Summary of Contents for Synetik ErgoCare PIPER
- Page 1 PIPER User manual...
-
Page 2: Table Of Contents
Index Intended use ..........................2 Warranty............................3 Safety and warning notes ......................3 Transportation ......................... 5 Overview of the Piper ........................5 Technical specification ........................ 5 Configuration ..........................6 Box contents ..........................6 Unboxing the Piper ........................6 Assembling the Piper ........................6 Hex Key ............................ -
Page 3: Intended Use
Intended use The Piper comfort stroller is built for short stay usage of children with special needs. It’s fully foldable frame is produced from lightweight aluminum profiles. The Piper is equipped with an adjustable calf rest, a 45 degrees reclining... -
Page 4: Warranty
seating specialist. Products corresponds to the newest EC standards as well as hygienic, technical and safety requirements. You will find all the details in the assembly section and on our website: www.synetikergocare.com. Warranty 1. On this product is applied 24-month warranty from the date of sale. The warranty is applied for material and manufacturing defects. - Page 5 Safety of a child might be in danger in case you will not follow the instructions and safety notices mentioned I the user guide. Safety points to consider when using the Piper stroller. BAGS ATTACHED TO THE HANDLE AFFECT THE STABILITY OF THE BUGGY •...
-
Page 6: Transportation
Synetik ErgoCare does not bear any responsibility for the damages and accidents caused • by inappropriate use of this product. The Piper stroller-style wheelchair has successfully passed impact tests. The seat meets the ISO Transportation 7176-19. The tests were carried out in all possible configurations of the product. -
Page 7: Configuration
1- Remove the contents of the boxes and place on a flat surface. 2- Make sure that the material corresponds to what you ordered and that no damage was caused by the transport. 3- Follow the instructions in the following section (assembling the Piper) Assembling the Piper... -
Page 8: Hex Key
Synetik ErgoCare representative. Hex Key Only one tool may be needed to assemble and adjust the Piper stroller. The main tool is a hex key that is in a pocket on the back of the backrest. Opening the Stroller To complete the assembly, you need to;... -
Page 9: Seat Depth
1. Seat depth The seat should support the tights on their whole length. To change the seat depth you need to; 1.1 Undo the velcro panel connecting the seat and backrest 1.2 Partially fold the buggy to relieve fabric tension 1.3 Grasp the end of the seat tube, press the seat spring button and move the seat tube until the spring button relocates into the desired hole 1.4 Repeat for other side of seat... -
Page 10: Daily Usage
Shorten the seat reinforcement straps to increase tension Never change the width of the seat by adjusting the seat tension. Daily usage Synetik ErgoCare recommends making a daily inspection before installing a child inside the Piper stroller. Opening the stroller 1. -
Page 11: Getting Out Of The Stroller
Getting out of the stroller 1. Ensure that the parking brakes are on 2. If possible, place the back of the buggy against a wall or immovable object (alternatively, another helper may hold the pushchair steady) 3. Unfasten safety belt 4. -
Page 12: Cleaning Instructions
2. Wash by hand on Max. 40 °C with mild detergent. Maintenance Synetik ErgoCare recommends that a daily visual inspection of equipment be performed daily by a therapist, parent or caregiver to ensure the safe use of the product. Recommended tire pressure: front/rear - 230/230 kPa Your Stroller has been designed to a high standard and with correct use and maintenance will give many years of trouble-free service. - Page 13 If there are used control cables (brakes, telescopes, tilt), check it regularly and, if necessary, set up and oil them. Synetik ErgoCare reserves the right to make design changes to any of their products without prior notice as a part of their continuous development program.
