its weight to prevent deformation of the slot. For a single PCIe x16 expansion card installation with optimum performance, using ●...
  • Page 36 Installing a graphics card into PCI_E1 slot 1. Ensure that the EZ PCIe Release Button is in the locked position. If it is unlocked, press the button to lock it. 2. Insert the graphics card into the PCIe slot.
  • Page 37 Removing a graphics card from PCI_E1 slot 1. Ensure that the EZ PCIe Release Button is in the unlocked position. If it is locked, press the button to unlock it. 2. Gently pull the graphics card out of the PCIe slot.

  • Page 38: M2_1~4: M.2 Slots (Key M)

    Install M.2 SSD with Screwless M.2 Shield Frozr heatsink. M2_1 ⚽ M2_2 M2_3 https://msi.gm/S7F5D000 ● M2_4 ⚠ Important If your M.2 SSD equips its own heatsink, please note the following: Remove the M.2 plate or rubber cube in the M.2 slot before installing M.2 SSD. Do not ●...
  • Page 39 Installing M.2 module into M2_1 slot 1. Press and hold the end button of Screwless M.2 Shield Frozr heatsink. 2. Slightly lift up the end part of Screwless M.2 Shield Frozr heatsink and move it forward to uninstall the heatsink.
  • Page 40 3. Remove the protective film from the M.2 thermal pads on the M.2 plate. 4. If you install 2260 SSD, remove the plate screw and install EZ M.2 Clip II in the slot by using the included EZ M.2 Clip II Remover. Skip this step if you install 2280 SSD. EZ M.2 Clip II Remover EZ M.2 Clip II Plate screw...
  • Page 41 7. Remove the protective films from the thermal pads under Screwless M.2 Shield Frozr heatsink. 8. Align the notches under Screwless M.2 Shield Frozr heatsink with the tenons, and then put the heatsink back in place. 9. Press the end side of Screwless M.2 Shield Frozr heatsink to lock it completely.
  • Page 42 Installing M.2 module into M2_2~M2_4 slots ⚠ Important Please remove all rubber cubes from the M.2 plates before installing the Screwless M.2 Shield Frozr heatsink. 1. Press and hold the end button of Screwless M.2 Shield Frozr heatsink. 2. Slightly lift up the end part of Screwless M.2 Shield Frozr heatsink and move it forward to uninstall the heatsink.
  • Page 43 3. Remove the protective film from the M.2 thermal pads on the M.2 plate. 4. If you install 2260 or 22110 SSD, please exchange EZ M.2 Clip II and the plate screw. Use the included EZ M.2 Clip II Remover to install EZ M.2 Clip II in the slot. Skip this step if you install 2280 SSD.
  • Page 44 M2_3 slot ● EZ M.2 Clip II Remover EZ M.2 Clip II Plate screw 5. Insert your M.2 SSD into the M.2 slot at a 30-degree angle. 6. Use the EZ M.2 Clip II to automatically lock and secure the SSD. 30º...
  • Page 45 7. Remove the protective films from the thermal pads under Screwless M.2 Shield Frozr heatsink. 8. Align the notches under Screwless M.2 Shield Frozr heatsink with the tenons, and then put the heatsink back in place. 9. Press the end side of Screwless M.2 Shield Frozr heatsink to lock it completely. Removing M.2 SSD using the EZ M.2 Clip II To remove M.2 SSD from the EZ M.2 Clip II, gently push the spring head on the top of the EZ M.2 Clip II outward while simultaneously pulling the M.2 SSD out.

  • Page 46: Sata_S1_S2, Sata_P3_P4: Sata 6Gb/S Connectors

    SATA_S1_S2, SATA_P3_P4: SATA 6Gb/s Connectors These connectors are SATA 6Gb/s interface ports. Each connector can connect to one SATA device. SATA_P4 SATA_P3 SATA_S2 SATA_S1 ⚠ Important Please do not fold the SATA cable at a 90-degree angle. Data loss may result during ●...

  • Page 47: Jfp1, Jfp2: Front Panel Connectors

    JFP1, JFP2: Front Panel Connectors The JFP1 connector controls the power on, power reset, and the LEDs on your PC case/ chassis. Power Switch/ Reset Switch headers allow you to connect power button/ reset button. Power LED header connects to LED light on the PC case, and HDD LED header indicates the activity of the hard disk.

  • Page 48: Cpu_Pwr1~2, Atx_Pwr1, Pcie_Pwr1: Power Connectors

    CPU_PWR1~2, ATX_PWR1, PCIE_PWR1: Power Connectors These power connectors allow you to connect an ATX power supply. CPU_PWR1~2 Signal Name Signal Name Ground Ground Ground Ground +12V +12V +12V +12V ATX_PWR1 Signal Name Signal Name +3.3V +3.3V Ground Ground CPU_PWR1~2 Ground PWR OK 5VSB +12V...

  • Page 49: Jci1: Chassis Intrusion Connector

    JCI1: Chassis Intrusion Connector This connector allows you to connect the chassis intrusion switch cable. Normal Trigger the chassis (default) intrusion event Using chassis intrusion detector 1. Connect the JCI1 connector to the chassis intrusion switch/ sensor on the chassis. 2.

  • Page 50: Jusbc1: Usb 20Gbps Type-C Front Panel Connectors

    JUSBC1: USB 20Gbps Type-C Front Panel Connectors This USB connector allows you to connect to the USB Type-C® port on the front panel and supports data transfer speeds of up to 20Gbps. It features a user-friendly design that ensures proper orientation when connecting the cable. USB Type-C Cable JUSBC1 USB Type-C port on...

  • Page 51: Jusb3~4: Usb 2.0 Connectors

    Important Note that the VCC and Ground pins must be connected correctly to avoid possible ● damage. In order to recharge your iPad, iPhone and iPod through USB ports, please install MSI ● Center utility. T_SEN1: Thermal Sensor Connector This connector allows you to connect the thermistor cable and use it to monitor the temperature of the detection point.

  • Page 52: Joc_Fs1: Safe Boot Jumper

    JOC_FS1: Safe Boot Jumper This jumper is used for Safe Boot. When this jumper is enabled, the system will boot with default settings and lower PCIe (from CPU) mode. Normal (default) Enabled Boot with the saved Apply the BIOS default BIOS settings.

  • Page 53: Cpu_Fan1, Pump_Sys1, Sys_Fan1~5: Fan Connectors

    CPU_FAN1, PUMP_SYS1, SYS_FAN1~5: Fan Connectors Fan connectors can be divided into two categories: PWM Mode and DC Mode. PWM Mode fan connectors provide a constant 12V output and adjust fan speed with a speed control signal. DC Mode fan connectors control fan speed by changing voltage. Please refer to the following specification table for the fan connector mode of your motherboard.

  • Page 54: Jrgb1: Rgb Led Connector

    (12V/G/R/B) with the maximum power rating of 3A (12V). Always turn off the power supply and unplug the power cord from the power outlet ● before installing or removing the RGB LED strip. Please use MSI’ s software to control the extended LED strip. ●...

  • Page 55: Jargb_V2_1~3: A-Rainbow V2 (Argb Gen2) Led Connectors

    JARGB_V2_1~3: A-RAINBOW V2 (ARGB Gen2) LED connectors The JARGB_V2 connectors allow you to connect the ARGB Gen2 and the ARGB-based LED strips. The JARGB_V2 connector supports up to 240 individually addressable RGB LEDs with maximum power rating of 3A (5V). Signal Name Signal Name Data...
  • Page 56 Always turn off the power supply and unplug the power cord from the power outlet ● before installing or removing the addressable RGB LED strip. Please use MSI’ s software to control the extended LED strip. ●...

  • Page 57: Jaf_2: Ez Conn-Header V2

    JAF_2: EZ Conn-Header V2 This header allows you to connect the ARGB Gen1 and Gen2 LED strips, fans and USB 2.0 devices. It can also be used to connect MPG EZ120 ARGB fans. Signal Name Signal Name Ground DATA Sense Ground Speed Ground...
  • Page 58 JAF_2 header is compatible with JAF_1 header since pins 1 to 7 carry the same ● signals. MPG EZ120 ARGB can be connected to the JAF_2 header. For more information on how to install MPG EZ120 ARGB, please refer to https://msi. ● gm/S5035E56.

  • Page 59: Onboard Leds

    Onboard LEDs EZ Debug LED These LEDs indicate the debug status of the motherboard. LED Color Status CPU is not detected or fail Yellow DRAM is not detected or fail White GPU is not detected or fail Green Booting device is not detected or fail JPWRLED1: LED power input This connector is used by retailers to demonstrate the onboard LED lights.

  • Page 60: Ez Digi-Debug Led

    EZ Digi-Debug LED The EZ Digi-Debug LED displays progress and error codes during and after POST. Refer to the EZ Digi-Debug LED table for details. Hexadecimal Character Table Hexadecimal LED display Hexadecimal LED display Boot Phases Security (SEC) – initial low-level initialization Pre-EFI Initialization (PEI) –...
  • Page 61 Pre-memory CPU initialization is started 12 - 14 Pre-memory CPU initialization (CPU module specific) Pre-memory System Agent initialization is started 16 - 18 Pre-Memory System Agent initialization (System Agent module specific) Pre-memory PCH initialization is started Pre-memory PCH initialization (PCH module specific) 1A - 1C Memory initialization.
  • Page 62 6B - 6F System Agent DXE initialization (System Agent module specific) PCH DXE initialization is started PCH DXE SMM initialization is started PCH devices initialization 73 - 77 PCH DXE Initialization (PCH module specific) ACPI module initialization CSM initialization 7A - 7F Reserved for future AMI DXE codes Boot Device Selection (BDS) phase is started Driver connecting is started...
  • Page 63 Legacy Boot event Exit Boot Services event Runtime Set Virtual Address MAP Begin Runtime Set Virtual Address MAP End Legacy Option ROM Initialization System Reset USB hot plug PCI bus hot plug Clean-up of NVRAM Configuration Reset (reset of NVRAM settings) B8 - BF Reserved for future AMI codes DXE Error Codes...
  • Page 64 S3 Resume PPI not Found S3 Resume Boot Script Error S3 OS Wake Error EC - EF Reserved for future AMI error codes Recovery Progress Codes Recovery condition triggered by firmware (Auto recovery) Recovery condition triggered by user (Forced recovery) Recovery process started Recovery firmware image is found Recovery firmware image is loaded...

  • Page 65: Installing Os, Drivers & Msi Center

    Installing OS, Drivers & MSI Center Please download and update the latest utilities and drivers at www.msi.com Installing Windows 11 1. Power on the computer. 2. Insert the Windows 11 installation disc/ USB into your computer. 3. Press the Restart button on the computer case.

  • Page 66: Installing Drivers With Msi Driver Utility Installer

    2. Select Start > Settings > Windows Update, and then select Check for updates. 3. MSI Driver Utility Installer will pop up automatically. 4. Select the I have read and agree to the MSI Terms of Use check box, and then click Next.
  • Page 67 5. Check the Select All checkbox in the lower-left corner and click Install to install MSI Center and drivers. The installation progress will be shown at the bottom. 6. Once the progress has completed, click Finish.
  • Page 68 MSI Center is an application that helps you easily optimize game settings and smoothly use content creation softwares. It also allows you to control and synchronize LED light effects on PCs and other MSI products. With MSI Center, you can customize ideal modes, monitor system performance, and adjust fan speed.

  • Page 69: Uefi Bios

    UEFI has many new functions and advantages that traditional BIOS cannot achieve, and it will completely replace BIOS in the future. The MSI UEFI BIOS uses UEFI as the default boot mode to take full advantage of the new chipset’ s capabilities.

  • Page 70: Bios Setup

    ● have. BIOS User Guide If you’ d like to know more instructions on setting up the BIOS, please refer to https://msi.gm/S53FE767 or scan the QR code to access. ⚠ Important The appearance of the BIOS user guide may differ based on your motherboard model.

  • Page 71: Entering Bios Setup

    Entering BIOS Setup Press Delete key, when the Press DEL key to enter Setup Menu, F11 to enter Boot Menu message appears on the screen during the boot process. Function key +/ -: Increase / decrease the value Enter: Select the item ESC: Exit Tab:...

  • Page 72: Resetting Bios

    ● Please follow the steps below to update BIOS: 1. Download the latest BIOS file from the MSI website that matches your motherboard model, and save it to the USB flash drive. 2. If your motherboard has a Multi-BIOS switch, switch to the target BIOS ROM.
  • Page 73 1. Download the latest BIOS file from the MSI website that matches your motherboard model. 2. Rename the BIOS file to MSI.ROM, and save it to the root directory of a USB flash device. 3. Connect the power supply to CPU_PWR1 and ATX_PWR1. (You don’ t need to install the CPU and memory.)

  • Page 74: Block Diagram

    Block Diagram MPG X870E CARBON WIFI PCI_E1 DDR5 PCIe 5.0x16 DIMM A1/A2 DIMM B1/B2 PCI_E2 M.2_1 PCIe 5.0x4 GEN5 x4 (PCIe Only) M.2_2 HDMI 2.1 FRL (8K@60Hz) GEN5 x4 (PCIe Only) USB4 40Gbps(Type-C) USB3.2 Gen2 10Gbps (Rear Type-C/Type-A) ASM4242 SIO 6687 PCIE x4 USB3.2 Gen2 10Gbps (Rear Type-C/Type-A)

  • Page 75: Regulatory Notices

    This device may not cause harmful interference. ● This device must accept any interference received, including interference that may ● cause undesired operation. MSI Computer Corp. 901 Canada Court, City of Industry, CA 91748, USA (626)913-0828 www.msi.com...
  • Page 76 ● Compliance with these directives is assessed using applicable European Harmonized Standards. The point of contact for regulatory matters is MSI-Europe: Eindhoven 5706 5692 ER Son. Products with Radio Functionality (EMF) This product incorporates a radio transmitting and receiving device. For computers in normal use, a separation distance of 20 cm ensures that radio frequency exposure levels comply with EU requirements.

  • Page 77: Australia And New Zealand Notice

    Wireless Radio Use This device is restricted to indoor use when operating in the 2.4GHz, 5GHz, 6GHz frequency band. Cet appareil doit être utilisé à l’ intérieur. 당해 무선설비는 운용중 전파혼신 가능성이 있음. この製品は 、 周波数帯域 2.4GHz, 5GHz, 6GHz で動作しているときは 、 屋内においてのみ使用 可能です...
  • Page 78 KC인증서 상호: (주)엠에스아이코리아 제품명: 메인보드 모델명: 10-7E49 제조년월: 2024년 R-R-MSI-10-7E49 제조자 및 제조국가: MSI/중국 KC인증서 상호: (주)엠에스아이코리아 제품명: USB FLASH DRIVE 모델명: USB3VR09 제조년월: 2024년 R-R-MSI-USB3VR09 제조자 및 제조국가: MSI/중국...

  • Page 79: Battery Information

    Battery Information European Union: Batteries, battery packs, and accumulators should not be disposed of as unsorted household waste. Please use the public collection system to return, recycle, or treat them in compliance with the local regulations. BSMI: 廢電池請回收 For better environmental protection, waste batteries should be collected separately for recycling or special disposal.

  • Page 80: Chemical Substances Information

    MSI will comply with the product take back requirements at the end of life of MSI-branded products that are sold into the EU. You can return these products to local collection points.
  • Page 81 MSI će poštovati zahtev o preuzimanju ovakvih proizvoda kojima je istekao vek trajanja, koji imaju MSI oznaku i koji su prodati u EU. Ove proizvode možete vratiti na lokalnim mestima za prikupljanje.
  • Page 82 MSI si adeguerà a tale Direttiva ritirando tutti i prodotti marchiati MSI che sono stati venduti all’ interno dell’ Unione Europea alla fine del loro ciclo di vita.

  • Page 83: 日本Jis C 0950材質宣言

    2008 № 1057. Việt Nam RoHS Kể từ ngày 01/12/2012, tất cả các sản phẩm do công ty MSI sản xuất tuân thủ Thông tư số 30/2011/TT-BCT quy định tạm thời về giới hạn hàm lượng cho phép của một số hóa...
  • Page 84 MS-7E49主板产品中有害物质的名称及含量 有害物质 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板组件* ╳ ○ ○ ○ ○ ○ 纽扣电池 ○ ○ ○ ○ ○ ○ 外部信号连接头 ╳ ○ ○ ○ ○ ○ 其他 (例: 线材等) ╳ ○...
  • Page 85 限用物質含有情況標示聲明書 設備名稱 ： 電腦主機板 型號(型式) ： MS-7E49 限用物質及其化學符號 單元 鉛 汞 鎘 六價鉻 多溴聯苯 多溴二苯醚 (Pb) (Hg) (Cd) (PBB) (PBDE) 電路板 ○ ○ ○ ○ ○ ○ 電子元件 ─ ○ ○ ○ ○ ○ 金屬機構件 ─ ○ ○ ○ ○ ○...

  • Page 86: Copyright And Trademarks Notice

    Copyright and Trademarks Notice Copyright © Micro-Star Int’ l Co., Ltd. All rights reserved. The MSI logo used is a registered trademark of Micro-Star Int’ l Co., Ltd. All other marks and names mentioned may be trademarks of their respective owners. No warranty as to accuracy or completeness is expressed or implied.

This manual is also suitable for:

Mpg x870e carbon wifiMpg series
