T540XP II
EN
Operator's manual
2-34

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 967 28 75-12 and is the answer not in the manual?

Questions and answers

Related Manuals for Husqvarna 967 28 75-12

Summary of Contents for Husqvarna 967 28 75-12

  • Page 1 T540XP II Operator's manual 2-34...

  • Page 2: Table Of Contents

    Intended use Product description This product is for professional tree maintenance such The Husqvarna T540XP II is a chainsaw model with a as pruning and to disassemble trees in sections. combustion engine. Work is constantly in progress to increase your safety...

  • Page 3: Symbols On The Product

    17. Guide bar 18. Throttle trigger 19. Throttle trigger lockout Air purge bulb. 20. Belt eyelet 21. Clutch cover 22. Chain tensioning screw Adjustment of the oil pump. 23. Product and serial number plate 24. Chain catcher 25. Spiked bumper Fuel.

  • Page 4: Safety Definitions

    Note: Handle insert dimension. Other symbols/decals on the product refer to certification requirements for certain markets. Euro V Emissions yyyywwxxxx The rating plate shows se- rial number. yyyy is the WARNING: production year and ww is Tampering with the engine the production week.
  • Page 5 • Before using this product you must understand the • Observe your surroundings and make sure that there effects of kickback and how to avoid them. Refer to is no risk of people or animals coming in contact with Kickback information on page 12 for instructions. or affect your control of the product.

  • Page 6: Personal Protective Equipment

    Do not • Use pants with saw protection. hesitate to contact your dealer or Husqvarna if you have any questions about the use of the chainsaw. • Use boots with saw protection, steel toe-cap and We will willingly be of service and provide you with non-slip sole.

  • Page 7: Safety Devices On The Product

    19 . • If the safety devices are defective, speak to your Husqvarna servicing dealer. Chain brake and front hand guard Your product has a chain brake that stops the saw chain if you get a kickback. The chain brake decreases the Chain catcher risk of accidents, but only you can prevent them.

  • Page 8: Fuel Safety

    you operate the product near flammable After refuelling, there are some situations where you materials and/or fumes. must never start the product: • If you have spilled fuel or chain oil on the product. WARNING: Wipe off the spillage and allow remaining fuel to Do not operate a product evaporate.

  • Page 9: To Assemble The Guide Bar And Saw Chain

    setting. Too large depth gauge setting increases the • Do maintenance on the cutting equipment regularly risk of kickback. and keep it correctly lubricated. If the saw chain is not correctly lubricated, the risk of wear on the guide bar, saw chain and chain drive sprocket increases. •...

  • Page 10: To Do A Function Check Before You Use The Product

    • If Husqvarna two-stroke oil is not available, use a two-stroke oil of good quality for air-cooled engines. 9. Make sure that the saw chain tension is correct. Speak to your servicing dealer to select the correct oil.

  • Page 11: To Use The Correct Chain Oil

    Speak to your servicing To fill the fuel tank dealer when you select your chain oil. • Use Husqvarna chain oil for maximum saw chain life WARNING: Obey the procedure that and to prevent negative effects on the environment.

  • Page 12: Kickback Information

    WARNING: No saw chain fully prevents kickback. Always obey the instructions. Common questions about kickback • Will the hand always engage the chain brake during a kickback? No. It is necessary to use some force to push the Note: To see where the chain oil tank is on your front hand guard forward.

  • Page 13: To Prepare Start With A Warm Engine

    1. Move the front hand guard forward to engage the 1. Move the front hand guard forward to engage the chain brake. chain brake. 2. Push the air purge bulb about 6 times or until fuel 2. Push the air purge bulb about 6 times or until fuel starts to fill the bulb.

  • Page 14: To Start The Product In The Tree

    To start the product in the tree 4. Pull the starter rope handle slowly with your right hand until you feel resistance. Note: Make sure that you have sufficient fuel before you start the product. 1. Engage the chain brake. 2.

  • Page 15: Pull Stroke And Push Stroke

    To prepare the product for operation in the tree Ground operator As a ground operator, do the following steps. Pull stroke and push stroke 1. Examine the product. You can cut through wood with the product in 2 different 2. Fill the fuel and chain oil tanks. positions.

  • Page 16: To Operate The Product In A Tree

    1. Before you disconnect the safety strop from the • Make sure that you are stable on your feet and keep ascent tools, you must attach the product to the a low lateral force when you cut vertical branches. harness. Attach the product to the harness through Steer the safety line through a different connection the belt eyelet or a steel ring on the safety strop.

  • Page 17: To Remove A Trapped Product

    engine temperature or ice on the air filter WARNING: You must engage the and the carburetor. chain brake when you lower the product onto its strop. 1. Clothe a part of the air intake on the starter. This increases the engine temperature. To remove a trapped product 2.
  • Page 18 Daily maintenance Weekly maintenance Monthly maintenance Do a check of the chain catcher. Re- Clean or replace the spark arrestor Do a check of the fuel filter and the To do a check of the chain To do fer to screen on the muffler.

  • Page 19: Maintenance And Checks Of The Safety Devices On The Product

    Maintenance and checks of the safety 3. Apply full throttle and tilt your left wrist against the front hand guard to engage the chain brake. The devices on the product saw chain must stop immediately. To do a check of the brake band 1.
  • Page 20 To do a check of the start/stop switch that has a defective muffler or a muffler that is in bad condition. Return product 1. Start the engine. to a Husqvarna dealer/service station if the muffler is defective. 1961 - 001 -...

  • Page 21: To Replace A Broken Or Worn Starter Rope

    3. Remove the spark arrester screen. 4. Let the pulley rotate slowly rearward to release the recoil spring. 5. Remove the bolt in the center of the pulley and remove the pulley. Note: Do not remove the muffler from the product. 4.

  • Page 22: To Assemble The Starter Housing On The Product

    2. Turn the starter pulley approximately 2 turns clockwise. 3. Make sure that you can turn the pulley ½ turn after the starter rope is fully extended. 8. Attach a new starter rope to the pulley. Wind the starter rope approximately 3 turns around the pulley. To assemble the starter housing on the 9.

  • Page 23: To Do A Check Of The Spark Plug

    Replace a worn or damaged guide bar or saw chain with seals tightly against the filter holder. the guide bar and saw chain combination recommended by Husqvarna. This is necessary to keep the safety Accessories on functions of the product. Refer to page 31 , for a list of replacement bar and chain combinations that we recommend.

  • Page 24: General Information About How To Sharpen The Cutters

    It is not easy to sharpen a saw chain correctly without through the wood. If the saw chain is very blunt, there the correct equipment. Use Husqvarna file gauge. This will be no wood chips but sawdust. will help you to keep maximum cutting performance and A sharp saw chain eats through the wood and the wood the kickback risk at a minimum.

  • Page 25: General Information About How To Adjust The Depth Gauge Setting

    1. Use a flat file and a depth gauge tool to adjust the depth gauge setting. Only use Husqvarna depth gauge tool to get the correct depth gauge setting and 4. Remove material from one side of all the cutting bevel for the depth gauge.

  • Page 26: To Do A Check Of The Saw Chain Lubrication

    To do a check of the spur sprocket 4. Tighten the saw chain until it is tight against the guide bar but still can move easily. The clutch drum has a spur sprocket that is welded on the clutch drum. •...

  • Page 27: To Do A Check Of The Guide Bar

    3. Compare the saw chain with a new saw chain to 5. Examine if the guide bar tip is rough or very worn. examine if the rivets and links are worn. 4. Replace the saw chain when the longest part of the cutting tooth is less than 4 mm/0.16 in.

  • Page 28: To Clean The Cooling System

    b) Turn the adjustment screw counterclockwise to CAUTION: A dirty or blocked decrease the chain oil flow. cooling system can make the product too hot, which can cause damage to the product. To clean the cooling system The cooling system keeps the engine temperature down.

  • Page 29: The Engine Starts But Stops Again

    • When the product is no longer in use, send it to • Attach the product safely during transportation. a Husqvarna dealer or discard it at a recycling To prepare your product for long-term location. storage 1. Stop the product and let it become cool before you disassemble it.

  • Page 30: Technical Data

    Technical data Technical data Husqvarna T540XP II Engine Cylinder displacement, cm 37.7 Idle speed, rpm 3000 Maximum engine power acc. to ISO 7293, kW/hp @ rpm 1.8/2.5@10200 Ignition system Spark plug NGK CMR6H Electrode gap, mm Fuel and lubrication system Fuel tank capacity, liter/cm 0.34/340...

  • Page 31: Recommended Cutting Equipment

    Filing equipment and filing angles on your product, refer to www.husqvarna.com for more information. Use a Husqvarna file gauge to sharpen the saw chain. A Husqvarna file gauge makes sure that you get the 5/32 in / 0.025 in / 579 65 36-01 30°...
  • Page 32 5/32 in / 0.025 in / 505 24 37-01 30° 80° 0° 505 69 81-38 4.0 mm 0.65 mm 5/32 in / 0.025 in / S93G 587 80 90-01 30° 60° 0° 587 80 67-01 4.0 mm 0.65 mm 5/32 in / 0.025 in / SP21G 595 00 47-01...

  • Page 33: Ec Declaration Of Conformity

    EC Declaration of Conformity EU Declaration of Conformity We, Husqvarna AB, SE-561 82 Huskvarna, Sweden, tel: +46-36-146500, declare on our sole responsibility that the product: Description Chainsaw for tree-service Brand Husqvarna Type / Model T540XP II Identification Serial numbers dating from 2016 and onwards...
  • Page 34 UK Declaration of Conformity We, Husqvarna AB, SE-561 82 Huskvarna, Sweden, tel: +46-36-146500, declare on our sole responsibility that the product: Description Chainsaw for tree-service Brand Husqvarna Type / Model T540XP II Identification Serial numbers dating from 2022 and onwards...
  • Page 35 1961 - 001 -...
  • Page 36 Original instructions 1143281-26 2022-09-15...
