iSSL+
NOTICE D'UTILISATION
USER MANUAL
sunna-design.com
© SUNNA DESIGN 2024 – Sunna Design se réserve le droit de modifier les
iSSL+, SD4100 - Z10054_B
informations de ce document. Sunna Design reserves the right to modify the
NOTICE D'UTILISATION / USER MANUAL
information in this document.

Advertisement

loading
Need help?

Need help?

Do you have a question about the iSSL+ and is the answer not in the manual?

Questions and answers

Summary of Contents for Sunna Design iSSL+

  • Page 1 NOTICE D’UTILISATION USER MANUAL sunna-design.com © SUNNA DESIGN 2024 – Sunna Design se réserve le droit de modifier les iSSL+, SD4100 - Z10054_B informations de ce document. Sunna Design reserves the right to modify the NOTICE D’UTILISATION / USER MANUAL...
  • Page 2 Sunna Design. Sunna Design thanks you for choosing the product iSSL+ and hopes it will give you entire satisfaction. This manuel will familiarize you with the features and operation of the iSSL+ solar street light.
  • Page 3 En conséquence, Sunna Design ne contracte this user manual. As a result, Sunna Design does not assume aucune obligation de conseils ou de renseignements en matière any obligation to provide advice or information regarding the d’installation des produits, dont la responsabilité...
  • Page 4: Informations Generales

    Sunna Design, la responsabilité de l’entreprise ne saurait If not sold by Sunna Design, the company cannot be held être engagée en cas d’incident lié au choix du mât. responsible for any incidents related to the choice of pole.
  • Page 5 Pour des raisons de sécurité, veillez à bien monter tous ces éléments sur le produit. For safety reasons, please ensure that every element Outils nécessaires / Required tools (non fournis / not included) Clé 6 pans métrique 4 mm / 4mm Allen key © 2024 SUNNA DESIGN...
  • Page 6 Do this before going on-site Log in the product after the installation to complete its comissioning If it’s an EverGen, you will need the order number available on the invoice / example : S00213 © 2024 SUNNA DESIGN...
  • Page 7 La responsabilité de Sunna Design ne Sunna Design liability won’t be engaged in case of pole saurait être engagée en cas d’incident lié au choix du mât. related incident.
  • Page 8 NOTICE D’UTILISATION / USER MANUAL Etapes d’installation / Installation steps Passage en position « Side » (si nécessaire) Move to “Side” position (if necessary) a) Déverrouillage loquet Latch release b) Orientation manchon puis verrouillage loquet Tenon orientation then latch locking © 2024 SUNNA DESIGN...
  • Page 9 / LED optical ajustment Ajuster l’inclinaison à 0°/10°/20°/30° selon la zone à éclairer Adjust the tilt to 0°/10°/20°/30° depending on the area to be illuminated Serrage sur le mât / Locking on pole max. 6 Nm © 2024 SUNNA DESIGN...
  • Page 10 Press the ON button Mise en route / Start- up Le module LED doit s’allumer brièvement à l’initialisation The LED module should light up briefly on initialization. Initialisation du produit / Initialization LED indicatrices / LED status © 2024 SUNNA DESIGN...
  • Page 11 Pour un profil horodaté, veillez à modifier le fuseau horaire dans les paramètres de la SunnApp : sélectionnez le fuseau horaire souhaité en prenant en compte les changements d’heure (DST = Daylight Saving Time). © 2024 SUNNA DESIGN...
  • Page 12 For a timestamped profile, please change the time zone in the SunnApp settings: select the desired time zone taking into account daylight savings time (DST). © 2024 SUNNA DESIGN...
  • Page 13 Dans le cas contraire, merci de If not, please contact our customer service. contacter notre service client. 100% Figure 1: Profil d’éclairage les 3 premières nuits Diagram 1: Lighting profile the first 3 nights JOUR NUIT JOUR NIGHT © 2024 SUNNA DESIGN...
  • Page 14 Flash Mode veille (Sleeping mode) Entretien / Maintenance Sunna Design recommande des inspections We recommend occasional visual inspections visuelles des panneaux solaires afin de of solar panels to ensure that they are clean and s’assurer qu’ils sont propres et dégagés de ce unobstructed by anything that could prevent the qui peut gêner leurs bon fonctionnement, dont :...
  • Page 15 à 4 °C background, greater than 4°C Vitesse du mouvement : 1 m/s Movement speed: 1 m/s Gabarit de détection : corps humain (minimum Detection size: human body (minimum 700 x 700 x 250 mm) 250 mm) © 2024 SUNNA DESIGN...
  • Page 16 THE BEGINNING OF THE NIGHT * FLASH : par défaut clignote toutes les 3 secondes ; si mode veille, clignote toutes les minutes. * FLASH: default flashes every 3 seconds; if sleep mode, flashes every minute. © 2024 SUNNA DESIGN...
  • Page 17 SD4100 NOTICE D’UTILISATION / USER MANUAL © 2024 SUNNA DESIGN...
  • Page 18 Téléphone : +33 (0)5 47 74 86 03 Site internet : www.sunna-design.com E-mail : sav@sunna-design.fr sunna-design.com © SUNNA DESIGN 2024 – Sunna Design se réserve le droit de modifier les Z10054_B informations de ce document. Sunna Design reserves the right to modify the information in this document.
