Technical Support and E-Warranty Certificate www.vevor.com/support
UNDER SEAT CAR SUBWOOFER
USER MANUAL
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YL-802C and is the answer not in the manual?

Questions and answers

Related Manuals for VEVOR YL-802C

Summary of Contents for VEVOR YL-802C

  • Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support UNDER SEAT CAR SUBWOOFER USER MANUAL We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
  • Page 2 This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.
  • Page 3 WARNING: Read and understand this entire manual before operating or servicing this product. Failure to follow these warnings and instructions can cause personal injury or damage to valuable property. FCC Information: CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment! This device complies with Part 15 of the FCC Rules.

  • Page 4: Safety Warning

    CORERECT DISPOSAL This product is subject to the provision of European Directive 2012/19/EC. The symbol showing a wheelie bin crossed through indicates that the product requires separate refuse collection in the European Union. This applies to the product and all accessories marked with this symbol.

  • Page 5: Mounting Locations

    1. Be sure to carefully read and understand the instructions before attempting to install the unit. 2. For safety, disconnect the negative lead from the battery prior to beginning the installation. 3. For easier assembly, we suggest you run all wires prior to mounting your unit in place.

  • Page 6: Battery And Charging

     leads, sensitive equipment or harnesses. The power wires carry substantial current and could induce noise into the audio system. SPECIFICATIONS Signal-to-noise Frequency Model RMS power Subwoofer ratio response YL-802C 120W 50-150Hz 8” >90% YL-803C 150W >90% 50-150Hz 8” YL-805C 200W >90%...

  • Page 7: Panel Controls And Features

    YL-1013 200W >90% 50-150Hz 10” YL-106Z 220W >90% 50-150Hz 10” PANEL CONTROLS AND FEATURES A. POWER STATUS LED This bio-color LED glows green when power is on and no problems are present. If one of the protection circuit comes on, it will change to red. B.
  • Page 8 D. LOW PASS FILTER This control permits you adjust the frequency range you want the subwoofer amplifier to receive. The subwoofer will reproduce all sound BELOW the frequency you set. Note: The low pass filter frequency can be higher or lower than the standard. There have +/-20% tolerance.

  • Page 9: Installation

    H. HIGH LEVEL (speaker low)INPUTS If your head unit does not have RCA outputs you can use the speaker outputs for the audio source for the subwoofer. Use the supplied cable and wire harness and connect the outputs properly as shown in the connection diagram in this manual I.

  • Page 10: Connect To The Power

    NOTE: In this connection, the AUTO TURN OFF switch is in the ON position. Fig 2.1 NOTE: In this connection, the AUTO TURN OFF switch is in the OFF position. Fig 2.2 2.1 Connect to the power 2.1.1) Trim the RED wire (power cable) within 18" of the battery. Strip 1/2" from the battery end of the power cable and crimp an appropriate size ring terminal to the cable.
  • Page 11 2.1.2) Other end insert a inline fuse holder and tighten the setscrew to secure the cable in place. Fig 2.1.2 The FUSE connection NOTE: The power cable MUST be fused 18" or less from the vehicle's battery. Install the fuse holder under the hood and ensure connections are watertight.

  • Page 12: Remote Level Control Connection

    Fig 2.2.1 2.2.2) Prepare the chassis ground by scraping any paint from the metal surface and thoroughly clean the area of all dirt and grease. Strip the other end of the wire and attach a ring connector. Fasten the cable to the chassis using a non-anodized screw and a star washer.
  • Page 13 4. Remote amplifier power switch wiring 4.1) Prepare the Remote turn-on wire (Blue) for attachment to the amplifier by stripping 1/2” of insulation from the end of the wire. 4.2) Insert the bared wire into the REM terminal of the power connector and tighten the set screw to secure the wire in place.
  • Page 14 Scenario 2: High level to low level wiring In the case of receiver without RCA output. When your receiver does not have RCA output, first use the high signal to low signal converter to convert the signal. Black Gray Blue White &...
  • Page 15 The overall wiring diagram is as follows Fig 5.2.2 Scenario 3: High Level Input Wiring In the case of receiver without RCA output , and directly using a high level input. The high level input(s) should only be used when your receiver lacks RCA outputs. If the RCA outputs are not present, connect the speaker outputs from the receiver to the high level input connector of the amplifier.
  • Page 16 Fig 5.3 - 15 -...

  • Page 17: Package Contents

    PACKAGE CONTENTS 1. Power cable*1 2. Fuse*1 3. Ground cable*1 5. high signal to low signal 6. High Level Input 4. RCA cable*1 converter*1 cable*1 8. Remote Level 7. ACC cable*1 9. Tapping screw*4 Control*1 12. Forked 10. Cross recessed 11.

  • Page 18: Troubleshooting

    Trouble Shooting If you experience operation or performance problems with this product, compare your installation with the electrical wiring diagram on the previous pages . If problems, please read the following trouble shooting tips which may help eliminate the problems. Symptom Possible Remedy Check to make sure you have a good ground connection.
  • Page 19 Disconnect all RCA inputs to the power sub's control panel. If the hiss disappears, then plug in the component driving the amplifier and unplug its inputs. If the hiss disappears at this High hiss in the point, go on until the faulty noisy component is found.It is best sound to set the amplifier's input level control as low as possible.
  • Page 20 Technical Support and E-Warranty Certificate www.vevor.com/support...
  • Page 21 QUICK OPERATION INSTALLATION GUIDE Battery 1. The RCA connects to the left and right audio 1. The positive electrode of the power supply is output of the host. connected to the positive electrode of the battery, 2. If the original car host does not have RCA connect the fuse within 18".

  • Page 22: Parts List

    Parts list 1.Power cable*1 2.Fuse*1 3.Ground cable*1 4.RCA cable*1 5.high signal to low signal 6.High Level Input cable*1 converter*1 7.ACC cable*1 8.Remote Level Control*1 9.Tapping screw*4 10.Cross recessed round 11.Fixed support*4 12.Forked cold-pressed head screws*8 terminal*2 13.Round cold-pressed 14.Insulating sleeve 15.subwoofer terminal*2 16.Manual...
  • Page 23 Scenario 2: High level to low level wiring In the case of receiver without RCA output. high signal to low signal converter Use the high signal to low signal converter to convert the high level signal to the low level signal output.Then you can connect cables according to scenario 1. Scenario 3: High Level Input Wiring In the case of receiver without RCA output , and directly using a...
  • Page 24 K1 K3 B. PHASE SWITCH C.AUTO POWER ON D.LOW PASS FILTER E.BASS BOOST F.INPUT GAIN CONTROL G.REMOTE LEVEL CONTROL F.HIGH LEVELINPUTS I.LOW LEVEL RCA INPUTS J.FUSE K1. POWER +12V K2. GROUND K3. REM Setting precautions: D: Set it to 50 E:Set it to 0-5 F:Do not exceed 50%...
