Page 1: Table Of Contents
General Information Safety Rules Electrical Connections Settings Accessories connection Manual Chain Using Method Circuit Board Fault Codes Accessories List SHAFT-1P-KIT/ 3P-KIT SERIES Installation and Operation Manual Relevant for versions: Control board - v 1.0 Software- v 1.0 © DoorHan, 04.2024... -
Page 2: General Information
1. GENERAL INFORMATION The electromechanical shaft operators 1P-KIT/3P-KIT series were designed for automation of industrial sectional doors. Each operator consists of a mechanical reducer in "oil bath", electric motor, encoder and control unit. The reducer and the motor have common casing. The manufacturer does not directly control installation, operation and maintenance of the product. - Page 3 Pic. 1.1. SHAFT-60-1P-KIT/SHAFT-60-3P-KIT Pic. 1.2. Motor size (SHAFT-100-3P-KIT)
-
Page 4: Safety Rules
1P-KIT/3P-KIT series was designed for automation of industrial sectional doors. Do not use the operator for other ƒ than intended purposes. DoorHan shall not be held responsible in case of injury caused by misuse of the product. ƒ Prior to installation make sure that the door is properly balanced and moves smoothly. - Page 5 Do not use the operator if it needs repair or adjustment as installation defects or unbalanced door can cause injury. ƒ DoorHan shall not be held liable in case of improper installation of the item and damage arisen during operation. ƒ...
-
Page 6: Electrical Connections
3. ELECTRICAL CONNECTIONS Pic. 3.1. Motor wiring diagram GND B A VCC CO OP W PE 1. Encoder 6. Waterproof connectors 2. Motor thermal protection line 7. Safety switch 3. Motor power wires 8. Power line 4. Terminals 9. Signal line 5. - Page 7 Pic. 3.2. AC 220V Motor and circuit board wire connection Power line port 1. L, N: AC 220 V 50/60 Hz power supply. 2. PE: Grounding. 3. U, V, W: Motor line. U (blue), V (brown), W (black) and motor terminals U, V, W corresponding connection. 4.
-
Page 8: Settings
4. SETTINGS Pic 4.1. Settings of code switch Code switch 1: Limit mode choice. ON: mechanical limit. OFF: electronic limit. Code switch 2: Not used. Keep it OFF. When mechanical limit: Code switch 3: ON: Automatic delay shutdown state. OFF: Manual shutdown state. When electron limiting time: Code switch 3. - Page 9 Pic 4.4. Display settings button and display symbols 125 mm Digital display screen SET key OPEN key STOP key CLOSE key SET key: Used for settings and parameters confirmation. OPEN key: 1. Used to open the door. 2. Used to increase the value of the parameter. STOP key: 1.
- Page 10 Table 4.1. Input state Number Instructions Stop Open Close One key Middle limit Interlock Door up and down limits adjustments: 1. Long press SET key more than 3 seconds, the display shows P0, than press the SET key one nore time, the display will show LO (upper limit ready to adjust).
- Page 11 4. Press SET key, LED show P2-01 (at this point by OPEN key or DOWN key you can choose and adjust the parameters). 5. Press SET key to save the settings. After the set completion of parameter press SET key to save, step-by-step press STOP key exit to the main menu. Table 4.3.
-
Page 12: Accessories Connection
5) The function of remote control settings Remote control receiving plate, installed on the screen of the socket on the back of the circuit board, can plug. Pay attention to the direction of the insert, when installation should pay attention to in rectangle area specified by the circuit board. - Page 13 Pic. 5.3. DH-W-Safety Pic. 5.4. Photocells Pic. 5.5. DHRE-1...
- Page 14 Pic. 5.6. DHREmini Pic. 5.7. Button (DKH009) Pic. 5.8. KEYSWITCH_SWK...
- Page 15 Pic. 5.9. Radar (AD-06) Pic. 5.10. Lamp or Siren (220V) Pic. 5.11. Traffic light 1P Motor...
-
Page 16: Manual Chain Using Method
Pic. 5.12. Traffic light 3P Motor Pic.5.13. Interlock 6. MANUAL CHAIN USING METHOD When it is necessary to operate the door machine manually, the loop chain will be used. It is advisable to operate the chains with even and continuous force. Sudden jerk of the chain shall be avoided to avoid the damage to the manual mechanism. -
Page 17: Circuit Board Fault Codes
7. CIRCUIT BOARD FAULT CODES Table 7.1. Reasons and solutions of fault codes Fault code Instructions The reason for the error analysis ERR01 Power supply lacks Three-phase 380V lack of L2 phase or wrong phase connection ERR02 Encoder not connected Encoder cables ERR03 Limit anomaly... - Page 18 Number Article Note 1P/3P-ENCODER Encoder for Shaft-60-1P/3P, Shaft-100-3P and Shaft-200-3P 1P/3P-CR-60/100 Chain reducer assembly for Shaft-60-1P/3P, Shaft-100-3P without cover 1P/3P-CR-200 Chain reducer assembly for Shaft-200-3P without cover 1P/3P-CRC-60/100 Chain reducer plastic cover for Shaft-60-1P/3P, Shaft-100-3P 1P/3P-CRC-200 Chain reducer plastic cover for Shaft-200-3P 1P-M Shaft-60-1P 220V Motor assembly 3P-M-60...
- Page 20 Thank you for purchasing DoorHan product. We believe you will be satisfied with its quality. For information on purchasing, distribution and servicing contact DoorHan central office at: 1 bld., 120 Novaya street, Akulovo village, Odintsovo city, Moscow region, 143002, Russia Phone: +7 495 933-24-00 E-mail: info@doorhan.com...
