- Page 1 KC5 120GB Storage Kit Kit Instructions Publication ID: 1925-K003 Publication Issue: C © 2024 NCR Voyix. All rights reserved. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
-
Page 2: Copyright And Trademark Information
Copyright and Trademark Information The product described in this document is a licensed product of NCR Voyix Corporation. NCR Voyix is a registered trademark of NCR Voyix Corporation. Product names mentioned in this publication may be trademarks or registered trademarks of their respective companies and are hereby acknowledged. -
Page 3: Revision Record
Revision Record Issue Date Remarks Feb 2022 First issue. Mar 2023 Converted to Guild template Oct 2024 Converted to Voyix template Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions. -
Page 4: Kit Contents
Static/ESD Warning Label, 1 3/4” x 2 1/2” 006-8623359 Bag, 2x2 Zip Lock * Items marked with an asterisk are not called out on the image. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions. -
Page 5: Installation Procedure
2. Insert the Storage Module at an angle into its socket, aligning the notch on the Storage Module with the socket key. Caution Do not touch the gold connectors or circuit components on the Storage Module. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions. - Page 6 4. Install the screw to secure the Storage Module to the Motherboard. 5. Close the chassis. For more information, refer to "Closing the Chassis" on page 9. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 7 5. When the imaging process is complete, enter Exit on the keyboard to reboot the system. 6. After the reboot, remove the USB Flash Drive and disconnect the keyboard. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
-
Page 8: Component Access
To access or service the NCR KC5 internal components, the front cover, back cover, and top extrusion must be removed. Note The unit must be placed upside down. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions. -
Page 9: Opening The Chassis
Gripping the gasket, remove both the Plate Gasket and the Front Plate from the unit. 3. Remove the Back Cover. a. Remove the screw that secure the Back Plate to the Display Port connector. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions. - Page 10 Remove the two flat head screws that secure the Back Plate and the Plate Gasket to the unit. c. Gripping the gasket, remove both the Plate Gasket and the Back Plate from the unit. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 11 4. Slide the Top Extrusion out of the Bottom Extrusion. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
-
Page 12: Closing The Chassis
1. Place the Top Extrusion into the grooves of the Bottom Extrusion, and slide the Top Extrusion until its ends are properly aligned with the Bottom Extrusion. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions. - Page 13 Plate Gasket between the Motherboard and the Bottom Extrusion. Note The rim of the Plate Gasket must evenly fit around the top and bottom extrusions. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 14 Top Extrusion. Gently push this grounding finger to assist in insertion. c. Install the two flat head screws to secure the Back Plate and the Plate Gasket to the unit. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 15 Position the indicated portion of the Plate Gasket between the Motherboard and the Bottom Extrusion. Note The rim of the Plate Gasket must evenly fit around the top and bottom extrusions. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 16 Install the two flat head screws to secure the Front Plate and the Plate Gasket to the unit. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
