OWNER'S MANUAL
WASHING MACHINE
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
WT19VSB/ WT19DSB/ WT19SSB/ WT19WSB/ WT19RSB/ WT19MBB/ WT18WSB/
WT18SSB/ WT18MBB/ WT17DSB/ WT17WSB
MFL68780963
Rev.03_061322
Copyright © 2019-2022 LG Electronics Inc. All Rights Reserved.
www.lg.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for LG WT19RSB
Summary of Contents for LG WT19RSB
- Page 1 Leave these instructions near the product after installation for future reference. ENGLISH WT19VSB/ WT19DSB/ WT19SSB/ WT19WSB/ WT19RSB/ WT19MBB/ WT18WSB/ WT18SSB/ WT18MBB/ WT17DSB/ WT17WSB www.lg.com MFL68780963 Rev.03_061322 Copyright © 2019-2022 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
Preparing the Wash Load ................15 Adding Detergents, Softeners and Bleaches..........17 Control Panel ....................19 Programme Table ....................20 Extra Options and Functions ................23 SMART FUNCTIONS LG ThinQ Application ..................26 Smart Diagnosis ....................26 MAINTENANCE Cleaning after Every Wash ................27 Cleaning the Appliance Periodically ..............27 TROUBLESHOOTING... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. Safety Messages This symbol is displayed to indicate matters and operations that can cause risk. - Page 4 WT19VSB/ WT19DSB/ WT19SSB/ WT18WSB/ WT17DSB/ WT19WSB/ WT18SSB/ WT18MBB WT17WSB WT19RSB/ WT19MBB 19 kg 18 kg 17 kg Installation • Never attempt to operate the appliance if it is damaged, malfunctioning, partially disassembled, or has missing or broken parts, including a damaged cord or plug.
- Page 5 SAFETY INSTRUCTIONS to weathering conditions such as direct sunlight, wind, rain, or temperatures below freezing. • Make sure the power plug is completely pushed into the power outlet. • Do not plug the appliance into multiple outlet sockets or an extension power cable.
- Page 6 • In case of a water leak from the appliance, disconnect the power plug and contact the LG Electronics customer information centre. • Turn off water taps to relieve pressure on hoses and valves and to minimize leakage if a break or rupture should occur.
- Page 7 • Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the appliance in a different location.
- Page 8 SAFETY INSTRUCTIONS • Remove the door before disposing of or discarding this appliance to avoid the danger of children or small animals getting trapped inside.
-
Page 9: Installation Parts And Specifications
*1 The included accessories vary depending on the model you purchased. *2 This accessory is not included in the product, but you can purchase it from the LG service centre. Cold and Hot Water Inlet Hoses Drain Hose Anti-Rat Cover... -
Page 10: Specifications
INSTALLATION Specifications WT19VSB/ WT19DSB/ WT19SSB/ WT19WSB/ WT19RSB/ WT19MBB/ Model WT18WSB/ WT18SSB/ WT18MBB/ WT17DSB/ WT17WSB Power Supply 120 V~, 60 Hz Product Weight Approx. 44,5 kg Rate Input 500 W Dimension(mm) D’ H’ 1 020 1 370... -
Page 11: Installation Place Requirements
Contact your local 2 cm 2 cm 10 cm authorised LG repairer. • The power plug must be plugged into an WARNING appropriate outlet socket that is installed and • This appliance must only be used for domestic... -
Page 12: Connecting The Water Inlet Hoses
INSTALLATION Connecting the Water Inlet Connecting the Hose to the Water Tap Hoses Connecting Screw-Type Hose to Tap with Thread Before connecting the water inlet hose to the water Screw the hose connector onto the water supply tap, check the hose fitting type and follow the tap. -
Page 13: Installing The Drain Hose
INSTALLATION Installing the Drain Hose Levelling the Appliance Before connecting the drain hose, check your drain Checking the Level hose model and follow the instructions for that model. Levelling the appliance prevents unnecessary noise and vibration. Check whether the appliance is Installing the Drain Hose with perfectly level after installation. - Page 14 INSTALLATION Assembling the Anti-Rat Cover You can insert the anti-rat cover according to the type to protect the appliance from the rat. Lay the appliance backwards. CAUTION • Be careful your feet or hands when you lay or raise the appliance. Insert the anti-rat cover to the assembling bracket from the back of the appliance.
-
Page 15: Operation Operation Overview
OPERATION OPERATION Operation Overview End of cycle. • When the cycle is finished, a melody will sound. Immediately remove your clothing Using the Appliance from the appliance to reduce wrinkling. Before the first wash, select the Normal programme and add a half amount of detergent. NOTE Start the appliance without clothes. - Page 16 OPERATION Checking the Fabric Care Label cause irreparable damage to both your appliance and clothes. This will tell you about the fabric content of your clothes and how it should be washed. Symbols on the Care Labels Symbol Wash / Fabric type •...
-
Page 17: Adding Detergents, Softeners And Bleaches
OPERATION Adding Detergents, CAUTION Softeners and Bleaches • Using liquid detergent without diluting, or leaving laundry for a long time after pouring Detergent Dosage diluted liquid detergent into the drum might cause the clothes to be damaged, bleached, • Detergent should be selected according to fabric discoloured. - Page 18 OPERATION Adding Fabric Softeners bleach dispenser . Avoid splashing or overfilling. Add a fabric softener to the maximum fill line. • If the softener is concentrated, then it should be diluted. • Mix powdered bleach with water to a liquid consistency and pour it into the bleach •...
-
Page 19: Control Panel
OPERATION Control Panel Control Panel Features ENCENDIDO/APAGADO Button • Press this button to turn on or off the appliance. • The appliance automatically turns off once a certain time has passed after the wash has completed. INICIO/PAUSA Button • Press this button to start or pause a wash cycle. •... -
Page 20: Programme Table
OPERATION - If the display shows , then the time will be displayed after the load sensing has detected the -:-- laundry size. - The time shown is only an estimate. Several external factors (laundry size, room temperature, incoming water temperature, etc.) can affect the actual time. •... - Page 21 OPERATION Edredones Description Use this programme to wash a blanket or bedclothes that have the hand wash sign on the care label. • Cashmere bedclothes, acrylic blanket, mixed spinning blanket, woollen blanket, infilling (polyester 101), and bed sheets might be damaged if they are allowed to float.
- Page 22 OPERATION Lavado Rápido Description Use this programme to wash lightly soiled clothes for a short time. • This programme's recommended laundry amount is under 3 kg. Limpieza Extra Description Use this programme to increase rinsing performance. • This programme is recommended for underwear and baby clothes. •...
-
Page 23: Extra Options And Functions
OPERATION Extra Options and • When the Enjuague option is selected, icon is lit. Functions • If selecting the maximum number of rinses, then this option is deactivated. You can use the extra options and functions on some programmes to customize the cycle. NOTE Customising a Washing •... - Page 24 OPERATION Press the INICIO/PAUSA button. Press and hold the Temp. and Enjuague buttons simultaneously for 3 seconds to activate this function. NOTE • This function is the time to the end of the Unlocking the Control Panel programme, not the start. The actual running time may vary due to water temperature, wash Turn on the power.
-
Page 25: Manual Washing
OPERATION Manual Washing When you need a rinse and spin, spin only, rinse only or wash only cycle, these can be set manually. Rinse and Spin Spin only Rinse only Wash only Press the ENCENDIDO/APAGADO button. Press the Press the Enjuague Press the Enjuague Press the Lavado Centrifugado... -
Page 26: Smart Functions
Using Audible Diagnosis to Diagnose Issues Follow the instructions below to use the audible diagnosis method. • Launch the LG ThinQ application and select the Smart Diagnosis feature in the menu. Follow the instructions for audible diagnosis provided in the LG ThinQ application. -
Page 27: Maintenance
MAINTENANCE MAINTENANCE WARNING • Unplug the appliance before cleaning to avoid the risk of electric shock. Failure to follow this warning may result in serious injury, fire, electric shock, or death. • Never use harsh chemicals, abrasive cleaners, or solvents to clean the appliance. They may damage the finish. -
Page 28: Cleaning The Water Inlet Filter
MAINTENANCE Cleaning the Water Inlet Filter NOTE Water inlet filter collects lime or any small objects • For models without a lint filter, the lint is that may be in water supplied to the appliance. discharged when the water drains during Clean the water inlet filter regularly. -
Page 29: Cleaning The Drain Pump Filter
MAINTENANCE • Be careful not to get your fingernails caught in Close the lid and then insert the lower part of the filter when you handle the filter. the filter into the wash drum. Press the top of the filter until you hear a click sound. •... - Page 30 MAINTENANCE Remove any foreign objects and fluff inside pump casing and from the filter. Insert the filter along the guide ribs inside the pump casing and turn the cap clockwise to refit the cap. • Securely turn the cap clockwise until it is tight.
-
Page 31: Troubleshooting
You can remedy most of the problems by yourself, consequently save time and money, since you do not need to call LG Electronics service centre. The following table should assist you by troubleshooting. - Page 32 TROUBLESHOOTING Symptoms Possible Cause & Solution Foreign objects, such as coins, pins, clips, etc.,are caught between the pulsator and the inner drum. FOREIGN OBJECTS ERROR • Turn off the appliance and then press the ENCENDIDO/APAGADO button. Press the Centrifugado button without selecting a cycle to drain and spin the laundry.
- Page 33 TROUBLESHOOTING Symptoms Possible Cause & Solution A motor error has occurred. DRAIN MOTOR ERROR • Unplug the appliance and call for service. is not an error. This prevents children from changing cycles or operating the appliance. CHILD LOCK FUNCTION • Turn off the Bloqueo infantil function in the control panel. Noises Symptoms Possible Cause &...
- Page 34 TROUBLESHOOTING Symptoms Possible Cause & Solution Appliance will not Water supply is turned off. operate. • Turn on the water supply tap completely. Controls are not set properly. • Make sure the cycle is correctly set. Close the door and press the INICIO/ PAUSA button.
- Page 35 TROUBLESHOOTING Symptoms Possible Cause & Solution Water leaking Drain hose has come out of drain or is not inserted far enough. • Tie drain hose to supply hose or standpipe to prevent it from coming out during drain. For smaller drain pipes, insert the drain hose into the pipe as far as the drain hose flange.
- Page 36 TROUBLESHOOTING Symptoms Possible Cause & Solution Poor stain removal Previously set stains. • Items that have previously been washed may have stains that have been set. These stains may be difficult to remove and may require hand washing or pretreating to aid in stain removal. Staining Bleach or softener dispensed too soon.
- Page 37 Memo...
- Page 38 Memo...
- Page 39 Memo...
