- Page 1 Operating and Installation Instructions Ventilation Hood To prevent accidents and damage to the appliance, you must read these instructions before installing the appliance and using it for the first time. en-US M.-Nr. 12 254 500...
-
Page 2: Table Of Contents
Description of functions ................... 16 Before using for the first time ................17 Selecting extraction mode or recirculation mode..........17 Setting up Miele@home ..................17 Connecting via the app .................. 18 Connecting via WPS ..................19 Signing out of WiFi (reset to factory settings) ..........20 Setting up Con@ctivity .................. - Page 3 Contents Cleaning and care ..................... 34 Stainless steel housing..................34 Grease filters and edge extraction panel............. 35 Replacing the grease filter................37 OdorFree Charcoal Filter ..................38 Resetting the filter saturation indicator for the charcoal filters....... 38 Disposing of charcoal filters ................38 Installation......................
-
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ AND SAVE THESE INSTRUCTIONS This appliance complies with current safety requirements. Improper use of the appliance can lead to personal injury and material damage. Read all instructions before installing or using the appliance for the first time. Only use the appliance for its intended purpose. Keep these operating instructions in a safe place and pass them on to any future user. -
Page 5: Safety With Children
Unauthorized installation, maintenance, and repairs can cause considerable danger for the user. Installation, maintenance, and repairs must only be carried out by a Miele authorized technician. A damaged ventilation hood can be dangerous. Always check for visible signs of damage. Never use a damaged ventilation hood. - Page 6 The function and operation of the protective measures provided in the domestic electrical installation and in this Miele product must also be maintained in isolated operation or in operation that is not synchronized with the grid power supply, or these measures must be replaced by equivalent measures in the installation.
-
Page 7: Correct Use
IMPORTANT SAFETY INSTRUCTIONS Only open the housing as described in the enclosed “Installation diagram” and in the “Cleaning and care” section of this manual. Under no circumstances should any other parts of the housing be opened. Tampering with electrical connections or components and mechanical parts is highly dangerous to the user and can cause operation faults. - Page 8 IMPORTANT SAFETY INSTRUCTIONS Open flames are a fire hazard. The use of an open flame under the ventilation hood is not permitted. To avoid the danger of fire, do not flambé or grill over an open flame. When switched on, the ventilation hood could draw flames into the filter.
- Page 9 IMPORTANT SAFETY INSTRUCTIONS Always turn the ventilation hood on whenever a burner is in use to prevent damage from condensation. Overheated oil and fat can ignite, causing fire damage to the ventilation hood. Do not leave cookware, pans, and deep-fat fryers unattended when cooking with oil or fat.
-
Page 10: Proper Installation
IMPORTANT SAFETY INSTRUCTIONS Proper installation WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: - a) Installation work and electrical wiring must be done by qualified person(s) in accordance with all applicable codes and standards, including fire-rated construction. -
Page 11: Cleaning And Maintenance
The steam can reach the electrical components and cause a short circuit. Accessories and parts Use only genuine original Miele parts. If parts or accessories from other manufacturers are used, the warranty may become void. Defective components should be replaced by Miele original parts only. -
Page 12: Fcc Declaration Of Conformity
IMPORTANT SAFETY INSTRUCTIONS Miele will guarantee to supply functional parts for a minimum of 10 years and up to 15 years following the discontinuation of your ventilation unit. FCC Declaration of Conformity These devices comply with FCC Rules Part 15. This equipment... -
Page 13: Disposal Of The Packing Material
Consult with local authorities, dealers or Miele in order to dispose of and recycle electrical and electronic appliances. Miele assumes no responsibility for deleting any personal data left on the appliance being disposed. -
Page 14: Guide To The Appliance
Guide to the appliance... - Page 15 Charcoal filters (2 filters) Optional accessories for recirculation mode (only for DA 2698) d Grease filters (DA 2698: 2 filters; DA 2628: 4 filters) e Edge extraction panel (DA 2698: 1 panel; DA 2628: 2 panels) f Control panel...
-
Page 16: Description Of Functions
Description of functions The following functions are available on Recirculation mode your ventilation hood, depending on the model: Extraction mode The air is drawn in and passed via the edge extraction panel through the grease filters and then through two charcoal filters. -
Page 17: Before Using For The First Time
Miele app. Switch off the blower and the lighting. If your Miele cooktop is connected to a home WiFi network, you can control the Press the control and the ventilation hood automatically via the operating-hours control ... -
Page 18: Connecting Via The App
Before using for the first time Miele App Connecting via the app The Miele App is available to download The Miele app can be used to connect free of charge from the Apple App to your network. ® Store or from the Google Play Store™. -
Page 19: Connecting Via Wps
Before using for the first time Switch the ventilation hood off. Connecting via WPS Your WiFi router must support WPS (WiFi Protected Setup). Press and hold the control. Switch the ventilation hood off. Press the lighting control at the ... -
Page 20: Signing Out Of Wifi (Reset To Factory Settings)
WPS to your The ventilation hood will be ready for router quickly enough. Repeat the steps disconnection in the next 2 minutes. above. Tip: If your WiFi router does not support WPS, please connect via the Miele app. -
Page 21: Setting Up Con@Ctivity
Con@ctivity is the direct communication Touch the control. system between an induction Miele cooktop and a Miele ventilation hood. It enables the ventilation hood to operate automatically depending on the 2 will light up constantly, 3 will flash on operational state of a Miele cooktop and off. -
Page 22: Con@Ctivity Via The Home Wifi Network (Con@Ctivity 3.0)
Con@ctivity function via a WiFi connection (Con@ctivity 3.0) or Prerequisite: via a wireless connection (Con@ctivity - WiFi enabled Miele cooktop 2.0). If you do not have a home network, you Con@ctivity via the home WiFi can establish a direct connection network (Con@ctivity 3.0) -
Page 23: Reattempting The Connection
Con@ctivity with direct wireless cooktop. For more details, see the connection (Con@ctivity 2.0) cooktop operating instructions. Required: - Con@ctivity 2.0 enabled Miele induction cooktop When successfully connected, 2 and 3 will light up constantly. Quit connection mode on the ventilation hood by pressing the delayed shutdown control . - Page 24 Before using for the first time Installing the Con@ctivity 2.0 stick Activating the ventilation hood See the relevant installation The cooktop and ventilation hood instructions provided with the must be switched off. Con@ctivity 2.0 stick. Activating the wireless connection ...
- Page 25 Before using for the first time Finishing activation on the ventilation hood To activate Con@ctivity 2.0, press the control. When successfully connected, B will go out, and 2 and 3 will light up constantly. 2 will light up constantly, 3 will flash on and off.
- Page 26 Before using for the first time Activation failed If a wireless connection cannot be Press the control to deactivate established despite activation of the Con@ctivity function on the ventilation Con@ctivity 2.0. hood and cooktop, the function must first be deactivated and then reactivated on both appliances.
-
Page 27: Cooking With Con@Ctivity (Automatic Mode)
Operation (Automatic mode) When Con@ctivity is active, the ventilation hood always operates in automatic mode (see “Before using for the first time – Setting up Con@ctivity”). If you wish to operate the ventilation hood manually; see “Operation (Manual mode) – Cooking without Examples for power levels 1 to B Con@ctivity”. -
Page 28: Temporarily Exiting Automatic Mode
Operation (Automatic mode) Resuming Automatic mode Switching off The ventilation hood resumes Turn off all burners. Automatic mode: Over the next few minutes, the - If the ventilation hood has not been ventilation hood blower setting will used for a period of approx. decrease one level at a time until the 5 minutes after the manual selection hood eventually turns off. -
Page 29: Operation (Manual Mode)
Operation (Manual mode) Cooking without Con@ctivity Selecting the delayed (Manual mode) shutdown time The ventilation hood can be operated It is advisable to run the blower for a manually if: few minutes after cooking has finished. This helps to neutralize any lingering - The Con@ctivity function is not vapors and odors in the air. -
Page 30: Power Management
Operation (Manual mode) With the lighting switched on, press - the lighting control , and hold the lighting control . The - the control, and then brightness will gradually dim until you release the control. - the lighting control . To increase the brightness, press and When power management is turned on, hold the lighting control ... -
Page 31: Operation (Automatic And Manual Modes)
Operation (Automatic and Manual modes) Switch off the blower and the lighting. Filter saturation indicator Press the delayed shutdown The ventilation hood registers the length control and the filter saturation of time it has been operated. control at the same time. The filter saturation indicators show The grease filter symbol ... -
Page 32: Adjusting Or Deactivating The Filter Saturation Indicator For The Charcoal Filter
Operation (Automatic and Manual modes) Adjusting or deactivating the filter Checking the filter saturation saturation indicator for the charcoal indicator filter Before the set operating time has run Charcoal filters are needed for out, you can check what percentage of recirculation mode. -
Page 33: Energy-Saving Tips
Energy-saving tips This hood operates in a very efficient - Use the Con@ctivity function. The and energy-saving manner. The ventilation hood will switch on and off following will help you to save even automatically. The ventilation hood more energy when using it: will select the optimum power level for the cooking you are doing, which - Ensure that there is sufficient... -
Page 34: Cleaning And Care
Unsuitable cleaning agents can treating them with a stainless steel care damage the surfaces and control product (available from Miele). elements. Do not use any cleaning agents Important information for the containing soda, acid, chloride, or controls solvent. -
Page 35: Grease Filters And Edge Extraction Panel
Cleaning and care Removing the panel and grease Grease filters and edge filters extraction panel The panel and grease filter can Risk of fire fall out when you are handling them. Oversaturated grease filters are a fire This can result in damage. hazard. - Page 36 Ensure the spray arm is not obstructed. Use a commonly available household dishwashing detergent. In a Miele dishwasher use the “Normal” program. Depending on the detergent used, cleaning the filters in a dishwasher may cause the inside filter surfaces to become discolored.
-
Page 37: Replacing The Grease Filter
If you identify any damage, replace the grease filters. Grease filters are available to order via Miele Customer Service (see end of these operating instructions for contact details) or from your Miele dealer. Lift the panel into the canopy and hook it in at the back. -
Page 38: Odorfree Charcoal Filter
Charcoal filters are available to order via symbol . the Miele Web Store (see end of this booklet for contact details), or from Resetting the filter saturation your Miele dealer. The charcoal filters indicator for the charcoal filters are listed under “Technical data”... -
Page 39: Installation
*INSTALLATION* Installation Before installation Before installation, it is important to read the information contained in this chapter and in the “IMPORTANT SAFETY INSTRUCTIONS” chapter. The ventilation hood is intended for installation in wall cabinets, ventilation housing units, vent flues or above kitchen islands. -
Page 40: Appliance Dimensions
*INSTALLATION* Installation Appliance dimensions... -
Page 41: Installation
1" (25 mm) from the cut-out. c Alternatively, the ventilation hood can be secured to four fixing points on an interim shelf. d There are additional fixing points on the installation surface. Installation dimensions will differ if you are using the Miele DAA 6 adapter... -
Page 42: Distance Between Cooktop And Ventilation Hood (S)
Please also observe the information contained in the “IMPORTANT SAFETY INSTRUCTIONS” section. Minimum distance S Cooking appliance Miele Non-Miele appliance appliance Electric Cooktops 24" (610 mm) Electric Barbeques and Fryers 26"... -
Page 43: Installation Recommendations
*INSTALLATION* Installation Installation recommendations Installation materials - A distance of at least 26" (660 mm) is recommended above electric cooktops to provide more workspace and easier cooking under the hood. - When selecting an installation height, always take the user height into consideration. -
Page 44: Uneven Installation Surface
*INSTALLATION* Installation Conversion kit for recirculation Using the suction cup supplied, pull mode the lamp out of its holder. including directional unit, hose, and Remove all other bulbs in the same hose clips (not supplied, but available way. as an optional accessory. -
Page 45: Air Venting
“Appliance dimensions”). This applies If the exhaust is ducted through an in particular when using flat ducting. outside wall, a Miele wall vent or roof - The ducting should be as short and vent (available as an optional straight as possible. -
Page 46: Condensate
*INSTALLATION* Installation Condensate Miele will not accept warranty claims for any functional defects or damage If the ducting is to run through cool caused by inadequate ducting. rooms or ceiling space, for example, the significant variations in temperature Reducing Collar between the different areas can cause condensate to form. -
Page 47: Electrical Connection
CSA C22.1-12, appliance to your power supply, Canadian Electrical Code, Part I. please consult a licensed electrician or call Miele’s Technical Service Department. WARNING: THIS APPLIANCE MUST BE GROUNDED... -
Page 48: Customer Service
In the event of a fault which you cannot remedy yourself, please contact your Miele dealer or Miele Customer Service. You can book a Miele Service Call online at www.miele.com/service. Contact information for Miele Customer Service can be found at the end of this document. -
Page 49: Technical Data
Technical data Blower motor 350 W Overhead lighting DA 2698 4 x 3 W DA 2628 3 x 4.5 W Total connected load DA 2698 362 W DA 2628 363.5 W Supply voltage, frequency 120 V AC, 60 Hz Fuse 15 A Power cord length 2.5 ft (0.75 m) Weight DA 2698 30.8 lbs (14 kg) DA 2628 33 lbs (15 kg) - Page 50 Technical data WiFi module EK037 FCC ID: 2ACUWEK037 IC: 5669C-EK037 ZigBee® module EK038 FCC ID: 2ACUWEK038 IC: 5669C-EK038 This device complies with Part 15 of the FCC Rules and with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 51 Customer Service. U.S.A. Canada Miele, Inc. Importer Miele Limited National Headquarters 9 Independence Way Headquarters and Miele Centre Princeton, NJ 08540 161 Four Valley Drive www.mieleusa.com Vaughan, ON L4K 4V8 www.miele.ca Customer Support Phone: 888-99-MIELE (64353) Customer Care Centre info@mieleusa.com...
- Page 52 DA 2698, DA 2628 en-US M.-Nr. 12 254 500 / 01...
