iSSL+, SD4100
NOTICE D'UTILISATION / USER MANUAL
Points de vérification / Checkpoints
Le mât
/ Pole
Le diamètre en tête du mât doit être de 60 mm.
La tolérance de diamètre est de ±1,2 mm.
Diameter at the top of the pole should be
Tolerance is
±1.2
mm.
L'iSSL+ est conçu pour s'adapter sur des mâts et crosses
en acier ou aluminium. En cas d'utilisation de mâts et
crosses en composite, béton ou bois, une mise à la terre
devra obligatoirement être faite par l'installateur selon
les règles de l'art pratiquées dans le pays d'installation
du produit.
Ne pas utiliser d'outil à chocs pour fixer l'iSSL+ sur le mât.
PRUDENCE ! Le mât doit être choisi en prenant en compte
le poids de l'iSSL+ et son environnement (exposition aux
vents, caractéristiques du sol, etc) afin que l'installation
soit sécurisée. La responsabilité de Sunna Design ne
saurait être engagée en cas d'incident lié au choix du mât.
Ombrage
/ Shading
Inclinaison : Produit non inclinable
© 2024 SUNNA DESIGN
60mm +/- 1,2
60mm +/- 1,2
60
mm.
The iSSL+ is designed to fit on steel or aluminum poles
and arms. In the case of use of composite, concrete or
wood poles and arms, a grounding must be made by the
installer according to the rules of art practiced in the
country where the product is installed.
Do not use a shock tool to fix the iSSL+ on the pole.
CAUTION ! Poles have to be chosen taking into account
iSSL+ weight and site specifications (wind exposition, soil
characteristics, etc) in order to have a safe installation.
Sunna Design liability won't be engaged in case of pole
related incident.
/ Angle : Untiltable product
60mm +/- 1,2
60 mm +/- 1,2
60mm +/- 1,2
60mm +/- 1,2
Pollution lumineuse
/ Light Pollution
100 mm
6
