SERVICE MANUAL
EXM Pro12
SMT Disclaimer
Due to the complex nature of the use of SMT installed components
in Yorkville equipment, we highly caution all service technicians in
attempting to repair or replace SMT factory installed components.
Many of these components may be glued prior to initial soldering.
Replacing SMT components requires expensive
specialized de-soldering equipment and training.
Yorkville Sound will repair and replace defective SMT components
to ensure proper quality assurance and installation is maintained.
EXMPRO12
Manual-Service-EXMPRO12-00-1v0 • MArch 6, 2025

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EXM Pro12 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for YORKVILLE EXM Pro12

Summary of Contents for YORKVILLE EXM Pro12

  • Page 1 Due to the complex nature of the use of SMT installed components 550 Granite Court 4625 Witmer Industrial Estate in Yorkville equipment, we highly caution all service technicians in Pickering, Ontario Niagara Falls, New York attempting to repair or replace SMT factory installed components.

  • Page 2: Important Safety Instructions

    IMPORTA NT SA FETY INSTRUCTIONS This lightning flash with arrowhead symbol, within an The exclamation point within an equilatereal triangle is intended to alert the user to the presence equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous of important operating and maintenance (servicing) instructions in the literature accompanying voltage”...
  • Page 3 This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 4 A-Z1839R / 1v0 120 V 50-60 Hz SERIAL NUMBER 100 VA DESIGNED & MANUFACTURED BY YORKVILLE SOUND • TORONTO, CANADA FUSE: T2.0AH NO USER SERVICEABLE PARTS INSIDE. NE CONTIENT AUCUNE PIECE CAUTION: REPLACE FUSE WITH REPARABLE PAR L’UTILISATEUR. THE SAME TYPE AND RATING ATTENTION: REMPLACER LE FUSIBLE DU MÊME TYPE ET DU MÊME COURANT NOMINAL...

  • Page 5: Specifications

    Specifications Program Power (watts) 800 watts program (500 Low, 200 Mid, 100 High) Max SPL (dB) 125dB Cont, 131dB Peak Frequency Response (Hz +/- 3dB) 45 - 20K (Hz +/-3dB) Power Consumption While Charging 100 watts (battery fully discharged and unit idling) Speaker Configuration - LF 12 inch Neo Speaker Configuration - MF/HF 6.5-inch/1-inch exit horn Neo Coaxial Inputs 8...

  • Page 6: Spécifications

    Spécifications Puissance Nominale (watts) 800 watts program (500 Basses, 200 Médiannes, 100 Aigues) Pression Sonore Max (dB) 125dB Cont, 131dB Pointe Réponse en Fréquence (Hz +/- 3dB) 45 - 20K (Hz +/-3dB) Consommation de puissance durant la charge 100 watts (batterie complètement déchargée et appareil en attente.
  • Page 7 Block Diagram - EXM Pro12 DESIGNED BY YORKVILLE SOUND Channel 1 Reverb Line 1/4-inch Bass / Treble CLIP Level Line Limit Combi Jack +48V Phantom 1.4-Inch Limit Tweeter Horn Power Channel 2 Reverb Notch Line 1/4-inch Master Bass / Treble...
  • Page 8 M2103 01-1 Parts Reference List 2025-02-19 YS # Description YS # Description YS # Description YS # Description YS # Description AI-ASS C206 M2103-59 EXMPRO12 MIXER M2103 5979 100N 50V 5%CAP 0805 SMT X7R 5979 100N 50V 5%CAP 0805 SMT X7R 7032 LED 1V7 20MA 1206 SMT 7634...
  • Page 9 M2103 01-2 Parts Reference List 2025-02-19 YS # Description YS # Description YS # Description YS # Description YS # Description R121 R204 R445 7679 W100 4K99 1% 0805 SMT RES 7625 W100 10K0 1% 0805 SMT RES 7823 W100 18K2 1% 0805 SMT RES R122 R205...
  • Page 10 M2401 01 Parts Reference List 2025-02-19 YS # Description YS # Description YS # Description YS # Description YS # Description AI-ASS M2104-59 EXMPRO12 PS & AMP 6018 __1U 100V 10%CAP X7R 1206 SMT 3303 INDUCTOR: 22UH 7688 W125 4M7 5% 0805 SMT RES R153 7978...
  • Page 11 +12V_MXR R153 C104 MMBT3906LT1 0805 4X4mm 100K0 7805 R156 R157 SOT23 W100 W100 W100 10K0 10K0 20K5 0805 0805 0805 MMSZ15T1G R158 15V0 15K0 0805 R159 SOD-123 Wake+ W100 100R 0805 0805 100N BIAS SO16 LM13700MX R160 0805 C139 W100 U19:1 100R Phant+...
  • Page 12 +12V_MXR C136 MMBT3906LT1 0805 4X4mm 100K0 R215 R216 7805 W125 W125 R290 SOT23 W100 W100 1K21 3K32 W100 100V 100V 10K0 20K5 0805 0805 6K98 0805 0805 R282 C143 0805 RAD .2in RAD .2in 10K0 R228 0805 220P 100V 15K0 W100 0805 0805...
  • Page 13 +12V_MXR Phant+ 6847 Mic/Line +VSw2 MMBTA42 R184 R183 SOT-23 W100 W100 4K99 4K99 100R 100R R192 R197 0805 0805 0805 0805 47K5 Ch 3 R186 0805 0805 7033 W100 CLIP 100R R168 R169 0805 4K99 4K99 6x6mm R334 0805 0805 SOT-23 0805 C106...
  • Page 14 W125 8K25 0805 MonoChannel1 SECTION MonoChannel2 SECTION U13:1 ChOut MonoChannel3 SECTION 5X5.5mm FX SECTION MC33078 W100 W125 475R0 1K21 0805 0805 C199 BusGnd C201 5X5.5mm W125 8K25 5X5.5mm 0805 Grounds C181 R258 475R0 Wake+ 0805 W125 100N 200K0 0805 0805 C182 R268 Wake-...
  • Page 15 +3V3 +12V_MXR R441 600R W125 +3V3 DSP F0805 U6:3 10R0 MC33078 0805 600R U37:3 U35:3 7817 F0805 +3V3 R431 MMBT3906LT1 MC33078 475R0 SOT23 C262 C263 MC33078 0805 0603 1206 0805 0805 C268 C269 C270 OSCILLATOR 0603 0603 1206 R136 7805 C285 7894 W125...

  • Page 16: Digital Effects

    R150 W100 20K5 0805 220P 100V +3V3FX 0805 100N 0805 0805 0805 R154 R152 7817 W100 W100 MonoChannel1 SECTION 100N R167 20K5 10K0 MonoChannel2 SECTION 0805 CLIP MC33078 W100 W100 ChOut 0805 0805 MonoChannel3 SECTION LOUT 28 4K99 U11:2 4K99 R155 Master SECTION 5X5.5mm...
  • Page 17 Wake- 100P 100V 0603 C119 C120 0805 0805 W100 10K0 R170 0805 W100 BT_Gnd 8516 10K0 R172 R218 R220 0805 BT_R RFS1 P0_0 / UART_TX_IND W125 100K0 100K0 +AdapIn 470R 0805 0805 R180 SCLK1 P3_7 / UART_CTS 1206 TL062 0805 J110 W100 P1_3 / TCK_CPU / SDA...

  • Page 18: Battery Status

    W1:2 BuckEnable W1:1 +VSw2 R261 100R +12V_MXR 0805 R265 R166 +5Vsw 562R0 Power 2K21 0805 0805 R114 499R MMBT5401 0805 LD3:1 LD17:2 SOT-23 7837 S3:2 S3:1 7036 7036 R246 18K2 LD17:1 LD3:2 Grounds 0805 0805 R326 LD16 7031 7031 100% 0805 +12V_MXR 8x8mm...

  • Page 19: Change History

    DESIGN HISTORY AND INFORMATION POTENTIOMETERS AND KNOBS CHANGE HISTORY POTENTIOMETERS/SWITCHES AND KNOBS DATE VER# DESCRIPTION OF CHANGE FUNCTION POT/SW YS# STYLE KNOB# M2103V01P5 April-18-2023 V01P4 LEVEL 4430 DEC-8-2023 V01P5 Ground Link trace connection between IG and Bat_Gnd removed from W8 pin 8 connector. LEVEL 4430 DESCRIPTION OF CHANGE...
  • Page 20 7K50 C277 100N 100N LD16 MASTER C287 EXMPRO12 R434 C272 C288 100N R454 12.288 S/N LABEL 475R0 R431 SLEEP ON/OFF TEST M2103 V01.2 Yorkville Yorkville C266 MIXER 2021 2021 C271 Score CLINCH M2103V01.2 EXMPRO12 MIXER INSERT INSERT ORIGIN ORIGIN SECONDARY...
  • Page 21 PCB ASSEMBLY DOCUMENTATION 26 mm FOAM 67 mm 3 mm THIS SHEET CONTAINS SPECIAL PRODUCTION NOTES AND A LIST OF PCB HARDWARE PARTS REQUIRED FOR THE BUILD. Assembly Documentation Section:...
  • Page 22 DESIGN HISTORY AND INFORMATION POTENTIOMETERS AND KNOBS CHANGE HISTORY POTENTIOMETERS/SWITCHES AND KNOBS DATE VER# DESCRIPTION OF CHANGE FUNCTION POT/SW YS# STYLE KNOB# M2103V01P5 April-18-2023 V01P4 LEVEL 4430 DEC-8-2023 V01P5 Ground Link trace connection between IG and Bat_Gnd removed from W8 pin 8 connector. DESCRIPTION OF CHANGE LEVEL 4430...
  • Page 23 +12V +VSw R138 W500 1210 3300U /63V 22X35MM 22UH 3300U 0805 1206 1206 3303 1206 2220 AGND AGND R110 R111 +VSw 1210 1210 3300U /63V 0805 PVDD_AB BST_A R112 R109 22X35MM PVDD_AB TPA3255 0805 3300U 1206 1206 PVDD_AB BST_B 1210 1210 6709 TSSOP44P...
  • Page 24 +12V +VSw R135 W500 3300U /63V 1210 22UH 22X35MM 3300U 3303 0805 1206 1206 1206 2220 R146 R147 AGND AGND +VSw 1210 1210 3300U /63V 0805 R148 R149 PVDD_AB BST_A 22X35MM PVDD_AB TPA3255 0805 1210 1210 3300U 1206 1206 PVDD_AB 6709 BST_B TSSOP44P...
  • Page 25 R136 B160 DO214AC BST 3 22UH RON/SD W125 +5V_FX 4X4mm 0805 4X4mm DO214AC 47K5 LM5010 100N 7975 SW 2 B160 0805 0805 6726 +VSw HTSSOP14 FDN5618 DO214AC ISEN B160 SOT-23 8x8mm FB 9 0805 0805 100U 6976 THERM +24V 0805 0805 SGND W125...
  • Page 26 1W00 1W00 1W00 2512 2512 2512 YS#5099 BATTERY YS#5099 BATTERY 15K0 100K0 SOD-323 0805 0805 0805 12V0 FDN5618 W3:1 W4:1 6976 100K0 W100 0805 100K0 SOT-23 W3:2 W4:2 0805 100N W3:3 W4:3 W100 W100 0805 100K0 0805 0805 0805 U6:2 W100 7661 7661...
  • Page 27 ClassName: RelayCircuit K1:3 W500 W500 033MA 2010 2010 ES1J 0W35 110VDC DO-214AC 43V0 274K W500 W500 RELAY 2C 0805 2010 2010 0W35 ES1J 43V0 4137 DO-214AC R100 0W35 ES1J 43V0 274K 0805 DO-214AC 220N ES1J 250V 0W35 DO-214AC RAD POLY 43V0 ES1J DO-214AC...
  • Page 28 DESIGN HISTORY AND INFORMATION CHANGE HISTORY DATE VER# DESCRIPTION OF CHANGE April-18-2023 V01P4 Dec-7-2023 V01P5 (R1 from 200K to 33K) (R3 from 200K to 100K0) (R30 10R0 removed) (R35 from 30K0 to 100K0) (R41 from 39R to 10R0) (R143 from 200K to 33K) (R144 from 200K to 100K0) (C16 from 47P to 220P) R136 0R0 replaced with B160 Diode) (C96 2U2/100V added between D8 pin2 and Buckgnd) (R133,R137,R142,R145 47R added in Series/Parallel Between Q15 and Q16)
  • Page 29 R145 10K0 100K0 4148 FDN5618 10K0 R142 R137 274K 1300UH 10K0 TEMP 43V0 43V0 6492 4227 4227 4227 4227 Yorkville Yorkville 43V0 ES1J 2021 2021 ES1J 250V R106 R127 R130 100N 100N 220UH B360 NTD20P06L R35 R11 LM5010 10K0 10K0...
  • Page 30 PCB ASSEMBLY DOCUMENTATION IMPORTANT! AFTER WAVE SOLDER BEFORE WAVE SOLDER 2_Remove the Kapton tape from the spacers. PCB HARDWARE 1_ADD Soldermask dots to the two threaded spacers bottom side of pcb . Z1892 Z1892 4285 4285 9441 9441 9441 9441 3_Place YS# 4285 (GAPPAD GR130A 1.50MM 15X7.5MM) onto U9 and U10 .Handle the pad by the edges only.
  • Page 31 PCB ASSEMBLY DOCUMENTATION ADD ADHESIVE AS SHOWN THIS SHEET CONTAINS SPECIAL PRODUCTION NOTES AND A LIST OF PCB HARDWARE PARTS REQUIRED FOR THE BUILD. Assembly Documentation Section: EXMPRO12 Product(s):...
  • Page 32 DESIGN HISTORY AND INFORMATION CHANGE HISTORY DATE VER# DESCRIPTION OF CHANGE April-18-2023 V01P4 Dec-7-2023 V01P5 (R1 from 200K to 33K) (R3 from 200K to 100K0) (R30 10R0 removed) (R35 from 30K0 to 100K0) (R41 from 39R to 10R0) (R143 from 200K to 33K) (R144 from 200K to 100K0) (C16 from 47P to 220P) R136 0R0 replaced with B160 Diode) (C96 2U2/100V added between D8 pin2 and Buckgnd) (R133,R137,R142,R145 47R added in Series/Parallel Between Q15 and Q16)
  • Page 33 Bluetooth® enabled devices and Low-Power “Sleep” State: The “Sleep” Button Operation: supports wireless ‘stereo’ pairing between state is a special feature of the EXM Pro12, this Single Tap: Enables Bluetooth® two EXM Pro12s. In Bluetooth® stereo mode, automatic mode reduces energy consumption Double Tap: Enter Stereo Mode the first unit acts as the “Primary,”...
  • Page 34 (environ 10 % restants). Les indicateurs ne mode stéréo. Le jumelage d’un appareil à une fonctionnent que lorsque l’appareil est allumé. EXM Pro12 qui est en mode secondaire met fin à la connexion sans fil stéréo. L'EXM Pro12 est livré avec 20-30% de la capacité...
