HiLook VI-K43P User Manual

Video intercom kit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VI-K43P Video Intercom Kit
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VI-K43P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HiLook VI-K43P

Summary of Contents for HiLook VI-K43P

  • Page 1 VI-K43P Video Intercom Kit User Manual...
  • Page 2 VI-V400W Villa Door Station User Manual...

  • Page 3: Legal Information

    VI-V400W Villa Door Station User Manual Legal Information About this Document This Document includes instructions for using and managing the Product. Pictures, charts, ● images and all other information hereinafter are for description and explanation only. The information contained in the Document is subject to change, without notice, due to ●...
  • Page 4 VI-V400W Villa Door Station User Manual PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS. YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY ● RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS;...

  • Page 5: Symbol Conventions

    VI-V400W Villa Door Station User Manual Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Indicates a hazardous situation which, if not avoided, will or could Danger result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, could Caution result in equipment damage, data loss, performance degradation, or...

  • Page 6: Safety Instruction

    VI-V400W Villa Door Station User Manual Safety Instruction Warning All the electronic operation should be strictly compliance with the electrical safety regulations, ● fire prevention regulations and other related regulations in your local region. Please use the power adapter, which is provided by normal company. The power consumption ●...
  • Page 7 VI-V400W Villa Door Station User Manual Improper use or replacement of the battery may result in hazard of explosion. Replace with the ● same or equivalent type only. Dispose of used batteries according to the instructions provided by the battery manufacturer. Input voltage should meet both the SELV and the Limited Power Source according to 60950-1 ●...

  • Page 8: Regulatory Information

    VI-V400W Villa Door Station User Manual Regulatory Information EU Conformity Statement This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the EMC Directive 2014/30/EU, the RoHS Directive 2011/65/EU 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union.
  • Page 9 VI-V400W Villa Door Station User Manual Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité...

  • Page 10: Table Of Contents

    VI-V400W Villa Door Station User Manual Contents Chapter 1 Appearance ........................ 1 Chapter 2 Terminal and Wiring Description ................. 3 2.1 Terminal Description ......................3 2.2 Wiring Description ......................... 4 2.2.1 Door Lock Wiring ......................4 2.2.2 Door Contact Wiring ..................... 5 2.2.3 Exit Button Wiring ......................
  • Page 11 VI-V400W Villa Door Station User Manual 5.6.4 Video & Audio Settings ....................30 5.6.5 Image Settings ......................33 5.6.6 Event Settings ......................36 5.6.7 Schedule Settings ......................40 5.6.8 Intercom Settings ......................41 5.6.9 Access Control Settings ....................44 Chapter 6 Configuration via Client Software ................48 6.1 Device Management ......................
  • Page 12 VI-V400W Villa Door Station User Manual 7.1 Call Resident ........................61 7.2 Unlock Door ......................... 61...

  • Page 13: Chapter 1 Appearance

    VI-V400W Villa Door Station User Manual Chapter 1 Appearance Front Panel and Rear Panel Figure 1-1 Front Panel and Rear Panel Table 1-1 Description Description Microphone Camera Indicator Unlock (Green)/ Call (Orange)/ Communicate (White) Button Card Reading Area Loudspeaker...

  • Page 14: Bottom Panel

    VI-V400W Villa Door Station User Manual Description Terminals Debugging Port TAMPER Set Screw Bottom Panel Figure 1-2 Bottom Panel Table 1-2 Description Description TF Card Slot (Reserved) Network Interface...

  • Page 15: Chapter 2 Terminal And Wiring Description

    VI-V400W Villa Door Station User Manual Chapter 2 Terminal and Wiring Description 2.1 Terminal Description Figure 2-1 Terminal Description Note RS-485 terminal is not supported.

  • Page 16: Wiring Description

    VI-V400W Villa Door Station User Manual 2.2 Wiring Description 2.2.1 Door Lock Wiring Figure 2-2 Door Lock Wiring Note Terminal NC/COM is set as default for accessing magnetic lock/electric bolt; terminal NO/COM is set as default for accessing electric strike.

  • Page 17: Door Contact Wiring

    VI-V400W Villa Door Station User Manual 2.2.2 Door Contact Wiring Figure 2-3 Door Contact Wiring...

  • Page 18: Exit Button Wiring

    VI-V400W Villa Door Station User Manual 2.2.3 Exit Button Wiring Figure 2-4 Exit Botton Wiring...

  • Page 19: Alarm Input Device Wiring

    VI-V400W Villa Door Station User Manual 2.2.4 Alarm Input Device Wiring Figure 2-5 Alarm Input Device Wiring...

  • Page 20: Chapter 3 Installation

    VI-V400W Villa Door Station User Manual Chapter 3 Installation Note Make sure the device in the package is in good condition and all the assembly parts are included. ● Make sure your power supply matches your door station. ● Make sure all the related equipment is power-off during the installation. ●...

  • Page 21: Surface Mounting Without Protective Shield

    VI-V400W Villa Door Station User Manual Note The dimension of the mounting plate is 102.58 mm × 39.24 mm × 6.2 mm. 3.2 Surface Mounting without Protective Shield Before You Start Tools that you need to prepare for installation: Drill (ø2.846) and gradienter. ●...
  • Page 22 VI-V400W Villa Door Station User Manual Figure 3-2 Mounting Template 2. Secure the mounting plate on the wall with 4 supplied screws according to the screw holes. 3. Install the villa door station to the mounting plate. Fix the device on the mounting plate with the set screw.
  • Page 23 VI-V400W Villa Door Station User Manual Figure 3-3 Apply Silicone Sealant...

  • Page 24: Surface Mounting With Protective Shield

    VI-V400W Villa Door Station User Manual Figure 3-4 Surface Mounting without Protective Shield 3.3 Surface Mounting with Protective Shield Before You Start Tools that you need to prepare for installation: Drill (ø2.846) and gradienter. ● Purchase the protective shield before installation. ●...
  • Page 25 VI-V400W Villa Door Station User Manual Figure 3-5 Mounting Template 2. Align the protective shield with the mounting template. 3. Secure the mounting plate and protective shield on the wall with 4 supplied screws according to the screw holes. 4. Install the villa door station to the mounting plate. Fix the device on the mounting plate with the set screw.
  • Page 26 VI-V400W Villa Door Station User Manual Figure 3-6 Surface Mounting with Protective Shield...
  • Page 27 VI-V400W Villa Door Station User Manual Figure 3-7 Finished View...

  • Page 28: Chapter 4 Activation

    VI-V400W Villa Door Station User Manual Chapter 4 Activation 4.1 Activate via Web Browser You can activate the device via the web browser. Steps 1. Enter the device default IP address (192.0.0.65) in the address bar of the web browser, and press Enter.

  • Page 29: Edit Network Parameters

    VI-V400W Villa Door Station User Manual 4. Create a password, and confirm the password. Caution The password strength of the device can be automatically checked. We highly recommend you change the password of your own choosing (using a minimum of 8 characters, including at least three kinds of following categories: upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.

  • Page 30: Chapter 5 Remote Configuration Via Web

    VI-V400W Villa Door Station User Manual Chapter 5 Remote Configuration via Web 5.1 Login Web Browser You can log into the Web browser for device configuration. Steps 1. Enter the device IP address in the address bar of the web browser and press Enter to enter the login page.
  • Page 31 VI-V400W Villa Door Station User Manual Figure 5-1 Live View Function Descriptions: Select the image size when starting live view. Set the volume when starting live view. Note If you adjust the volume when starting two-way audio, you may hear a repeated sounds. You can capture image when starting live view.

  • Page 32: User Management

    VI-V400W Villa Door Station User Manual 5.4 User Management You can add, delete or search the information of the user. Click User to enter the settings page. Figure 5-2 User Management Click Add to add users. Enter the Employee ID, Name, Floor No. and Room No., Set the Start ●...

  • Page 33: Add Device

    VI-V400W Villa Door Station User Manual Figure 5-3 Device Management Add Device Click Add to add the indoor station or sub door station. Enter the parameters and click OK to ● add. Click Import. Enter the information of the device in the template to import devices in batch. ●...

  • Page 34: Local Parameters Settings

    VI-V400W Villa Door Station User Manual 5.6.1 Local Parameters Settings You can configure the parameters of the live view, record files and captured pictures. The record files and captured pictures are the ones you record and capture by using the web browser. You can also set and view the saving paths of the captured pictures and recorded videos on the PC that running the web browser.

  • Page 35: System Settings

    VI-V400W Villa Door Station User Manual Record File Parameters Record File Size Select the packed size of the manually recorded and downloaded video files to 256M, 512M or 1G. After the selection, the maximum record file size is the value you selected. Save record files to Set the saving path for the manually recorded video files.

  • Page 36: Maintenance

    VI-V400W Villa Door Station User Manual About Click System Settings → About and click Open Source Software Licenses to view the details. Maintenance Click Maintenance → Upgrade & Maintenance to enter the settings page. Figure 5-5 Maintenance Reboot: Click Reboot to reboot the device. ●...

  • Page 37: Security Service

    VI-V400W Villa Door Station User Manual Security Service Click Security → Security Service to enter the settings page. On the page, you can enable SSH according to your actual needs. Click Save to enable the settings. User Management Click User Management to enter the settings page. Administrator can edit the permission for the users.

  • Page 38: Network Settings

    VI-V400W Villa Door Station User Manual 5.6.3 Network Settings TCP/IP Settings TCP/IP settings must be properly configured before you operate the device over network. The device supports IPv4. Steps 1. Click Network → Basic Settings → TCP/IP to enter the settings page. Figure 5-7 TCP/IP Settings 2.

  • Page 39: Port Settings

    VI-V400W Villa Door Station User Manual - Check DHCP, the device will get the parameters automatically. - Set the IPv4 Address, IPv4 Subnet Mask and IPv4 Default Gateway manually. 3. Configure the corresponding DNS server parameters. 4. Click Save to enable the settings. Port Settings Steps 1.
  • Page 40 VI-V400W Villa Door Station User Manual SIP Setting Steps 1. Click Network → Basic Settings → SIP to enter the settings page. Figure 5-9 SIP Settings 2. Check Enable VOIP Gateway. 3. Configure the SIP parameters. 4. Click Save to enable the settings. FTP Settings Steps 1.
  • Page 41 VI-V400W Villa Door Station User Manual Figure 5-10 FTP Settings...

  • Page 42: Platform Access

    VI-V400W Villa Door Station User Manual 2. Check Enable FTP. 3. Select Server Type. 4. Input the Server IP Address and Port. 5. Configure the FTP Settings, and the user name and password are required for the server login. 6. Set the Directory Structure, Parent Directory and Child Directory. 7.
  • Page 43 VI-V400W Villa Door Station User Manual Figure 5-11 Video Parameters 2. Select the Stream Type. 3. Configure the video parameters. Stream Type Select the stream type to main stream or sub stream. Video Type Select the stream type to video stream, or video & audio composite stream. The audio signal will be recorded only when the Video Type is Video &...

  • Page 44: Audio Parameters

    VI-V400W Villa Door Station User Manual Set the frame rate. The frame rate is to describe the frequency at which the video stream is updated and it is measured by frames per second (fps). A higher frame rate is advantageous when there is movement in the video stream, as it maintains image quality throughout.

  • Page 45: Image Settings

    VI-V400W Villa Door Station User Manual Note Available range of volume: 0 to 10. 4. Click Save to save the settings. 5.6.5 Image Settings Display Settings Configure the image adjustment, backlight settings and other parameters in display settings. Steps 1. Click Image → Display Settings to enter the display settings page. Figure 5-13 Display Settings 2.
  • Page 46 VI-V400W Villa Door Station User Manual Saturation Saturation describes the colorfulness of the image color, which ranges from 1 to 100. Sharpness Sharpness describes the edge contrast of the image, which ranges from 1 to 100. 4. Set the Day/Night Mode. Figure 5-14 Day/Night Mode - Set Day Mode or Night Mode manually.

  • Page 47: Osd Settings

    VI-V400W Villa Door Station User Manual Figure 5-15 Backlight 1) Check the checkbox to enable BLC. 2) Select BLC Area. 6. Click Save to enable the settings. OSD Settings You can customize the camera name, time/date format, display mode, and OSD size displayed on the live view.

  • Page 48: Event Settings

    VI-V400W Villa Door Station User Manual 5. Select Cropping Resolution. 6. Click Save. Note You can select Cropping Resolution as 704*576, 1280*720, or 1920*1080. ● You can zoom in or zoom out the image by selecting Cropping Resolution after clicking Save. ●...
  • Page 49 VI-V400W Villa Door Station User Manual Figure 5-16 Motion Detection 2. Slide Enable Motion Detection to enable the function. 3. Click Draw Area. Click and drag the mouse on the live video to draw a motion detection area. Click Save to save the settings. Clear Area Click X to clear all of the areas.
  • Page 50 VI-V400W Villa Door Station User Manual 5. Click on the time bar and drag the mouse to select the time period. Click Save to save the settings. Delete Schedule Click Delete to delete the current arming schedule. 6. Click Linkage Method to enable the linkages. Notify Security Center Send an exception or alarm signal to the remote management software when an event occurs.
  • Page 51 VI-V400W Villa Door Station User Manual Figure 5-17 Event Linkage...

  • Page 52: Schedule Settings

    VI-V400W Villa Door Station User Manual 2. Select the Major Type as Device Event or Door Event. 3. Select the type of the Normal Linkage for the event. 4. Click Save to enable the settings. 5.6.7 Schedule Settings You can create call schedule, or else the device will call indoor station all day by default. Steps 1.

  • Page 53: Intercom Settings

    VI-V400W Villa Door Station User Manual Figure 5-19 Holiday Schedule 2) Click Add. 3) Set Start Time and End Time. 4) Select Call Type. 5) Drag mouse to set the schedule according to the actual needs. 6) Click OK. 7) You can edit or delete the schedule according to the actual needs. 8) Click Save.
  • Page 54 VI-V400W Villa Door Station User Manual Figure 5-20 Villa Door Station No. Settings 2. Select the device type from the drop-down list, and set the corresponding information including Building No., Floor No., Door Station No., Community No. and Unit No. Note When you select Doorphone as Device Type, only Community No., Building No.

  • Page 55: Time Parameters

    VI-V400W Villa Door Station User Manual 5. Click Save to enable the settings. Time Parameters Go to Intercom → Time Parameters to enter the page. Configure Max. Call Duration, Max. Message Duration, Max. Ring Duration, and click Save. Note Max. call duration between the module indoor station and client ranges from 90 s to 120 s. The ●...

  • Page 56: Access Control Settings

    VI-V400W Villa Door Station User Manual Number Settings Link the room No. and SIP numbers. Click Number Settings to enter the page. Figure 5-22 Number Settings Click Add, set the Room No. and SIP numbers in the pop-up dialog box. 5.6.9 Access Control Settings Door Parameters Steps...

  • Page 57: Elevator Control

    VI-V400W Villa Door Station User Manual Figure 5-23 Door Parameters 2. Select the door and edit the door name. 3. Edit Open Duration. 4. Set door contact status. 5. Click Save to enable the settings. Elevator Control Before You Start Make sure your door station is in the mode of main door station.
  • Page 58 VI-V400W Villa Door Station User Manual Figure 5-24 Elevator Control 2. Check to enable elevator control function. 3. Select an Elevator No., and select an elevator controller type for the elevator. 4. Set the Negative Floor. 5. Select the Interface Type as RS-485 or Network Interface. And enable the elevator control. - If you select RS-485, make sure you have connected the door station to the elevator controller with RS-485 wire.
  • Page 59 VI-V400W Villa Door Station User Manual Note Up to 4 elevator controllers can be connected to one door station. ● Up to 10 negative floors can be added. ● Make sure the interface types of elevator controllers, which are connected to the same door ●...

  • Page 60: Chapter 6 Configuration Via Client Software

    VI-V400W Villa Door Station User Manual Chapter 6 Configuration via Client Software 6.1 Device Management Device management includes device activation, adding device, editing device, and deleting device, and so on. After running the Guarding Vision, video intercom devices should be added to the client software for remote configuration and management.
  • Page 61 VI-V400W Villa Door Station User Manual Figure 6-1 Add to the Client...

  • Page 62: Add Device By Ip Address

    VI-V400W Villa Door Station User Manual 6.1.2 Add Device by IP Address Steps 1. Click +Add to pop up the adding devices dialog box. 2. Select IP/Domain as Adding Mode. 3. Enter corresponding information. 4. Click Add. 6.1.3 Add Device by IP Segment You can add many devices at once whose IP addresses are among the IP segment.

  • Page 63: Modify And Delete Organization

    VI-V400W Villa Door Station User Manual Note Up to 10 levels of organizations can be created. 6.3.2 Modify and Delete Organization You can select the added organization and click to modify its name. You can select an organization, and click X button to delete it. Note The lower-level organizations will be deleted as well if you delete an organization.

  • Page 64: Modify And Delete Person

    VI-V400W Villa Door Station User Manual Note The picture should be in *.jpg format. Click Upload Select the person picture from the local PC to upload it to the client. Click Take Phone Take the person's photo with the PC camera. Click Remote Collection Take the person's photo with the collection device.

  • Page 65: Import And Export Person Information

    VI-V400W Villa Door Station User Manual Steps 1. Select the person in the list and click Change Organization. 2. Select the organization to move the person to. 3. Click OK to save the settings. 6.4.4 Import and Export Person Information The person information can be imported and exported in batch.

  • Page 66: Issue Card In Batch

    VI-V400W Villa Door Station User Manual Note The person information, including person details, person's fingerprint information (if ● configured), and the linked card (if configured), will be imported to the selected organization. If the person name stored in the device is empty, the person name will be filled with the ●...
  • Page 67 VI-V400W Villa Door Station User Manual Figure 6-2 Issue Card in Batch 2. Click Settings.

  • Page 68: Video Intercom Settings

    VI-V400W Villa Door Station User Manual Figure 6-3 Card Settings 3. Select Card Type and Card No. Type. 4. Click OK to save the settings. Result After issuing the card to the person, the person and card information will display in the Person(s) with Card Issued list.

  • Page 69: Receive Call From Door Station

    VI-V400W Villa Door Station User Manual Note For the user with access control module permissions, the user can enter the Access Control module and manage video intercom and search information. You should add the device to the software and configure the person to link the device in Access Control module before your configuration remotely.

  • Page 70: Search Video Intercom Information

    VI-V400W Villa Door Station User Manual Steps 1. On the video intercom settings page, click Notice to enter the page. 2. Click +Add to pop up the adding dialog box. 3. Select the person according to your needs. 4. Edit the Subject, Type and Information. 5.
  • Page 71 VI-V400W Villa Door Station User Manual Figure 6-4 Search Call Logs 2. Set the search conditions, including call status, device type, start time and end time. Call Status Click ˅ to unfold the drop-down list and select the call status as Dialed, Received or Missed. Or select All to search logs with all statuses.

  • Page 72: Search Notice

    VI-V400W Villa Door Station User Manual Search Notice Steps 1. On the Video Intercom page, click Notice to enter the page. 2. Set the search conditions, including notice type, start time and end time. Type Select Advertising Information, Property Information, Alarm Information or Notice Information as Type according to your needs.

  • Page 73: Chapter 7 Video Intercom Operation

    VI-V400W Villa Door Station User Manual Chapter 7 Video Intercom Operation 7.1 Call Resident You can press the call button of the door station to call resident. Note Make sure you have added contacts to the device. ● Make sure you have configured the room No. for the call button. For more details. please refer ●...
  • Page 74 UD36150B...
  • Page 75 VI-H460W Network Indoor Station User Manual...
  • Page 76 VI-H460W Network Indoor Station User Manual Legal Information About this Document This Document includes instructions for using and managing the Product. Pictures, charts, ● images and all other information hereinafter are for description and explanation only. The information contained in the Document is subject to change, without notice, due to ●...
  • Page 77 VI-H460W Network Indoor Station User Manual PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS. YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY ● RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS;...
  • Page 78 VI-H460W Network Indoor Station User Manual Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Indicates a hazardous situation which, if not avoided, will or could Danger result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, could Caution result in equipment damage, data loss, performance degradation, or...
  • Page 79 VI-H460W Network Indoor Station User Manual Regulatory Information EU Conformity Statement This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the EMC Directive 2014/30/EU, RE Directive 2014/53/EU,the RoHS Directive 2011/65/EU 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union.
  • Page 80 VI-H460W Network Indoor Station User Manual Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité...
  • Page 81 VI-H460W Network Indoor Station User Manual Contents Chapter 1 Activation ........................1 1.1 Activate Indoor Station ......................1 1.2 Activate via Guarding Vision ....................2 Chapter 2 Configuration on Device ..................... 3 2.1 Quick Operation (For Normal Device) ..................3 2.2 Basic Settings .........................
  • Page 82 VI-H460W Network Indoor Station User Manual 2.8 Output Settings ........................29 2.9 Device Information ......................30 Chapter 3 Other Operations on Device ..................31 3.1 Leave Message ........................31 3.2 Call Settings .......................... 31 3.2.1 Add Contact ........................ 31 3.2.2 Call Resident ....................... 32 3.2.3 Call Indoor Extension/Indoor Station ................
  • Page 83 VI-H460W Network Indoor Station User Manual 4.5 Receive Call from Indoor Station/Door Station ..............65 4.6 View Live Video of Door Station and Outer Door Station ............ 66 4.7 View Call Logs ........................67 4.8 Release Notice ........................67 4.9 Search Video Intercom Information ..................70 4.9.1 Search Call Logs ......................

  • Page 84: Chapter 1 Activation

    VI-H460W Network Indoor Station User Manual Chapter 1 Activation 1.1 Activate Indoor Station You can configure and operate the indoor station after creating a password for the device activation. Steps 1. Power on the device. It will enter the activation page. Figure 1-1 Activation Page 2.

  • Page 85: Activate Via Guarding Vision

    VI-H460W Network Indoor Station User Manual 1.2 Activate via Guarding Vision You can only configure and operate the indoor station after creating a password for the device activation. Before You Start Default parameters of indoor station are as follows: Default IP Address: 192.0.0.64. ●...

  • Page 86: Chapter 2 Configuration On Device

    VI-H460W Network Indoor Station User Manual Chapter 2 Configuration on Device 2.1 Quick Operation (For Normal Device) After device activation, the wizard page will pop up. The description is for other indoor stations. Steps 1. Choose language and tap Next. Figure 2-1 Language Settings 2.
  • Page 87 VI-H460W Network Indoor Station User Manual Figure 2-2 Password Reset Methods 3. Set network parameters and tap Next. - Edit Local IP, Subnet Mask and Gateway parameters manually. - Enable Auto Get IP address, the device will get network parameters automatically. Figure 2-3 Network Parameters...
  • Page 88 VI-H460W Network Indoor Station User Manual 4. Configure the indoor station. 1) Select Device Type as Indoor Station or Indoor Extension. 2) Set Floor No.. 3) Set Room No.. 4) Configure advanced settings. Set Comminity No., Building No. and Unit No. 5) Set Registration Password.
  • Page 89 VI-H460W Network Indoor Station User Manual Figure 2-5 Wi-Fi 6. Set time and tap Next. 1) Select the Time Zone. 2) Tap Date Format and Time Format to set the time format. 3) Tap Time to set time manually. 4) Enable DST.Set the DST start time, end time and bias time.
  • Page 90 VI-H460W Network Indoor Station User Manual Figure 2-6 Time Settings 7. Configure the Hik-Connect service settings. 1) Enable Hik-Connect service. 2) Edit verification code or use the activation password by default. 3) View Hik-Connect Server Status. 4) Scan the first QR Code to download the APP of Hik-Connect. Scan the second QR Code to add your device to the APP.
  • Page 91 VI-H460W Network Indoor Station User Manual Figure 2-7 Guarding Vision Service Settings 8. Link related devices and tap Next. If the device and the indoor station are in the same LAN, the device will be displayed in the list. Tap the device or enter the serial No. to link. Figure 2-8 Related Device 1) Tap the door station in the list to link.

  • Page 92: Basic Settings

    VI-H460W Network Indoor Station User Manual Note If the door station is inactive, the system will pop up the dialog to activate the door station. 2) Edit the network parameters of the door station manually. 3) Tap Next. 9. Optional: Enable Indoor Station and link related indoor extension devices. Tap Finish. If the indoor extension and the indoor station are in the same LAN, the device will be displayed in the list.

  • Page 93: Set Indoor Station Network Parameters

    VI-H460W Network Indoor Station User Manual 2.2.1 Set Indoor Station Network Parameters Network connection is mandatory for the use of the indoor station. Set the network parameters after activating the indoor station. Only when the IP address of the indoor station is in the same network segment as other devices, it can work properly in the same system.

  • Page 94: Set Linked Device Ip

    VI-H460W Network Indoor Station User Manual 2.2.2 Set Linked Device IP Linked network parameters refers to the network parameters of devices (like door station, doorphone, main station, center, etc.), to which the indoor station is linked. Linked devices for the indoor station refers to door station, center, main station, and doorphone.

  • Page 95: Set Wi-Fi

    VI-H460W Network Indoor Station User Manual 3. Select a device to link. Edit the following parameters. Name You can edit the name of the device. Language Select a language from the drop-down list for the device. Network Enable Auto Get IP Address and the system will assign IP address, subnet mask, and gateway automatically.

  • Page 96: Set Indoor Station No

    VI-H460W Network Indoor Station User Manual Tap Settings → to enter the Wi-Fi Settings page. Enable Wi-Fi. Select a Wi-Fi from the list and enter the password of the Wi-Fi, and the indoor station can connect to the Wi-Fi. Figure 2-13 Wi-Fi Settings 2.2.4 Set Indoor Station No.

  • Page 97: Sip Settings

    VI-H460W Network Indoor Station User Manual Figure 2-14 Set Indoor Station No. 2. Select Indoor Station to set the room information, live view duration, SIP parameters and password. Room Information You can set room name, floor No., and room No. Tap Advanced Settings to set community No., building No.
  • Page 98 VI-H460W Network Indoor Station User Manual Room Information You can set room name and No. Tap Advanced to set the community No., building No., and unit No. if you need. When calling the indoor station and the two devices are in the same building, you can call the room No.

  • Page 99: Add Camera

    VI-H460W Network Indoor Station User Manual 3. Set SIP registration password. 1) Tap Registration Password. 2) Create a new SIP registration password and confirm the password. 3) Tap OK. 4. Optional: Enable Compatible with SIP 1.0 Indoor Station and the indoor station (SIP 2.0) can be compatible with SIP 1.0 indoor station.

  • Page 100: Zone And Alarm Settings

    VI-H460W Network Indoor Station User Manual Enter the device name, IP address, user name and the password of the camera. Edit port No. and channel No. Exit the page to save the settings. - Select Open Network Video Interface to add the camera. Enter the device name, IP address, user name and the password of the camera.
  • Page 101 VI-H460W Network Indoor Station User Manual 2. Press a zone to pop up the zone editing dialogue box. 3. Set the zone type, alarm type, status of arming status, entering delay, and exiting delay. 4. Tap OK to save the settings. Note 7 zone types are selectable: Panic Button, Door Magnetic, Smoke Detector, Active Infrared, ●...

  • Page 102: Password Settings

    VI-H460W Network Indoor Station User Manual Figure 2-18 Arming Mode Settings 3. Arm the selected zone. Note Zones are configurable on the arming mode page. ● 24H alarm zone including smoke detector zone and gas detector zone will be triggered even if ●...

  • Page 103: Security Settings

    VI-H460W Network Indoor Station User Manual Steps 1. Tap Settings → → Configuration , to enter the Admin Password page. 2. Tap Forgot Password. 3. Download the APP of Guarding Vision and run Guarding Vision client software. 4. Scan the QR code via Guarding Vision. 5.
  • Page 104 VI-H460W Network Indoor Station User Manual Figure 2-19 Arm/Disarm Password Settings 2. Create the indoor station's arm/disarm password. You should enter the arm/disarm password to enable or disable the function. Figure 2-20 Create Password...

  • Page 105: Modify Unlock/Duress Code

    VI-H460W Network Indoor Station User Manual 3. When you slide to disable Scene Password, there is no needs to enter password during scene mode switching. 2.3.4 Modify Unlock/Duress Code You can create and edit the duress code and unlock password of the indoor station. Steps 1.

  • Page 106: Synchronize Time

    VI-H460W Network Indoor Station User Manual 2.4 Synchronize Time Steps 1. Tap Settings → → Time and Date to enter the time synchronization page. 2. Tap Date Format and Time Format to set the time format. 3. Optional: Tap Time to set time manually. 4.

  • Page 107: Call Settings

    VI-H460W Network Indoor Station User Manual 2.5.1 Call Settings You can set the ringtone, ring duration, call forwarding time on call settings page. Steps 1. Tap Settings → to enter the call settings page. Figure 2-23 Call Settings 2. Set corresponding parameters. Ringtone There are 3 ringtones by default, and you can custom and import at most 4 ringtones via Batch Configuration Tool or Guarding Version Client Software.
  • Page 108 VI-H460W Network Indoor Station User Manual Auto-answer Enable Auto-answer. After enabling, the call from door station/villa door station will be answered by the indoor station automatically. The caller from door station/villa door station can leave voice messages. After the message is left, you can check it from Message on the main page of the device.

  • Page 109: Volume Settings

    VI-H460W Network Indoor Station User Manual Note Indoor extension does not support the ring duration settings, call forwarding settings, or auto- answer function. 2.5.2 Volume Settings Set the microphone volume, prompt sound volume, call volume, and enable touch sound. Steps 1.

  • Page 110: Unlink The Account

    VI-H460W Network Indoor Station User Manual 2.6.2 Unlink the Account Remove the account from the mobile client. Steps 1. Tap Settings → → Configuration , and enter the admin (activation) password. 2. Tap to enter the system maintenance page. 3. Tap Unlink App Account, and follow the steps on the page. 2.7 System Settings You can format or install TF card, clear the screen, view the version information of the indoor station and reboot the system on the settings page.

  • Page 111: System Maintenance

    VI-H460W Network Indoor Station User Manual Note Make sure your device is connected with the network or the NTP function will not available. ● For details, see Synchronize Time . ● System Language Tap System Language to change the system language. Note The indoor station supports 19 languages.

  • Page 112: Output Settings

    VI-H460W Network Indoor Station User Manual Tap Restore All to restore all parameters to factory settings and the system will reboot automatically. Wizard Tap Wizard and set the language, network, indoor station type, device No., and select a device according to the wizard. Refers to Quick Operation (For Normal Device) for the details. Preference Tap Settings →...

  • Page 113: Device Information

    VI-H460W Network Indoor Station User Manual You can change the relay's name. Note 1 to 32 characters are allowed. Supports uppercase letters, lowercase letters, numerics, and special characters. Remain Open Enable the function, the relay remains open. Disabled the function, and you can set the remain open duration. Note By default, the function is disabled.

  • Page 114: Chapter 3 Other Operations On Device

    VI-H460W Network Indoor Station User Manual Chapter 3 Other Operations on Device 3.1 Leave Message You can set leave message, and view the messages. Tap Settings → → Shortcut Settings , and enable Leave Message. Set Leave Message Time as 1 day, 7 days or 30 days. Tap Message →...

  • Page 115: Call Resident

    VI-H460W Network Indoor Station User Manual 3. Enter contact information. If you adopt private SIP protocol, enter the contact name and the room No. ● If you adopt standard SIP protocol, enter the contact name and the phone number of VOIP ●...

  • Page 116: Call Indoor Extension/Indoor Station

    VI-H460W Network Indoor Station User Manual Note Community No., building No., and unit No. can be omitted if there is no such information. ○ If there are two indoor stations that are in the same building, and should call each other, ○...

  • Page 117: Live View

    VI-H460W Network Indoor Station User Manual Figure 3-3 Call Logs 2. Tap a piece of call logs in the list to call back. Note Indoor extension does not support this function. ● The indoor station saves call logs from door station, outer door station, management center ●...

  • Page 118: Arming Mode Settings

    VI-H460W Network Indoor Station User Manual Figure 3-4 Live View 2. Tap to enter the live view page of door station. Note On the Call from Door Station page, there are 2 unlock buttons: Unlock 1, and Unlock 2. When ●...

  • Page 119: Arm/Disarm

    VI-H460W Network Indoor Station User Manual 1. Back to the home page, tap Settings → → Scene Settings to enter the arming mode settings page. 2. Tap Stay Mode, Away Mode, Sleeping Mode, or Custom to enter the page. Figure 3-5 Arming Mode Settings 3.

  • Page 120: Arm Room

    VI-H460W Network Indoor Station User Manual 3.5.1 Arm Room Steps 1. Tap → One-Push to Arm to enable the scene. 2. Tap to enter the scene page. Figure 3-6 Arm Settings page 3. Select Stay, Away, Sleeping or Custom. 4. Enter the arm/disarm password to enable the scene. 5.

  • Page 121: Call Elevator

    VI-H460W Network Indoor Station User Manual Figure 3-7 Disarm Room 2. Enter the arm/disarm password. 3. Tap OK. 3.6 Call Elevator The indoor station supports calling the elevator. Before You Start Enable call elevator via Guarding Vision Client Software. Steps 1.

  • Page 122: Relay Settings

    VI-H460W Network Indoor Station User Manual Figure 3-8 Call Elevator 2. Tap on the home page of the indoor station to start calling the elevator. 3. When the device communicates with door station, tap unlock icon to start calling the elevator. 3.7 Relay Settings After you set the output parameters and display the relay button on the main page, you can control the relay manually.
  • Page 123 VI-H460W Network Indoor Station User Manual Figure 3-9 Alarm Logs Delete a Log: Hold the item, you can delete it. Clear Logs: Hold the item, you can clear all logs. See Details: Hold a alarm log, you can see the alarm details. Note Indoor extension only supports alarm log and capture log.

  • Page 124: Chapter 4 Remote Operation Via Client Software

    VI-H460W Network Indoor Station User Manual Chapter 4 Remote Operation via Client Software 4.1 Device Management Device management includes device activation, adding device, editing device, and deleting device, and so on. After running the Guarding Version, video intercom devices should be added to the client software for remote configuration and management.
  • Page 125 VI-H460W Network Indoor Station User Manual Figure 4-1 Add the Device 4. Optional: Click Online Device, the active online devices in the same local subnet with the client software will be displayed on the Online Device area.

  • Page 126: Modify Network Information

    VI-H460W Network Indoor Station User Manual Note To add online devices to the software, you are required to change the device IP address to the same subnet with your computer first. 1) You can click Refresh Every 60s to refresh the information of the online devices. 2) Select the devices to be added from the list.

  • Page 127: System Configuration

    VI-H460W Network Indoor Station User Manual Note You should enter the admin password of the device in the Password field of the pop-up window to modify the parameters. 4.2 System Configuration You can configure the video intercom parameters accordingly. Steps 1.
  • Page 128 VI-H460W Network Indoor Station User Manual Device Information Click Device Information to enter device basic information page. You can view basic information (the device type, and serial No.), and version information of the device. Figure 4-2 Device Information General Click General to enter device general parameters settings page. You can view and edit the device name and device ID, and select overwrite record file.
  • Page 129 VI-H460W Network Indoor Station User Manual Figure 4-4 Time Settings Page Select Time Zone, Enable NTP, Enable DST, or SDK Synchronization. Click Save to save the time settings. Time Zone: Select a time zone from the drop-down list menu. ● NTP: Click Enable NTP, and enter the server address, NTP port, and synchronization interval.
  • Page 130 VI-H460W Network Indoor Station User Manual Figure 4-5 System Maintenance Reboot: Click Reboot and the system reboot dialog box pops up. Click Yes to reboot the system. ● Restore Default Settings: Click Restore Default Settings to restore the default parameters. All ●...
  • Page 131 VI-H460W Network Indoor Station User Manual Note The device supports 19 languages: English, French, Brazilian Portuguese, Spanish, Russian, ○ German, Italian, Polish, Arabic, Turkish, Vietnamese, Ukrainian, Hungarian, Dutch, Romanian, Czech, Bulgarian, Croatian, Serbian. Rebooting the device is required after you change the system language. ○...
  • Page 132 VI-H460W Network Indoor Station User Manual RS-485 Click RS485 to enter the RS-485 settings page. You can view and edit the RS-485 parameters of the device. Figure 4-7 RS-485 Settings Note For indoor station and main station, there are 3 choices for the working mode: transparent channel, disable, and custom.

  • Page 133: Video Intercom

    VI-H460W Network Indoor Station User Manual Figure 4-8 Security 4.3.2 Video Intercom Click Video Intercom on the remote configuration page to enter the video intercom parameters settings: Time Parameters, Password, Zone Configuration, IP Camera Information, Volume Input and Output Configuration, Ring, Arming Information, Calling Linkage, Relay, and SIP No. Time Parameters Steps 1.

  • Page 134: Permission Password

    VI-H460W Network Indoor Station User Manual Figure 4-9 Time Parameters 2. Configure the calling duration, live view duration, call forwarding time, and the ringtone duration. 3. Click Save. Note Calling duration is the maximum duration of indoor station when it is called without being ●...

  • Page 135: Zone Alarm

    VI-H460W Network Indoor Station User Manual Figure 4-10 Permission Password For indoor station, you can change the arm/disarm password. Zone Alarm Steps 1. Click Zone Alarm to enter the zone settings page.
  • Page 136 VI-H460W Network Indoor Station User Manual Figure 4-11 Zone Alarm 2. Select Area No. 3. Select Zone Type from the drop-down list. 4. Select Alarm Type from the drop-down list. 5. Set the NO/NC status. 6. Set Entering Delay and Exiting Delay. 7.

  • Page 137: Export And Import Added Device Information

    VI-H460W Network Indoor Station User Manual When the zone type is set to be 24H Alarm, the indoor station will receive alarm message ● when the detector is triggered no matter it is under arming mode or disarming mode. When the zone type is set to be Delay Alarm, only under arming mode, the indoor station will ●...
  • Page 138 VI-H460W Network Indoor Station User Manual Figure 4-13 Import Added Device Information Volume Settings Steps 1. Click Volume Input/Output to enter the configuring the volume input or output page.

  • Page 139: Ring Import

    VI-H460W Network Indoor Station User Manual Figure 4-14 Volume Input or Output 2. Slide the slider to adjust the input volume, output volume and speak volume. 3. Click Save to enable the settings. Ring Import Steps 1. Click Ring Import to enter the ring configuration page. Figure 4-15 Ring Import 2.
  • Page 140 VI-H460W Network Indoor Station User Manual Note The ring to be imported should be in the wav format, and the size of the ring cannot be larger ● than 300k. Up to 4 rings can be added. ● Arming Information Click Arming Information to enter the configuring arming informaton page and view the arming information.
  • Page 141 VI-H460W Network Indoor Station User Manual Figure 4-17 Extension Settings 2. Click Add.
  • Page 142 VI-H460W Network Indoor Station User Manual Figure 4-18 Add SIP Info 3. Select Device Type as Indoor Extension.

  • Page 143: Network

    VI-H460W Network Indoor Station User Manual 4. Enter the required information. Serial No. Enter the device's serial No.. The serial No. is on the rear panel of the device (A fixed-length number with 9 digits). IP Address Enter the device's IP address. Gateway Enter the device's gateway.

  • Page 144: Sip Server Configuration

    VI-H460W Network Indoor Station User Manual Figure 4-19 Local Network Configuration 2. Enter the Local IP Address, IP Address Subnet Mask, Gateway, Port No. and HTTP Port No. 3. Click Save to enable the settings. Note The default port No. is 8000. ●...
  • Page 145 VI-H460W Network Indoor Station User Manual Figure 4-20 SIP Server Configuration 2. Click Enable. 3. Set the parameters according to your needs. Note Up to 32 characters are allowed in the Register User Name field. ● Registration password should be 1 to 16 characters in length. ●...
  • Page 146 VI-H460W Network Indoor Station User Manual Figure 4-21 DNS Settings Configure Mobile Client Connection Configure Guarding Vision server parameters before viewing videos via mobile client. Before You Start Make sure the indoor station connects to the network. Steps 1. Click Guarding Vision to enter the configuring the settings page. 2.

  • Page 147: Call Indoor Station Via Client Software

    VI-H460W Network Indoor Station User Manual Figure 4-22 Group Network Settings Device No. Settings Select the device type from the drop-down list, and set the corresponding information. Note Device type can be set as indoor station or indoor extension. ● When you select indoor extension as device type, the device No.

  • Page 148: Receive Call From Indoor Station/Door Station

    VI-H460W Network Indoor Station User Manual Figure 4-23 Calling Indoor Station 3. After answered, you will enter the In Call window. Click to adjust the volume of the loudspeaker. ● Click Hang Up to hang up. ● Click to adjust the volume of the microphone. ●...

  • Page 149: View Live Video Of Door Station And Outer Door Station

    VI-H460W Network Indoor Station User Manual Figure 4-24 Incoming Call from Indoor Station 2. Click Answer to answer the call. Or click Hang Up to decline the call. 3. After you answer the call, you will enter the In Call window. Click to adjust the volume of the loudspeaker.

  • Page 150: View Call Logs

    VI-H460W Network Indoor Station User Manual 4.7 View Call Logs You can check all the call logs, including dialed call logs, received call logs and missed call logs. You can also directly dial via the log list and clear the logs. Steps 1.
  • Page 151 VI-H460W Network Indoor Station User Manual Figure 4-26 Release Notice 3. Click Add on the left panel to create a new notice.
  • Page 152 VI-H460W Network Indoor Station User Manual Figure 4-27 Create a Notice 4. Edit the notice on the right panel. 1) Click ... on the Send To field to pop up the Select Resident dialog. 2) Check the checkbox(es) to select the resident(s). Or you can check the All checkbox to select all the added residents.

  • Page 153: Search Video Intercom Information

    VI-H460W Network Indoor Station User Manual 5) Click in the Type field to unfold the drop-down list and select the notice type. 6) Optional: Click View to add a local picture to the notice. Note Up to 6 pictures in the JPGE format can be added to one notice. And the maximum size of one picture is 512KB.
  • Page 154 VI-H460W Network Indoor Station User Manual Figure 4-28 Search Call Logs 3. Set the search conditions, including call status, device type, start time and end time. Call Status Click to unfold the drop-down list and select the call status as Dialed, Received or Missed. Or select All to search logs with all statuses.

  • Page 155: Search Notice

    VI-H460W Network Indoor Station User Manual 4.9.2 Search Notice Steps 1. On the main page, click Access Control → Video Intercom to enter the Video Intercom page. 2. Click Notice to enter the Notice page. Figure 4-29 Search Notice 3. Set the search conditions, including notice type, subject, recipient, start time and end time. Recipient Input the recipient information in the Recipient field to search the specified notice.
  • Page 156 VI-H460W Network Indoor Station User Manual 6. You can view and edit the notice details, check the sending failed/sent succeeded/unread users, and resend the notice to sending failed/unread users. 7. Optional: Click Export to export the notices to your PC.
  • Page 157 UD36151B...

Table of Contents
