No-Drill MudFlaps
1
Start by thoroughly washing your vehicle. Take
care to remove all dirt, debris, and stains from
each fender in the areas corresponding to
where the MudFlaps will be installed.
2
Park the vehicle on level ground with the
wheels turned fully to the left. Begin with the
driver's side MudFlap installation.
3
3
Locate the #1 and #2 factory Torx head screws that
face the tire, as pictured.
5
5
Find the MudFlap marked "LH," and place it up to
the fender in appropriate orientation.
2
1
Installation Instructions
4 4
Using a ratchet, appropriate socket and supplied
Torx bit, remove the #1 and #2 factory Torx head
screws. One screw will be reused for installation
later.
6
6
With the MudFlap against the fender, loosely
re-install the previously removed factory Torx head
screw in location #1.
What You Need
Ratchet and Socket Set*
Flat Blade Screwdriver*
T15 Torx bit (included)
*Not included
48MF568 Parts Kit:
(2) U-Clips
48MF587 Parts Kit:
(2) #8 Screws

Advertisement

loading
Need help?

Need help?

Do you have a question about the No-Drill MudFlaps and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for WeatherTech No-Drill MudFlaps

  • Page 1 Installation Instructions No-Drill MudFlaps What You Need Ratchet and Socket Set* Flat Blade Screwdriver* T15 Torx bit (included) *Not included Start by thoroughly washing your vehicle. Take care to remove all dirt, debris, and stains from each fender in the areas corresponding to where the MudFlaps will be installed.
  • Page 2 Then fully tighten steps 3-9. the fasteners in locations #1 and #2. Congratulations! Your new WeatherTech® No-Drill MudFlaps have been installed! Your WeatherTech® No-Drill MudFlap carries a Lifetime Limited Warranty against defects in materials and workmanship when installed correctly.
  • Page 3 Lo que necesita Matériel nécessaire No-Drill MudFlaps Juego de matraca y dados* Trousse de douilles et rochet* Desarmador de pala plana* Tournevis à lame plate* Punta Torx T15 (incluida) Embout Torx T15 (compris) Instrucciones de instalación *No incluido * Non compris.
  • Page 4 étapes 3 à 9. ¡Felicitaciones! ¡Sus nuevas Loderas Sin-Perforar de WeatherTech® están instaladas! Cuando se instalan correctamente, las Loderas Sin-Perforar de WeatherTech® incluyen una garantía limitada de por vida contra defectos de materiales y mano de obra. Félicitations! Vos nouvelles bavettes garde-boue sans perçage WeatherTech®...
