USER GUIDE
PIPER
V1 2019-02-07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PIPER and is the answer not in the manual?

Questions and answers

Related Manuals for Synetik ErgoCare PIPER

Summary of Contents for Synetik ErgoCare PIPER

  • Page 1 USER GUIDE PIPER V1 2019-02-07...

  • Page 2: Table Of Contents

    Table of Contents Intended Use ..........................2 Warranty ............................ 3 Safety and Warning Notes ......................4 Transportation ........................... 5 Overview of the Piper ........................ 5 Technical Specifications ......................6 Configuration ..........................7 Box Contents ..........................7 Unboxing the Piper ........................7 Assembling the Piper .........................

  • Page 3: Intended Use

    Business Hours: 8 am to 4 pm Eastern Time Only use parts and accessories supplied by Synetik ErgoCare. Any substitution of parts with those of another company will result in the loss of warranty and may cause damage. Read this manual carefully before using the stroller for the first time and keep it for future reference.

  • Page 4: Warranty

    The Piper stroller-style wheelchair comes in one size. This stroller is produced from lightweight alloy. It is equipped with an optimized folding system, adjustable calf rest, extended reclining backrest and a large detachable and adjustable footrest. The stroller also comes with solid quick- release wheels for a stable ride.

  • Page 5: Safety And Warning Notes

    The safety of a child might be in jeopardy if the instructions and safety information listed in the User Guide are not followed. Safety points to consider when using the Piper Stroller. • BAGS ATTACHED TO THE HANDLE AFFECT THE STABILITY OF THE...

  • Page 6: Transportation

    Transportation The Piper stroller-style wheelchair has successfully passed impact tests. The seat meets the WC-19 and ISO 7176-19. The tests were carried out in all possible configurations of the product. To be compliant, the wheelchair must have the transit option which includes 4 tie-downs.

  • Page 7: Technical Specifications

    17. Backrest recline locking catch 8. Buttons to remove the footrest 18.Transport safety-catch 9. Front wheels 19. Backrest 10. Swivel lock Technical Specifications Measurements Piper Backrest Height 26.8 Seat Depth 8 -11.4 (*) Seat Width 8 -13.8 (*) Seat to Footrest 9.8–14.8...

  • Page 8: Configuration

    Attach the 4 metal snaps to both sides of the chassis frame. Apply pressure on the cover to make sure it is properly fastened. 4- Follow the instructions in the following section (Assembling the Piper) Assembling the Piper The instructions in the User Guide will guide you through the assembly process of the positioning seat.

  • Page 9: Assembling The Rear Wheels

    1- Insert and push each swivel wheel into the wheel moulding until you hear a ‘click’ which indicates the wheel is properly locked in. Assembling the Rear Wheels 1- Insert each wheel axle into the wheel moulding and push in until locked. You should hear a ‘click’...

  • Page 10: Seat Depth

    1. Seat Depth Use the seat inlay to reduce the seat depth. It is possible to trim the backrest wedge to obtain the desired depth. Refer to the Accessories section for more information. 2. Brakes To engage the brake, press the brake lever (14) fully to the end position. To disengage the parking brake, lift the brake lever.

  • Page 11: Daily Usage

    Daily Usage Synetik ErgoCare recommends performing a daily inspection before seating a child in the Piper Stroller. Opening the Stroller 1. Release the transport safety-catch (18) 2. Push the stroller partially into the upright position (Pic.7a) 3. Stand between the rear wheels of the stroller and using your foot, push down the pedal (Pic.

  • Page 12: Footplate Height Adjustment

    NOTE: For a more compact folding you can: 1. Remove the front swivel wheels - a. Press the front wheel-release button to remove the wheels (Pic. 13b) 2. Remove the rear wheels – a. Press the rear wheel-release button to remove the wheels (Pic.13a) Footplate Height Adjustment 1- Remove the footrest locking pins (7) located on both sides of the front frame (Pic.

  • Page 13: Front Wheel Swivel Lock

    Front Wheel Swivel Lock If needed, the front wheel forks can be locked against vertical rotation. The wheels are only locked in the direction of travel. 1. Press the lock lever (10) down to lock the wheel. (Pic. 15c). 2. Make sure, with a slight pull on the wheels that they are both properly locked. 3.

  • Page 14: Getting Into The Stroller

    Getting into the Stroller 1. Ensure the parking brakes are on 2. To make access easier, the footrest can be removed 3. If possible, place the back of the stroller against a wall or immovable object (alternatively, another helper may hold the stroller steady) 4.

  • Page 15: Negotiating Curb Or Single Steps

    Going up stairs: 1- Position the stroller squarely with the rear wheels against the bottom step. 2- Tilt the stroller backward and raise toward the next step. 3- The helper stands in front, steadies and lifts the stroller by firmly holding on to the front frame.

  • Page 16: Thigh Fixation - 010-169

    Thigh Fixation – 010-169 Mounting – 1- Attach the thigh support to the seat using the Velcro straps. 2- Place the thigh support on the front part of the stroller seat and Velcro the straps underneath the seat 3- Secure the child’s thighs in place using the Velcro straps, which you thread through the metal clips.

  • Page 17: H-Style Harness - 010-135

    H-Style Harness – 010-135 1- Slip the shoulder straps through the upholstery opening according to the top shoulder height of the child. *For lower upholstery openings, run the upper straps under the upholstery up to the highest opening in the backrest and insert the buckle of strap through the hole in the backrest.

  • Page 18: Seat Inlay - 010-175

    Seat Inlay - 010-175 Install- 1- Unclip the shoulder straps of the 5-point belt. 2- Place the seat inlay over the seat and run the shoulder straps through the holes in the reduction pad according to the shoulder height of the child. 3- Run the side straps of the 5-point belt under the sides of the seat inlay.

  • Page 19: Headrest Adjustable - 010-173

    Headrest Adjustable – 010-173 1- Position the headrest at the required height of the backrest and secure the Velcro straps onto the back of the backrest. 2- To lower the position of the headrest, thread the straps through the holes in the upholstery and then secure the headrest with the Velcro straps onto the back of the backrest.
  • Page 20 1. During transit, the chair must be forward facing. 2. The wheelchair tie-downs must be securely attached to the four red anchor points on the chair. See above photo for anchor points. 3. All floor tie-down straps must be drawn tight in the front and the back to eliminate any forward/aft movement of the chair.

  • Page 21: Cleaning Instructions

    5- To attach the upholstery, follow steps in reverse order. Maintenance Synetik ErgoCare recommends that a daily visual inspection of equipment be performed by a therapist, parent or caregiver to ensure the safe use of the product. Your Stroller has been designed to a high standard and with correct use and maintenance...
  • Page 22 If there are used control cables (brakes, telescopes, tilt), check it regularly and, if necessary, oil them. Synetik ErgoCare reserves the right to make design changes to any of their products without prior notice as a part of their continuous development program.
