Summary of Contents for Inova INOVA-E8
- Page 1 INOVA-E8 USER MANUAL This document includes important tips to prolong the life of your filters and get the most out of your new air purifier.
-
Page 2: Table Of Contents
Contents Introducing your INOVA-E8 system Important safety instructions How the INOVA-E8 works Positioning the INOVA-E8 sytem System operation Tips for getting the most out of your system Accessing the filters When to replace the filters Replacing filters Ordering new filters... -
Page 3: Introducing Your Inova-E8 System
Introducing your INOVA-E8 system. Standard system and filters The INOVA-E8 system box will contain the air purifier with the HEPA filter and Pre- filter pre-installed inside as well as a power cable and this instruction manual. INOVA-E8 HEPA FILTER Pre-installed inside the system. -
Page 4: Important Safety Instructions
Important safety instructions To reduce the risk of fire, electric shock, or injury 1. Do not detach baseplate or attempt to access filters until the system has been switched off. 2. Disconnect power, or unplug, before cleaning, performing any maintenance or replacing a filter. - Page 5 Contact our support team for a replacement. 17. Keep power cord away from heated surfaces. 18. Refer all servicing to qualified INOVA service personal. Servicing is required when the product has been damaged in any way. Do not attempt to service this product yourself.
-
Page 6: How The Inova-E8 Works
How the INOVA-E8 works... - Page 7 4 simple steps to cleaner air Air is drawn into the system through the vents on the sides into the filter compartment at the bottom of the unit. Air then passes through the dust pre-filter and on to the H13 medical-grade HEPA filter which removes allergens, viruses, bacteria and other sub-micron fine particle matter.
-
Page 8: Positioning The Inova-E8 Sytem
There are two main points to consider: where you spend your time and where the main pollutants are. The longer you keep your INOVA-E8 in a single room, the cleaner the air in that room will be. As with a heater or air conditioner, the INOVA purifier will only be effective if windows are closed during operation. -
Page 9: System Operation
System operation The system has 4 speed settings and uses an energy efficient European AC fan. Power consumption is relative to the selected speed. Control position Speed level High The higher the speed, the more times per hour the air in your living space will be cleaned, so it is recommended to run the system at the highest speed you are com- fortable with. -
Page 10: Tips For Getting The Most Out Of Your System
By switching the system off you are only allowing these contaminants to build up in the interim until it is switched back on. INOVA systems are designed for optimal energy efficiency – so don’t be concerned about power consumption as this will barely be noticeable on an electricity bill. - Page 11 Check your pre-filters regularly for dust build-up We recommend that you check your pre-filter after every three months of operation to visually inspect the level of dust buildup. Pre-filters typically last between 3 to 6 months based on average dust levels in a home environment. If the levels of dust in your home are high due to external factors such as living near a main road, you may need to change your filters more regularly.
- Page 12 Accessing the filters 1. Disconnect the power cord. 2. Ensure system is sitting on a flat and even surface. 3. Pull top of the latches (A) away from the main unit. 4. Push the latches back towards the main unit (B) 5.
-
Page 13: When To Replace The Filters
Operating conditions will vary based on levels of dust, chemicals & odours present, and system proximity to major pollution sources each of which may lower any of the filter lifespans. INOVA does not warranty consumable filter life. Stage 1: Technostat Pre-filter ®... - Page 14 Stage 2: H13 Medical-Grade HEPA Filter HEPA filters known as High-Efficiency Particulate Arrestance filters were originally developed to filter fine radioactive particles. A HEPA filter will filter with a minimum efficiency 99.95% of particles at 0.3 microns and 95% of particles at 0. 1 microns. With 1 micron measuring just 1/10,000 of a centimetre and the smallest particle visible to the naked eye being 40 microns.
- Page 15 Please note: If you have not ordered this be removed by the activated carbon filter with your INOVA-E8 system, it can be added as required and ordered from filter can be found on the INOVA the INOVA website.
-
Page 16: Replacing Filters
Replacing Filters The pre-filter is wrapped around the HEPA filter & fastened with Velcro. Gently unwrap from the filter & replace with a new pre-filter. Ensure pre-filter is installed so the ‘fluffy’ velcro strip is facing outwards and is firmly fitted around the HEPA filter to avoid air bypassing the pre-filter. -
Page 17: Ordering New Filters
Operating conditions will vary based on levels of dust, chemicals & odours present, and system proximity to major pollution sources each of which may lower any of the filter lifespans. INOVA does not warranty consumable filter life. Replacement filters can be ordered from the INOVA website using the URL or QR code below. -
Page 18: System Warranty
In this warranty: “ACL” refers to the Australian Consumer Law . “Back to Base” means where delivery to and collection of your product from the Service Agent is your responsibility. “Consumable” includes (without limitation) filters and pre-filters. “INOVA Air Purifiers” means InovaAir Australia Pty Ltd ACN 103 549 435. “Factory ®... - Page 19 warranty, whether express or implied, written or oral, including any warranty of merchantability or fitness for a particular purpose. NB. This exclusion is subject to any relevant Commonwealth or state law, which is intended to override such exclusions. 6. Maximum liability shall not exceed the actual purchase price paid for this product.
- Page 20 INOVA System Warranty Warranty application This Warranty applies only: a. To a Product that is supplied new to You by InovaAir Australia or by any other ® authorized person; b. If you use the Product for your own private or business purposes; and c.
- Page 21 vii. Failure is due to improper maintenance by customer (refer to maintenance section of Operating Instructions); viii. Misuse, abuse or neglect; ix. Incorrect voltage or a power surge; or x. Your use of any non-genuine Consumables parts accessories or interfacing; xi.
- Page 22 INOVA was founded in 2003 when allergy sufferer Nicholas Kraus couldn’t find an air purifier that truly freed him from his allergies. Now, INOVA’s products provide genuine protection for the health of Australians all over the country, freeing them from the challenges of pollen, pesticides, dust, toxins and more. ...
- Page 23 Record your filter replacement history Pre-filter (Replace every 3-6 months) Replaced __ /__ / 20___ Replaced __ /__ / 20___ Replaced __ /__ / 20___ Replaced __ /__ / 20___ Replaced __ /__ / 20___ Replaced __ /__ / 20___ Replaced __ /__ / 20___ Replaced __ /__ / 20___ Replaced __ /__ / 20___...
- Page 24 INOVA-E8 USER MANUAL INOVA Air Purifiers Building B, 10 Corella Close Berkeley Vale, NSW 2261 Australia TEL: 1300 137 244 www.airclean.com.au...
