- Page 1 AirCheq Touch U S E R M A N U A L...
-
Page 2: Table Of Contents
Table of Contents Home screen display CO2 Auto Base Line CO2 Sensor Calibration History Built In Sensor Calibration Settings Humidity Sensor Calibration Language Time Zone Selection Clock Daylight Saving Time Backlight Home screen colour Standby screen Alarm speaker ON/OFF Temp alarm History Time Humi Alarm Lock... -
Page 3: Home Screen Display
Home screen display Actual date and time Actual CO2 value Adjust threshold values Turn on/off lock AirTeq settings Actual Humidity History Actual temperature Settings Turn on/off AirCheq Touch User Manual... -
Page 4: History
History Click on the History chart to open the options Select the parameter you want to see AirCheq Touch User Manual... - Page 5 Click on the arrow to return back to previous screen Click on data log table to open the data log AirCheq Touch User Manual...
- Page 6 The data from the graphs and table will be deleted PC it can export a txt file when using the Save When connected with AirCheq all data will still be to File button stored and visible online AirCheq Touch User Manual...
-
Page 7: Settings
Settings Click on AirTeq settings Setup sensor - make sensor ready for use Connect sensor - info about AirCheq Network setting - connect wifi Manuals & support - View latest manuals AirCheq Touch User Manual... -
Page 8: Language
Language settings Open the settings Select your language Click on language Click on return button AirCheq Touch User Manual... -
Page 9: Clock
Clock settings Open the settings Adjust the date and time. Click on Clock Setting You can turn on/off US time and 12hr clock Click on the return button to save AirCheq Touch User Manual... -
Page 10: Backlight
Backlight settings Open the settings Use the arrows to adjust brightness Click on the backlight setting Turn on/off Always Max brightness option Turn on/off Ambient Light Dimming. The sensor will adjust to light level in the room. AirCheq Touch User Manual... -
Page 11: Standby Screen
Standby screen settings Open the settings Select your preferred standby screen Click on Standby screen option Select the time before standby screen is activated AirCheq Touch User Manual... -
Page 12: On/Off
ON/OFF settings Open the settings Click on ON/OFF settings screen Standby Screen Options Default Turn of Screen AirCheq Touch User Manual... - Page 13 Turn on/off the function Set the start and stop time for device to be turned on Select Off in weekend to turn device off on Saturday + Sunday AirCheq Touch User Manual...
-
Page 14: History Time
History time settings Open the settings Select the preferred time interval used in graphs and data log chart. Click on History Time Setting AirCheq Touch User Manual... -
Page 15: Lock
Lock settings Open the settings Turn on/off lock pin Click on Lock Use arrows to set the number code for the lock AirCheq Touch User Manual... - Page 16 When the lock is turned on the screen will ask for the code before the settings can be opened. AirCheq Touch User Manual...
-
Page 17: Temperature Format
Temperature format settings Open the settings Select the preferred option Click on temperature format AirCheq Touch User Manual... -
Page 18: Co2 Calibration
CO2 calibration settings Open the settings Use the arrows to adjust the minimum and maximum Click on CO2 Set limitation AirCheq Touch User Manual... -
Page 19: Co2 Calibration At 415Ppm
CO2 calibration at 415ppm settings Open the settings Follow the instructions and press start Click on CO2 Calibration at 415ppm AirCheq Touch User Manual... -
Page 20: Co2 Auto Base Line
CO2 auto base line settings Open the settings Enable: the sensor will autocalibrate based on average lowest values measured in the Click on CO2 Auto Base Line Settings past 2 weeks. AirCheq Touch User Manual... -
Page 21: Co2 Sensor Calibration
CO2 sensor calibration settings Open the settings Use the arrows to manually calibrate the CO2 value Click on CO2 Sensor Calibration AirCheq Touch User Manual... -
Page 22: Built In Sensor Calibration
Built in sensor calibration settings Open the settings Use the arrows to manually calibrate the temperature value Click on Built In Sensor Calibration AirCheq Touch User Manual... -
Page 23: Humidity Sensor Calibration
Humidity sensor calibration settings Open the settings Use the arrows to manually calibrate the Humidity value Click on Humidity Sensor Calibration AirCheq Touch User Manual... -
Page 24: Time Zone Selection
Click on Time Zone Selection the time server of your wifi network. (sensor must be connected to wifi) Use the arrows to manually calibrate the Humidity value. When time sync is activated, manual changes can not be made. AirCheq Touch User Manual... -
Page 25: Daylight Saving Time
Daylight saving time settings Open the settings Select your region Click on Daylight Saving Time Use Auto-DST for summer/winter time changes This setting is not in effect when time sync is enabled. AirCheq Touch User Manual... -
Page 26: Home Screen Colour
Home screen colour settings Open the settings Select the preferred background color Click on Home Screen Colour AirCheq Touch User Manual... -
Page 27: Alarm Speaker
Alert High -> When CO2 High threshold (red Click on Alarm Speaker Setting color) is reached, the sensor will make a beeping noise. Alert Low -> When CO2 Low threshold (orange color) is reached, the sensor will make a beeping noise. AirCheq Touch User Manual... -
Page 28: Temp Alarm
Click on Temp Alarm Setting the selected value, the sensor will make a beeping noise. Alert low -> When temperature is below the selected value, the sensor will make a beeping noise. Use the arrows to adjust the value. AirCheq Touch User Manual... -
Page 29: Humi Alarm
Click on Humi Alarm Setting value, the sensor will make a beeping noise. Alert low -> Humidity is below the selected value, the sensor will make a beeping noise. Use the arrows to adjust the value. AirCheq Touch User Manual... -
Page 30: Reset To Factory Settings
Reset to factory settings Open the settings Click on Reset to go back to factory settings Click on Reset to Factory Setting AirCheq Touch User Manual... -
Page 31: System Information
System information Open the settings When the sensor has no LoRa, it will show the sensor ID Click on System Information AirCheq Touch User Manual... - Page 32 When the sensor has LoRa, it will show the sensor ID, DevEUI, AppEUI and Appkey. AirCheq Touch User Manual...
-
Page 33: Network Settings
Network settings Open the settings Select your network Click on Network Settings AirCheq Touch User Manual... - Page 34 When the wifi is connected it will show a checkmark. AirCheq Touch User Manual...
- Page 35 When the wifi is connected it will show on the home screen. AirCheq Touch User Manual...
