Wattson EDS147H-2 User Manual

Specification
EDS147H-2
1/3'' Sony color CCD 540TVL
1/3" Sony Super-HAD CCD 420TVL
1/4'' Sony color CCD 420TVL
1/3'' Sharp color CCD 420TVL
1/4'' Sharp color CCD 420TVL
540TVL PAL:752X582 NTSC:768X494
pixels
PAL:500×582
420TVL NTSC:510×492
3.6mm
Lens
6mm
OEM Color Black Beige
Signal System PAL/NTSC Optional
Min. illumination 1.0 LUX/F1.2
Electronic
PAL: 1/50~1/100,000ses ; NTSC:1/60~1/100,000ses
Shutter
S/N Ratio ≥48dB
Video Output 1Vp-p/75 Ω
White balance Auto
Backlight
Auto
Compensation
Gamma
≥0.15
Characteristic
Dimension Φ85*55mm
Weight 105g
Power Supply DC 12V,
Operation
-10°C ~ + 50°C
Temperature
Content
No Name
1. Color Dome Camera
2. UserGuide
User Manual
Silver
Model QTY.
147 Series 1
147 Series 1
Color Dome Camera
OEM Color
Beige Silver
Notes:
Before providing power for the
camera, please read this User Guide in de-
tail!
Do not attempt to disassemble the camera. If the
camera can not work, please contact local fran-
chiser or our company.
