NCR VOYIX 7772-K241 Kit Instructions

Solid state drive for cx7/ cx8/ cx5 (7772/7773/7736)
Hide thumbs

Advertisement

Table of Contents

Solid State Drive (SSD)
Kit Instructions
7772-K241/K253/K255
Issue G
© 2024 NCR Voyix. All rights reserved. Confidential and proprietary information of NCR Voyix.
Use and disclose solely pursuant to company instructions.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7772-K241 and is the answer not in the manual?

Questions and answers

Summary of Contents for NCR VOYIX 7772-K241

  • Page 1 Solid State Drive (SSD) Kit Instructions 7772-K241/K253/K255 Issue G © 2024 NCR Voyix. All rights reserved. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 2: Copyright

    NCR Voyix, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR Voyix in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR Voyix representative or NCR Voyix office for information that is applicable and current.

  • Page 3: Table Of Contents

    Table of Contents Copyright Solid State Drive (SSD) Kit Contents Installation Procedure NCR CX7 All-in-One POS (7772)/NCR CX5 All-in-One POS (7773) NCR CX8 POS (7736) Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 4 Added installation procedure for CX8 (7736) Jan 2021 Added K256 Aug 2021 Updated PNs for K253 and K255 Removed K256 Dec 2021 Added Warning statement Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 5: Solid State Drive (Ssd)

    NCR CX7 All-in-One POS (7772) or NCR CX8 POS (7736) 7772-K241 – 120GB SSD 7772-K253 – 240GB SSD 7772-K255 – 480GB SSD NCR CX5 All-in-One POS (7773) 7772-K241 – 120GB SSD Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 6: Kit Contents

    Apacer 480GB 4-channel BiCs4 NVMe M.2 Module (PNPE1B3A) 7772-K256 480GB NVMe 4-channel SSD 006-8627556 Screw, M3x4mm Phillips, Low Profile, Black 006-8627767 Storage, Apacer, 480GB M.2 42mm NVME PCIe Gen3 X4 Module Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 7: Installation Procedure

    Always use a soft material (cloth, foam) to protect the display screen when placing the terminal face down. 2. Remove the Cable Cover. a. Remove the two (2) screws that secure the Cable Cover to the Back Cover. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 8 Loosen the thumbscrew of the 180-degree USB-C Cable then disconnect the Cable. b. Remove the Ethernet Cable from the Cable Management Hook then disconnect the Cable. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 9 4. Loosen the two (2) captive screws that secure the Back Cover to the Display. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 10 5. Rotate the Back Cover away from the Display and unhook the Back Cover Tabs. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 11 7. Secure the M.2 SSD to the Motherboard with a screw. Note When installing the secondary M.2 SSD in M.2 Port 2, ensure cables are not pinched by the SSD and the SSD’s mounting screw. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.

  • Page 12: Ncr Cx8 Pos

    1. Remove the Top Cover. There are two types of Top Covers: Top Cover without Duct — Remove the four (4) screws securing the Top Cover to the chassis. Top Cover with Duct Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 13 There are two M.2 Ports on the Motherboard. The primary M.2 SSD should be installed in the M.2 Port 1, and the secondary M.2 SSD (for dual media) should be installed in the M.2 Port 2. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 14 3. Secure the M.2 SSD to the Motherboard with a screw. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 15 4. Reinstall the Top Cover. Top Cover without Duct – Install the Top Cover on the chassis using four (4) screws. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
  • Page 16 Slide the Top Cover in the direction shown to align the screw holes of the Cover with the screw holes of the chassis. c. Secure the Top Cover with four (4) screws. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
