Wattson WTS920 User Manual

WTS920
H.R. 600TVL
Introduction :
.
This User Guide suits WTS920
latest technology of sensor and driver. The most
attractive characteristics are small and easy hidden, suits
the elevator and corridor. In addition, it owns the characters
of high definition and stability, strong anti-jamming, rich and
real color. Fixing and using this model is very easy.
It is very good for you to apply to your CCTV system.
Please read this instruction manual carefully to ensure proper use
of the product.
Camera
product. We adopt the
FEATURES
(1) 1/3" H.R.Color CCD
(2) High resolution
(3) Low light sensitivity of 0.05 Lux at F1.4, 0 Lux (IR ON)
(4) IP66, suitable for outdoor use
(5) Day and night features for 24-hour surveillance
Specifications :
MODEL
Pick-up Element
Number of Pixels
Min. Illumination
Resolution
IR LED
IR Effective Distance
S/N Ratio
Lens
Scaning system
Gama characteristic
video output
AGC
IP Rating
operating temperature
Power Source (±10%)
Current Consumption
(±10%)
dimensions
* The specifications are subject to change without notice.
** Dimensional Tolerance: ± 5mm
WTS920
1/3" H.R. Color CCD
PAL:752(H)×582(V) NTSC:768(H)×494(V)
0Lux (with IR LED ON)
600TVL
Φ42*4pcs
Up to 120 meters
More than 48dB
8-20mm Manual Zoom lens
2:1 interface
0.45
1Vpp, 75Ω
AUTO
IP66
-10~+45℃ RH95% MAX
DC 12V
1500mA
230(W) x180(H) x115(D)
