- Page 1 INOVA-E20 | INOVA-DE20 USER MANUAL This document includes important tips to prolong the life of your filters and get the most out of your new air purifier.
-
Page 2: Table Of Contents
Contents Introducing your INOVA system Important safety instructions How the INOVA Air Purifier works Positioning the INOVA Air Purifier INOVA-E20 System operation INOVA-DE20 System operation INOVA-DE20 Digital Controller Tips for getting the most out of your system Accessing the filters... -
Page 3: Introducing Your Inova System
Introducing your INOVA system. Standard system and filters The INOVA system box will contain the air purifier with the HEPA filter and pre-filter pre-installed inside as well as a power cable and this instruction manual. Air Purifier *INOVA-DE20 pictured HEPA FILTER... -
Page 4: Important Safety Instructions
Important safety instructions To reduce the risk of fire, electric shock, or injury 1. Do not detach baseplate or attempt to access filters until the system has been switched off. 2. Disconnect power, or unplug, before cleaning, performing any maintenance or replacing a filter. - Page 5 Contact our support team for a replacement. 17. Keep power cord away from heated surfaces. 18. Refer all servicing to qualified INOVA service personal. Servicing is required when the product has been damaged in any way. Do not attempt to service this product yourself.
-
Page 6: How The Inova Air Purifier Works
How the INOVA Air Purifier works *INOVA-E20 pictured... - Page 7 4 simple steps to cleaner air Air is drawn into the system through the perforated side vents. Air then passes through the dust pre-filter and into the H13 medical-grade HEPA filter which removes allergens, viruses, bacteria and other sub-micron fine particle matter. Chemicals and odours are also removed from the air by the final stage activated carbon filter.
-
Page 8: Positioning The Inova Air Purifier
There are two main points to consider: where you spend your time and where the main pollutants are. The longer you keep your INOVA Air Purifier in a single room, the cleaner the air in that room will be. As with a heater or air conditioner, the INOVA Air Purifier will only be effective if windows are closed during operation. -
Page 9: Inova-E20 System Operation
INOVA-E20 system operation The INOVA-E20 system has a variable speed controller and uses an energy efficient European EC fan. Power consumption is relative to the selected speed. Select the required fan speed by turning the variable speed controller. The higher the speed the more times per hour the air in your living space will be cleaned, so it is recommended to run the system at the highest speed you are comfortable with. -
Page 10: Inova-De20 System Operation
INOVA-DE20 system operation The INOVA-DE20 system has a variable speed digital controller and uses an energy efficient European AC fan. Power consumption is relative to the selected speed. Select the required fan speed by using the up and down keys on the turning the variable speed digital controller (more information on page 1 1). -
Page 11: Inova-De20 Digital Controller
INOVA-DE20 Digital Controller The INOVA-DE20 digital controller continuously tracks filter life by monitoring system runtime and fan speed. Connect the power cord supplied to the power cord socket on the rear of the unit, switch the power switch to ON. The system will initiate startup power cycle and all LEDS will illuminate momentarily. - Page 12 Using the INOVA-DE20 Digital Controller 1. Filter Check Each press of the ‘Filter Check’ button will cycle through the 3 individual filters. The illuminated LED next to the filter number indicates which filter information is currently being displayed. FILTER NUMBER...
- Page 13 3. Customise Filter Replacement Interval To customise the filter replacement intervals press ‘Filter Check’ and select filter you want to change, then press and hold the ‘Filter Check’ button and continue to hold the button throughout the rest of the adjustment process. Once the initial flashing has stopped use the ‘Fan Speed’...
-
Page 14: Tips For Getting The Most Out Of Your System
By switching the system off you are only allowing these contaminants to build up in the interim until it is switched back on. INOVA systems are designed for optimal energy efficiency – so don’t be concerned about power consumption as this will barely be noticeable on an electricity bill. - Page 15 Check your pre-filters regularly for dust build-up We recommend that you check your pre-filter after every three months of operation to visually inspect the level of dust buildup. Pre-filters typically last between 3 to 6 months based on average dust levels in a home environment. If the levels of dust in your home are high due to external factors such as living near a main road, you may need to change your filters more regularly.
-
Page 16: Accessing The Filters
3. Pull top of the latches (A) away from the main unit. 4. Push the latches back towards the main unit (B) 5. Ensure the latch clasps are clear of catches on the base (C). 6. Lift casing clear of base to access filters. *INOVA-E20 pictured... -
Page 17: When To Replace The Filters
Operating conditions will vary based on levels of dust, chemicals & odours present, and system proximity to major pollution sources each of which may lower any of the filter lifespans. INOVA does not warranty consumable filter life. Stage 1: Technostat Pre-filter ®... - Page 18 Stage 2: H13 Medical-Grade HEPA Filter HEPA filters known as High-Efficiency Particulate Arrestance filters were originally developed to filter fine radioactive particles. A HEPA filter will filter with a minimum efficiency 99.95% of particles at 0.3 microns and 95% of particles at 0. 1 microns. With 1 micron measuring just 1/10,000 of a centimetre and the smallest particle visible to the naked eye being 40 microns.
- Page 19 • Volatile Organic Compounds stop smelling clean or smell stale. (VOC’s) • Smoke • Road pollution More information on which chemicals and volatile organic compounds can be removed by the activated carbon filter can be found on the INOVA website.
-
Page 20: Replacing Filters
Replacing filters The pre-filter is wrapped around the HEPA filter & fastened with Velcro. Gently unwrap from the filter & replace with a new pre-filter. Ensure pre-filter is installed so the ‘fluffy’ Velcro strip is facing outwards and is firmly fitted around the HEPA filter to avoid air bypassing the pre-filter. -
Page 21: Ordering Replacement Filters
Operating conditions will vary based on levels of dust, chemicals & odours present, and system proximity to major pollution sources each of which may lower any of the filter lifespans. INOVA does not warranty consumable filter life. Replacement filters can be ordered from the INOVA website using the URL or QR code below. -
Page 22: System Warranty
Service Agent is your responsibility. “Consumable” includes (without limitation) filters and pre-filters. “INOVA Air Purifiers” means InovaAir Australia Pty Ltd ACN 103 549 435. “Factory Second” means a Product sold by InovaAir Australia or any other authorised person as a ‘second’... -
Page 23: Year Limited Warranty
of merchantability or fitness for a particular purpose. NB. This exclusion is subject to any relevant Commonwealth or state law, which is intended to override such exclusions. 6. Maximum liability shall not exceed the actual purchase price paid for this product. -
Page 24: Warranty Application
INOVA System Warranty Warranty application This Warranty applies only: a. To a Product that is supplied new to You by InovaAir Australia or by any other ® authorized person; b. If you use the Product for your own private or business purposes; and c. -
Page 25: Australian Consumer Law
vii. Failure is due to improper maintenance by customer (refer to maintenance section of Operating Instructions); viii. Misuse, abuse or neglect; ix. Incorrect voltage or a power surge; or x. Your use of any non-genuine Consumables parts accessories or interfacing; xi. -
Page 26: About Inova Air Purifiers
INOVA Purifiers is an Australian-owned company that for more than 20 years has engineered and manufactured air purifiers for home, commercial and industrial use. INOVA air purifiers are built in a modern factory on the pristine NSW Central Coast, one hour north of Sydney. -
Page 27: Record You Filter Replacement History
Record your filter replacement history Pre-filter (Replace every 3-6 months) Replaced __ /__ / 20___ Replaced __ /__ / 20___ Replaced __ /__ / 20___ Replaced __ /__ / 20___ Replaced __ /__ / 20___ Replaced __ /__ / 20___ Replaced __ /__ / 20___ Replaced __ /__ / 20___ Replaced __ /__ / 20___... - Page 28 INOVA-E20 | INOVA-DE20 USER MANUAL INOVA Purifiers Building B, 10 Corella Close Berkeley Vale, NSW 2261, Australia 1300 137 244 airclean.com.au...
