- Page 1 ST208E/208S User Manual Enhanced 2.4G Wireless Bridge User Manual ST208E/ST208S V2.0 Be Honest & Do Best Your Trustworthy Smart Industrial IoT Partner pusr.com...
-
Page 2: Table Of Contents
2.6.5. Firmware Upgrade ........................- 23 - 2.6.6. User management ........................- 24 - 2.6.7. System restart ..........................- 24 - 2.6.8. SSH Tool ............................. - 25 - 2.6.9. Management Tool ........................- 25 - 2.7. DM Platform ............................- 30 - pusr.com - 2 -... - Page 3 2.7.5. Firmware upgrading ........................- 36 - 2.7.6. Delete bridge device ........................- 38 - 3. Warranty ................................- 38 - 4. Contact Us ..............................- 38 - 5. Disclaimer ..............................- 38 - 6. Revision History ............................. - 39 - pusr.com - 3 -...
-
Page 4: Introduction
300Mbps, and the measured coverage distance can reach 300 meters. It supports PoE injector and power adapter to power on the device and comes with 2 x 10/100Mbps RJ45 ports. PUSR offers 2 version for customers to choose from: the standard version and the external antenna version. -
Page 5: Indicators Description
The device is powered on normally. No power supply connected or power supply is abnormal. Flashing The device can work normally. WORK OFF/Steady ON The device work abnormally. The port is connected. LAN1/LAN2 Flashing The port is transmitting data. pusr.com - 5 -... -
Page 6: Dimension
-75dBm ≤ RSSI< -65dBm, the wireless signal is Yellow normal. RSSI < -75dBm,the wireless signal is weak. Please adjustthe position and direction of the device The devices are not matched. 1.5. Dimension Unit: mm Figure 1. Dimension of ST208E pusr.com - 6 -... -
Page 7: How To Power
Note: It's suggested to use the attached PoE injector to power on the device. If you need to use other POE injectors, you can view the "Product Parameters" to check the power parameters and select an appropriate POE injector for power supply, otherwise the bridge may be damaged. Option 2: Power with power adapter pusr.com - 7 -... -
Page 8: Network Diagram Of The Bridges Connections
Internet, connect the master bridge to router or switches that can access the Internet. Figure 5. The mater bridge connections The slave bridge is suggested connecting to the IP camera and the other terminal device. pusr.com - 8 -... -
Page 9: Get Started
The username is admin, the password is admin01. Items Value SSID ST208-XXXX, XXXX is the last 4 characters of the MAC address. Master bridge: 192.168.2.66 Slave bridge: 192.168.2.67 WiFi Password www.usr.cn (only available of master bridge) User Name admin Login Password Admin01 pusr.com - 9 -... -
Page 10: Overview Information
When you log in to the device, the web page will navigate you to the overview page. Users can check [System Information], [Equipment Status], [ARP Information] and other needed information. The bridge in the box is pre-paired, after powering on, the master and the slave bridge can communicate already. Figure 8. Initializing configuration pusr.com - 10 -... -
Page 11: Quick Settings
LAN settings: the IP address of master and the slave bridge should be in the same network segment. Can leave the DNS as blank if the bridge needn’t access Internet. Wireless settings: the slave wireless bridge will connect the master bridge using this [wireless name] and [wireless password]. pusr.com - 11 -... -
Page 12: Settings Of Slave Bridge
2.4.2. Settings of Slave bridge Select the “subnet bridge end”, and the click the “Next step”. Figure 9. Select work mode LAN settings: the IP address should be in the same network segment with the master bridge. pusr.com - 12 -... - Page 13 Wireless settings: users can enter the wireless name of the master bridge manually or click “scan bridge network” to scan the master’s wireless. Figure 11. Wireless settings Checking the settings, and click the “Accomplish” button to finish the settings. pusr.com - 13 -...
-
Page 14: Checking The Connection Status
Alternatively, when the SIG indicator is on, the connection between the main and slave Bridges is successful. Figure 13. Status of slave bridge PC connect to the slave bridge via LAN port, and login to the master bridge via 192.168.2.66(IP address of master bridge). pusr.com - 14 -... -
Page 15: Network Management
IP address of other network devices. The device also supports a DHCP client. When the device is connected to a network with a DHCP server, it automatically obtains an IP address. Figure 15. Static IP pusr.com - 15 -... - Page 16 Not required for local network communication DHCP lease Click to update to restart the lease timer NONE DHCP IP Off: The bridge will be without an IP when it fails to obtain address fallback an IP via DHCP pusr.com - 16 -...
-
Page 17: Wireless Settings
Checked: SSID is visible and can be searched for connection Open attempts. Checked SSID broadcast Unchecked: SSID is hidden and cannot be searched; the sub bridge can connect to the main bridge only by entering the pusr.com - 17 -... - Page 18 Countries Select the country and region. and regions wireless Auto or channels 1-13. auto channel Set the appropriate transmission power based on the wireless power 100% environment; default is maximum power level. pusr.com - 18 -...
- Page 19 SSID and must enter it manually. When there are multiple devices with the same SSID, Peer MAC address you can distinguish the target main bridge by its MAC NONE address, e.g., D4:AD:20:AD:78:74. pusr.com - 19 -...
- Page 20 WPA2 PSK (TKIP, CCMP) Wireless password Set the wireless password. www.usr.cn Note: If a PC is connected to the hotspot of master/slave bridge, it should be set a static IP address in the same network segment as the bridge. pusr.com - 20 -...
-
Page 21: System Management
NTP Server_1 Set the NTP server address None NTP Server_2 Set the NTP server address None 2.6.2. System Log Query or download system logs. The downloaded logs contain the logs of the last one to three days. pusr.com - 21 -... -
Page 22: Ping Test
2.6.3. Ping Test Users can diagnose the network status using ping, traceroute and nslookup tools. Figure 21. Network diagnose 2.6.4. Configuration Users can reset the bridge to factory settings, export and import configuration file on this page. pusr.com - 22 -... -
Page 23: Firmware Upgrade
Do not power off the bridge during the upgrade process. The upgrade process lasts about 3 minutes. Please wait until the WORK indicator is on and log in to the built-in web page again. Figure 23. Firmware upgrading Note: The parameter set by the customer is reserved by default after the firmware upgrading. pusr.com - 23 -... -
Page 24: User Management
Users can modify the web login password on this page. Figure 24. User management 2.6.7. System restart Users can reboot the bridge device or set Scheduled Reboot the bridge on this page. Figure 25. System restart pusr.com - 24 -... -
Page 25: Ssh Tool
2.6.9. Management Tool Through the management tool, the basic bridge information, such as device information, network information, wireless information, etc. can be transferred to the customer defined server. The bridge support 1 server and 5 rules. pusr.com - 25 -... - Page 26 The data cycle for actively reporting rules list, in minutes None The content of the registration packet when connecting to the Registration packet server Custom Custom/None/SN/MAC Register Package Type The type of custom registration packet, ASCII or HEX ASCII pusr.com - 26 -...
- Page 27 If a query command is filled in, the server will send the query command Query instructions to query the information. None If it’s leaved blank, server can send rule name to query the information. Table 7. Descriptions of the rules pusr.com - 27 -...
- Page 28 Users can also send AT command to query information of the bridge device. When sending AT command from the server, it need add the “Query instructions” before the AT command like the AT command format in the following picture. Figure 32. Query device information with rule Figure 33. Basic data rules detail pusr.com - 28 -...
- Page 29 Figure 34. Query device information using query instruction If the query instructions is leaved blank, users can send rule name to query device information like the following picture. Figure 35. Query device information using rule name pusr.com - 29 -...
-
Page 30: Dm Platform
Login website: mp.usriot.com Note: Add all the master/slave bridges that you want to manage in the DM platform. For unified management, add all Bridges that need to be managed by the platform to one account. pusr.com - 30 -... -
Page 31: Add Bridge Device In Dm Platform
2.7.1. Add bridge device in DM platform Add bridge using SN and MAC. Users can get the SN and MAC on the back label or on the GUI of the bridge. Figure 38. Add bridge 1> Add master bridge and slave bridge pusr.com - 31 -... -
Page 32: Set Bridge Device
ST208E/208S User Manual Figure 39. Add bridge 2> Add bridge device successfully Figure 40. Add bridge device successfully 2.7.2. Set bridge device Enable the DM platform. This function is enabled by default. Figure 41. Enable DM platform pusr.com - 32 -... - Page 33 Settings of the master bridge: if the bridge need to access the Internet, the DNS server must be set. Figure 43. Settings of the master bridge Settings of the slave bridge: if the bridge need to access the Internet, the DNS server must be set. pusr.com - 33 -...
-
Page 34: The Bridge Get Online
Figure 44. Settings of the slave bridge 2.7.3. The bridge get online Figure 45. Get online Users can also check the paired bridges on the platform. In this case there is one slave bridge is paired with master bridge. pusr.com - 34 -... - Page 35 ST208E/208S User Manual Figure 46. Paired bridges Click the gateway name, it will display the bridge details. Figure 47. Bridge details Figure 48. Network topology diagram pusr.com - 35 -...
-
Page 36: Open The Gui On Platform
2.7.4. Open the GUI on platform Click the “More” button to open the configuration page. Figure 49. Open configuration page Figure 50. The login page 2.7.5. Firmware upgrading Users can open the firmware upgrade page in 2 ways: The first way: pusr.com - 36 -... - Page 37 ST208E/208S User Manual Figure 51. Firmware upgrade Figure 52. Firmware upgrade settings The second way: Figure 53. Firmware upgrading pusr.com - 37 -...
-
Page 38: Delete Bridge Device
4. Contact Us Jinan USR IOT Technology Limited Address : Floor 12 and 13, CEIBS Alumni Industrial Building, No. 3 Road of Maolingshan, Lixia District, Jinan, Shandong, China Official website:https://www.pusr.com Official shop:https://shop.usriot.com Technical support: http://h.usriot.com/ Email : sales@usriot.com Tel : +86-531-88826739 Fax : +86-531-88826739-808 5. -
Page 39: Revision History
USR IoT and/or its affiliates do not make any commitment to update the information contained in this document. 6. Revision History Version Date Author Description V1.0.0 2023-11-17 Established V1.0.1 2024-01-27 May Liu Translation pusr.com - 39 -... - Page 40 ST208E/208S User Manual Official Website: www.pusr.com Official Shop: shop.usriot.com Technical Support: h.usriot.com Inquiry Email: inquiry@usriot.com Skype & WhatsApp: +86 13405313834 关注有人微信公众号 登录商城快速下单 Product Catalog Facebook Youtube Click to view more: & & pusr.com...
