Lem Elettronica SCF516/6 User Manual

SCF516/6
User manual
Optical Receiver
2 Satellites orbital position 6 Outputs
Reception of 2 satellites and terrestrial feed
6 Legacy/dSCR - DTT/DAB/FM outputs
Output booster for satellite signals
Optical link monitor Led
A.G.C. for each output
MADE IN
ITALY
MODEL
OPTICAL INPUT
RF OUTPUTS
OPTICAL
OPERATION WAVELENGTHS
INPUT POWER RANGE
INPUT CONNECTOR TYPE
RETURN LOSS
SATELLITE
OUTPUT BANDWIDTH
SCR/dCSS OUTPUT LEVEL
LEGACY OUTPUT LEVEL
SATELLITE CONTROL STANDARDS
SCR/dCSS/DSCR PROTOCOLS
AVAILABLE USER BAND FREQUENCY PLANS
TV TERRESTRIAL / FM / DAB
OUTPUT BANDWIDTH
MAXIMUM OUTPUT LEVEL MIX OUT
OUTPUT LEVEL ADJUSTMENT
OTHERS
ISOLATION BETWEEN SATELLITE/TERRESTRIAL
ISOLATION V / H
OUTPUT RETURN LOSS
DC INPUT VOLTAGE RANGE
MAXIMUM CONSUMPTION
OPERATING TEMPERATURE
DIMENSIONS
A B
2 Satellite Positions
nm
dBm
dB
MHz
dBµV
dBµV
MHz
dBµV
dB
dB
dB
dB
V
W
°C
mm
Rel. 1.0
1.270 - 1310 - 1330 - 1.490 - 1550
85 Booster OFF / 94 Booster ON
75 Booster OFF / 80 Booster ON
Universal LNB Voltage & Tone / DiSEqC 1.0 / DiSEqC 2.0
EN50494 / EN50607 / SKY UK (AUTO-SWITCH)
SKY ITALIA - SKY UK
237 x 118 x 38
118 mm
SCF516/6
1
6
-14... 0
SC/APC
≥40
950... 2150
40... 790
≥75
0... -20
≥ 40
> 30
> 10
12... 20
16
0... 50
