INSTALLATION MANUAL
Optical receiver FCO-IF-T
Up to 64 PON
0... -14dBm optical range
Adjustable TV Terrestrial output level
Adjustable IF-SAT output level
Led optical link
ITALY
OPTICAL RECEIVER
OPTICAL INPUT
RF OUTPUTS
OPTICAL
OPERATION WAVELENGTH
INPUT POWER RANGE
INPUT CONNECTOR TYPE
RETURN LOSS
SATELLITE
OUTPUT BANDWIDTH
LEVEL ADJUSTER RANGE
MAX TOTAL OUTPUT LEVEL
TV TERRESTRIAL / FM / DAB
OUTPUT BANDWIDTH
LEVEL ADJUSTER RANGE
MAX TOTAL OUTPUT LEVEL
OTHERS
ISOLATION TV TERR./SATELLITE
OUTPUT RETURN LOSS
INPUT VOLTAGE RANGE
MAXIMUM CONSUMPTION
OPERATING TEMPERATURE
DIMENSIONS
MADE IN
nm
dBm
dB
MHz
dB
dBµV
MHz
dB
dBµV
dB
dB
VDC
W
°C
mm
127 mm
1
1
1550
-14... 0
SC/APC
≥40
950... 2.200
0... -10
105
80... 790
0... -20
105
>40
> 12
12... 20
3,0
0... 50
127x90x35
Rel. 1.0
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lem Elettronica FCO-IF-T
Summary of Contents for Lem Elettronica FCO-IF-T
- Page 1 INSTALLATION MANUAL Optical receiver FCO-IF-T 127 mm Up to 64 PON 0... -14dBm optical range Adjustable TV Terrestrial output level Adjustable IF-SAT output level Led optical link MADE IN ITALY Rel. 1.0 OPTICAL RECEIVER OPTICAL INPUT RF OUTPUTS OPTICAL OPERATION WAVELENGTH...
- Page 3 DESCRIPTION OF SYMBOLS AND ELECTRICAL SAFETY The equipment complies with the CE requirements The equipment is designed for indoor use only Equipment grounding terminal This symbol indicates that the equipment complies with the class II equipment safety requirements To avoid the risk of electric shock, do not open the equipment. CAUTION The equipment is compliant with RoHS 2011/65EU Dispose according to local authorities recycling processes...
- Page 4 TV+IF-SAT 0... -14dBm Ground bonding DC input + Power led Optical signals higher than 0dBm can damage the FCO-IF-T in PON with less than 4 optical points add at least a 7dBm optical attenuator. MONITOR LED DC Input Optical Link...
- Page 5 The optical receiver FCO-IF-T must be used with the transmitters TX-T e TX-IF-T. For a correct transmitter / receivers set up please follow the tables below. SATELLITE FEEDS Number or Optical TX-IF-T Transmitter Satellite FCO-IF-T max. Satellite Optical points Attenuation...
- Page 6 DSP20 Optical Splitter 1x64 FCO-IF-TC FCO-IF-TC FCO-IF-T FCO-IF-T 9/125 TV Terr. Coaxial Single-mode Radio FM/DAB Cable Fiber optic Outlet Distribution of terrestrial feed (DTT; FM; DAB) over a single-mode optical fibre PON. The headend TX-IF-T converts and transmits over a single-mode fibre optical cable the terrestrial feeds.
- Page 7 DSP20 Optical Splitter 1x64 FCO-IF-TC FCO-IF-TC FCO-IF-T FCO-IF-T TV Terr. Single-mode FM/DAB Fibre Optic SATELLITE 9/125 Power Coaxial Line Cable Distribution of IF-IF SAT and terrestrial feed (DTT; FM; DAB) over a single-mode optical fibre PON. The headend TX-IF-T converts and transmits over a single-mode fibre optical cable the terrestrial feeds and the IF-SAT output.
- Page 8 Label with serial and tracking data Model Serial # Manuf. Manuf. Week Year Rel. Rel. LEM ELETTRONICA srl • Via Grezze, 38 • 25015 Desenzano d/G • Italy Tel. +39 0309120006 • Fax. +39 0309123035 • info@lemelettronica.it www.lemelettronica.it...
